用户程序的相互影响是可能的！
在多个用户程序中使用相同的全局变量可能会导致不同的结果
用户程序之间的相互影响所导致的后果。
ƒ仔细规划在多个用户程序中使用相同的全局变量。
ƒ使用SILworX中的交叉引用检查全局数据的使用。全球数据
只能由一个实体（在用户程序中）从
安全相关输入或通过安全相关通信协议！
用户有责任排除由于以下原因造成的任何潜在操作干扰：
用户程序的相互影响！
有关多任务处理的详细信息，请参阅系统手册（HI 801 001 E）
10.2.12测试机构的验收
HIMA建议在设计测试时尽快让测试机构参与
须经批准的系统。
本验收测试仅适用于用户功能，但不适用于安全相关的功能
已批准的HIMax系统的模块和自动化设备。
10.3创建用户程序的检查表
为了在编程阶段遵守所有安全相关方面，HIMA
建议在加载新的或修改的文件之前和之后使用以下检查表：
程序检查表可用于帮助规划和演示
后来，规划阶段仔细完成。
检查表以Microsoft®Word®格式在HIMA网站上提供。
HIMax 11配置通信
HI 801 003 E版本4.00第51页，共64页
11.配置通信
除了使用物理输入和输出变量外，还可以使用变量值
通过数据连接与其他系统交换。在这种情况下，变量为：
由编程系统SILworX从
对应的资源。
11.1标准协议
许多通信协议仅确保非安全相关的数据传输。这些
协议可用于自动化任务的非安全相关方面。
危险
因使用不安全的导入数据而造成的人身伤害
请勿将从不安全源导入的任何数据用于用户的安全功能
程序
以下标准协议可用：
ƒ在通信模块的以太网接口上：
-Modbus TCP（主/从）
-Modbus，冗余（从）。
-SNTP
-发送/接收TCP
-PROFINET IO（控制器、设备）。
ƒ在通信模块的现场总线接口（RS485）上，根据
设备型号：
-Modbus（主/从）。
-Modbus，冗余（从）。
-PROFIBUS DP（主/从）
11.2安全相关协议：安全以太网
使用safeethernet编辑器配置如何监控安全相关通信。
有关安全以太网的更多详细信息，请参阅通信手册（HI 801 101 E）。
注
可能出现意外过渡到安全状态！
ReceiveTMO是一个安全相关参数！
ReceiveTMO是PES 1的监控时间，在此时间内，PES 2做出正确响应
必须接收。
i ReceiveTMO也适用于从PES 2到PES 1的其他方向！
如果没有从ReceiveTMO内的通信伙伴接收到正确的响应，
HIMax终止安全相关通信。本发明的输入变量
safeethernet连接根据预设参数“冻结数据打开”做出反应
丢失连接[ms]。“使用初始数据”设置只能用于与安全相关的应用程序
这些功能通过安全以太网实现。
11.配置通信HIMax
第52页，共64页HI 801 003 E版本4.00
i在以下等式中用于确定坏情况下的反应时间、目标循环时间和反应时间
如果目标循环时间模式设置为auf Fix或
固定和容忍。
HIMax 11配置通信
HI 801 003 E版本4.00第53页，共64页
11.3安全以太网的坏情况反应时间
在以下示例中，仅适用于计算坏情况下反应时间的公式
如果参数安全时间=2，则申请与HIMatrix控制器连接*
看门狗时间已设置。这些公式始终适用于HIMax控制器。
i允许的坏情况反应时间取决于工艺，必须达成一致
以及负责终检验的测试机构。
条款
ReceiveTMO：PES 1的监控时间，在此时间内PES 2做出正确响应
必须接收。否则，安全相关的通信将被禁用
在时间到期后终止。
生产率：两次数据传输之间的小间隔。
看门狗时间：控制器运行周期允许的大持续时间。这个
运行周期的持续时间取决于用户的复杂性
程序和安全以太网连接的数量。看门狗
必须在资源属性中输入时间（WDT）。
坏的情况
反应时间
坏情况下的反应时间是两次事件之间的时间
PES 1的物理输入信号（in）和对其的反应
PES 2的相应输出（out）。
延迟：transm的延迟
