REXROTH-CSB01模块备件

REXROTH-CSB01

补充硬件配置
系统要求
AutoMax的灵活性允许控制系统设计者
选择适合
应用
典型的AutoMax系统由一个或多个单元组成。
每个单元可以基于多总线机架或基于PC卡
取决于系统参数。基于机架的单元
由电源和底盘组成，具有各种类型的
处理器、输入/输出和通信模块。这个
基于PC卡的单元安装在单机中
打包版本，也提供电源
PC卡模块和串行
接口模块或模块安装在其中一个
客户PC电脑。PC卡模块包括
配备内置DCS网络和A-B远程输入/输出端口。
各装置通过DCS网络相互通信
网络它们还通过远程输入/输出网络连接到输入/输出。
该系统还提供单元之间的数据共享
在同一单元中的程序之间。此外
基于多总线的机架单元用于协调
同一机架中有多个处理器。本通信
数据共享允许工业控制功能
分布在多个单元之间。
•可加载运行库大大简化了合并
系统的未来增强。操作
系统从cd加载到AutoMax中。
•多处理功能让您可以添加更多
需要时，AutoMax机架中的处理器电源
它无需重写应用软件。
•多任务使程序开发、检查
通过允许软件被破坏，支持更容易
分为逻辑部分或任务。AutoMax允许
处理器内多个任务的并发操作
根据您分配的先级。
•3种编程语言可用于编程
AutoMax任务：梯形图逻辑、控制块和
增强的基本功能。用户选择有效的
用于编程每个任务的语言。
•高速网络允许共享信息
在AutoMax机架之间轻松切换，从而解放用户
配置硬件以实现高的成本效益
安装
•远程输入/输出功能允许您将输入/输出放置在
控制设备以降低布线成本。
•内置诊断，结合车载状态
LED和数字显示器，有助于实现可靠的
操作简单，易于故障排除。
•与非AutoMax设备的通信，例如
CRT和主机，通过使用
可用的网络接口和串行端口。
Artisan Technology Group-质仪器…保证|（888）88-SOURCE | www.artistatg.com
概述-5
全体的
•IBM PC–兼容编程执行功能
完整文档、在线过程监控、梯形图
逻辑修改、程序上传和下载
能力。
多用途控制器
AutoMax的设计包含了许多功能
允许硬件和软件有效运行
在许多类型的单机和多单元中高效运行
分布式工业控制装置。
多任务操作系统
AutoMax软件操作系统提供
多个程序或任务的实时并发操作
在共享时，以先级为基础在同一处理器上
系统数据和控制信号。虽然只有一个任务运行
在同一处理器上执行任务
调度，以便每个任务通过
一段时间。这种多任务处理允许用户
将控制方案分为单独的任务，其中
简化了
应用程序。AutoMax中的多任务也
减少总体执行时间并提供更快的
对关键任务的响应。
多处理硬件
在基于机架的装置中
AutoMax基于广泛使用和接受的总线
结构，Intel的多总线。多总线，经过多年的现场验证
工业用途，提供了一个高度可靠的基础
建立一个非常可靠的产品。
通过选择多总线，信实电气确保了
AutoMax将满足工业
控制今天和未来。
利用多总线标准和AutoMax操作系统
系统允许实现一个独特的
AutoMax中的多处理架构。
多处理是对额外需求的解决方案
工业中的输入/输出、速度、内存和处理能力
控制应用程序。AutoMax多可容纳
多总线机架中的四个处理器模块以及一个
公共内存模块。网络等其他卡
和远程输入/输出通信模块、接口模块
通用输入/输出模块可以作为
空间允许。AutoMax的独特功能
多处理系统是指程序任务
可在处理器之间传输–扩展
不需要对现有任务重新编程。使用的内存
至stor

REXROTH-CSB01

REXROTH-CSB01

Hardware Configurations To Complement The System Requirements The flexibility of AutoMax allows the control system designer to select the hardware configuration best suited to the application. A typical AutoMax System is made up of one or more units. Each unit can be Multibus rack based or PC- card based depending the system parameters. The rack based units consist of power supply and chassis with various types of processor, input/output and communications modules. The PC-Card based units are either installed in stand-alone packaged versions, which also provide the power supply necessary for the PC-Card module as well as a serial interface module or the module is installed in one of the customers PC computers. The PC-Card modules are complete with built-in DCS-Net and A-B Remote I/O ports. The units communicate with each other using the DCS-Net network. They also connect to I/O via remote I/O networks. The System provides sharing of data between units as well as between programs in the same unit. In addition, the Multibus based rack units provide for coordination between multiple processors in the same rack. This communications and data sharing allows the industrial control function to be distributed among multiple units. • Loadable run base greatly simplifies the incorporation of future enhancements to the system. The operating system is loaded into the AutoMax from a cd. • Multi-processing capability lets you add more processor power in the AutoMax rack when you need it. . .without rewriting your application software. • Multi-tasking makes program development, checkout and support easier by allowing the software to be broken into logical parts or tasks. The AutoMax permits concurrent operation of multiple tasks within a processor according to the priorities you assign. • 3 programming languages are available to program AutoMax tasks: Ladder Logic, Control Block and Enhanced BASIC. The user chooses the most effective language for programming each task. • High-speed network allows information to be shared easily between AutoMax racks, thus freeing the user to configure the hardware for the most cost effective installation. • Remote I/O capability lets you place the I/O near the equipment to be controlled for reduced wiring costs. • Built-in diagnostics, coupled with on-board status LEDs and digital displays, help to make for reliable operation and easy troubleshooting. • Communications to non-AutoMax devices, such as CRTs and host computers, is simple through the use of available network interfaces and serial ports. Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com General-5 General • IBM PC – compatible programming executive features full documentation, on-line process monitoring, ladder logic modifications, and program upload and download capability. A Multi-Use Controller The design of the AutoMax incorporates many features that allow the hardware and software to function effectively and efficiently in many types of stand-alone and multi-unit distributed industrial control installations. Multi-Tasking Operating System The AutoMax Software Operating System provides the real-time concurrent operation of multiple programs or tasks on the same processor on a priority basis, while sharing system data and control signals. Though only one task runs at a time on the same processor, the execution of the tasks is scheduled so that each task shares the processor over a period of time. This multi-tasking permits the user’s overall control scheme to be separated into individual tasks which simplifies writing, checkout and maintenance of the application program. Multi-tasking in the AutoMax also reduces overall execution time and provides a faster response to critical tasks. Multi-Processing Hardware In the rack based units, internal communications of the AutoMax are based on the widely used and accepted bus structure, Multibus by Intel. Multibus, field proven by years of industrial use, provides a highly dependable base on which to build a very reliable product. By choosing Multibus, Reliance Electric has insured that the AutoMax will meet the demanding requirements of industrial control today and in the future. Utilizing the Multibus standard and the AutoMax operating system allows the implementation of a unique multi-processing architecture in the AutoMax. Multi-processing is a solution to requirements for additional I/O, speed, memory, and processing power in industrial control applications. The AutoMax will accommodate up to four Processor Modules in the Multibus rack along with a Common Memory Module. Other cards such as the Network and Remote I/O Communication Modules, Interface Modules and the general I/O Modules can be inserted in the rack as space permits. The unique feature of the AutoMax multi-processing system is that program tasks are transportable from processor to processor – expansion requires no reprogramming of existing tasks. Memory used to store process parameters and data in any of the Processor modules is accessible by other Processor Modules and this access is transparent to the user. Multi-Language Programming In conjunction with it’s Multi-tasking Operating System, the AutoMax also provides three separate languages for programming, each tailored to a specific need. The LADDER LOGIC language is used for sequencing operations and discrete input/output. It allows the user to program the I/O and internal contacts and coils with easily recognizable names. The CONTROL BLOCK language is used for analog regulation and process control. The blocks are preconfigured control statements that allow the user to easily specify control strategies. The ENHANCED BASIC is used for arithmetical operations, numeric and string handling, and host computer communications. The ENHANCED BASIC tasks link the AutoMax to keyboard and CRT-based operator interface devices. The CONFIGURATION task sets the priority and scheduling of all of the various Ladder Logic, Control Block, and BASIC tasks in the application program and defines all system I/O. Programming Systems IBM Based Development Executive Software DCS Network 56 nodes (1 master, 55 slaves), 1.75 mbaud, Multidrop configuration 3000 ft. with Belden 9259 or equivalent coaxial cable. AutoMax Remote I/O System Up to 15 remote I/O processors can be installed in each master rack. Each remote I/O network provides for up to 7 remote I/O drops. Allen-Bradley Remote I/O System Up to 15 remote I/O processors can be installed in each master rack. Each remote I/O network provides for up to 7 remote I/O drops. AutoMax Specifications Power Requirements Input power: 120 VAC 50/60 Hz (+10%, –15%) Output power: 50 amps @ 5 VDC Environment Operating temperature range: –0 to +60oC Storage temperature range: –40 to 85oC Humidity range: 5 to 90% Non-Condensing Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com General-6 General AutoMax Processors AutoMax 6011: Motorola 68010, 8 mHz clock rate AutoMax 7010: Motorola 68020, 25 mHz clock rate AutoMax PC3000: Motorola 68040, 25 mHz clock rate AutoMax 6011 and 7010 processors can be mixed in the same rack. All processors may be programmed over the DCS-Network. The 6011, 7010 and the PC3000 packaged version processors each have 2 serial ports. The PC3000 processor does not have serial ports. * IBM-PC is a trademark of International Business Machines. Motorola 68010, 68020 and 68040 are trademarks of Motorola Corporation. Data Highway and Data Highway Plus are trademarks of Allen-Bradley Company, Inc. Modbus and Modbus Plus are trademarks of Modicon. Multibus is a trademark of Intel Corporation. Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com General-7 General Approvals/Certification/Registration UL Approval Generally, we pursue applicable UL approval for our products. There are two relevant types of approval granted by Underwriters Laboratories (UL): • UL Recognized: If a product was UL Recognized at the time this catalog was printed, we included the following either in its specification section or in the UL/CSA information at the end of each section: UL Recognized • UL Listed: If a product was UL Listed at the time this catalog was printed, we included the following either in its specification section or in the UL/CSA information at the end of each section: Actual UL approval is indicated by the label on the product and not by statements in this catalog or any product literature. CSA Certification Generally, we pursue applicable CSA certification for our products. CSA certifies products for general use as well as for use in hazardous locations. Products in this catalog might be certified in one of these two ways: • CSA Class 1, Division 2 Hazardous Location Certification: This product is listed by the Canadian Standards Association as certified for use in Class 1, Division 2, Group A, B, C, D, or non-hazardous locations only. If a product possessed this certification at the time this catalog was printed, we included the following either in its specification section or in the UL/CSA information at the end of each section: Class 1, Division 2 Hazardous • CSA Normal Certification: The product is listed by the Canadian Standards Association as certified for non-hazardous locations. If a product possessed this certification at the time this catalog was printed, we included the following either in its specification section or in the UL/CSA information at the end of each section. Actual CSA certification is indicated by the label on the product and not by statements in this catalog or any
