2500-C200模块备件

2500-C200

注意：本设备适用于污染等级为2的工业环境，适用于过电压II类应用（如EN/IEC中所定义
60664-1），在海拔高达2000米（6562英尺）的情况下无降额。
本设备不适用于居住环境，可能无法为此类环境中的无线电通信服务提供充分保护
环境。
本设备作为开放式设备提供，供室内使用。它必须安装在为特定用途而适当设计的外壳内
存在的环境条件，并适当设计，以防止因接触带电部件而造成人身伤害。围墙
必须具有适当的阻燃性能，以防止或大限度地减少火焰蔓延，符合5VA的火焰蔓延额定值，或获得批准用于：
如果是非金属的应用。必须使用工具才能接近外壳内部。本出版物的后续章节可能包含更多内容
有关符合某些产品安全认证所需的特定外壳类型额定值的信息。
除本出版物外，请参见以下内容：
•工业自动化布线和接地指南，出版物1770-4.1，了解更多安装要求。
•NEMA标准250和EN/IEC 60529（如适用），用于解释外壳提供的防护等级。
防止静电放电
注意：本设备对静电放电敏感，可能导致内部损坏，影响正常运行。遵循这些准则
处理此设备时：
•触摸接地物体以释放静电。
•佩戴经批准的接地腕带。
•请勿触摸组件板上的连接器或插脚。
•请勿触摸设备内部的电路部件。
•如果可用，使用静态安全工作站。
•不使用时，将设备储存在适当的静电安全包装中。
英国和欧洲危险场所批准
以下模块经英国和欧洲2区批准：1794-IB8、1794-IB16。
以下适用于标有II 3 G的产品：
•属于设备组II，设备类别3，并符合与此类设备的设计和施工相关的基本健康和安全要求
见UKEX附表1和欧盟指令2014/34/EU附件II。参见韩国的UKEx和欧盟合规声明。有关详细信息，请参阅汽车/认证。
•根据EN IEC -0:2018和EN IEC 7-7:2015+A1:2018，保护类型为Ex-ec IIC T4 Gc（1794-IB16）。
•根据EN -0:2009和EN -15:2010，保护类型为Ex-nA IIC T3 Gc（1794-IB8）。
•符合标准EN IEC -0:2018和EN IEC 7-7:2015+A1:2018参考证书编号DEMKO 14 ATEX 1342501X和UL22UKEX2378X。
•符合标准EN -0:2009、EN -15:2010，参考证书编号LCIE 01ATEX6020X。
•拟用于不太可能发生气体、蒸汽、雾气或空气引起的爆炸性环境的区域，或可能仅偶尔发生的区域
时期。根据UKEX 20161107号法规和ATEX指令2014/34/EU，此类位置对应于2区分类。
IEC危险场所认证
以下适用于具有IECEx认证（1794-IB16）的产品：
•拟用于气体、蒸汽、雾气或空气造成的爆炸性环境不太可能发生，或可能仅偶尔发生的区域
短期内。这些位置对应于IEC -0的2区分类。
•根据IEC -0和IEC -7，保护类型为Ex-ec IIC T4 Gc。
•符合标准IEC -0，爆炸性环境0部分：设备-一般要求，7版，修订日期2017，IEC -7，5.1版修订日期
2017，爆炸性环境-7部分：通过增加安全性“e”保护设备，参考IECEx证书编号IECEx UL 14.0066X。
警告：安全使用的特殊条件：
•该设备应安装在UKEX/ATEX/IECEx 2区认证外壳中，低防护等级至少为IP54（根据
符合EN/IEC -0），并且当应用于2区环境时，用于不超过2级污染度的环境（如EN/IEC 60664-1所定义）。这个
必须使用工具才能访问机柜。
•该设备应在罗克韦尔自动化公司规定的额定值范围内使用。
•应提供瞬态保护，其设置水平不超过设备供电端子处峰值额定电压值的140%。
•应遵守用户手册中的说明。
•该设备只能与UKEX/ATEX/IECEx认证的罗克韦尔自动化背板一起使用。
•通过在轨道上安装模块实现接地。
警告：使用螺钉、滑动插销、螺纹接头固定与本设备匹配的任何外部连接

2500-C200

2500-C200

ATTENTION: This equipment is intended for use in a Pollution Degree 2 industrial environment, in overvoltage Category II applications (as defined in EN/IEC 60664-1), at altitudes up to 2000 m (6562 ft) without derating. This equipment is not intended for use in residential environments and may not provide adequate protection to radio communication services in such environments. This equipment is supplied as open-type equipment for indoor use. It must be mounted within an enclosure that is suitably designed for those specific environmental conditions that will be present and appropriately designed to prevent personal injury resulting from accessibility to live parts. The enclosure must have suitable flame-retardant properties to prevent or minimize the spread of flame, complying with a flame spread rating of 5VA or be approved for the application if nonmetallic. The interior of the enclosure must be accessible only by the use of a tool. Subsequent sections of this publication may contain more information regarding specific enclosure type ratings that are required to comply with certain product safety certifications. In addition to this publication, see the following: • Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1, for more installation requirements. • NEMA Standard 250 and EN/IEC 60529, as applicable, for explanations of the degrees of protection provided by enclosures. Prevent Electrostatic Discharge ATTENTION: This equipment is sensitive to electrostatic discharge, which can cause internal damage and affect normal operation. Follow these guidelines when you handle this equipment: • Touch a grounded object to discharge potential static. • Wear an approved grounding wriststrap. • Do not touch connectors or pins on component boards. • Do not touch circuit components inside the equipment. • Use a static-safe workstation, if available. • Store the equipment in appropriate static-safe packaging when not in use. UK and European Hazardous Location Approval The following modules are UK and European Zone 2 approved: 1794-IB8, 1794-IB16. The following applies to products marked II 3 G: • Are Equipment Group II, Equipment Category 3, and comply with the Essential Health and Safety Requirements relating to the design and construction of such equipment given in Schedule 1 of UKEX and Annex II of EU Directive 2014/34/EU. See the UKEx and EU Declaration of Conformity at rok.auto/certifications for details. • The type of protection is Ex ec IIC T4 Gc (1794-IB16) according to EN IEC -0:2018 and EN IEC -7:2015+A1:2018. • The type of protection is Ex nA IIC T3 Gc (1794-IB8) according to EN -0:2009 & EN -15:2010. • Comply to standards EN IEC -0:2018 & EN IEC -7:2015+A1:2018 reference certificate number DEMKO 14 ATEX 1342501X and UL22UKEX2378X. • Comply to standards EN -0:2009, EN -15:2010, reference certificate number LCIE 01ATEX6020X. • Are intended for use in areas in which explosive atmospheres caused by gases, vapors, mists, or air are unlikely to occur, or are likely to occur only infrequently and for short periods. Such locations correspond to Zone 2 classification according to UKEX regulation 2016 No. 1107 and ATEX directive 2014/34/EU. IEC Hazardous Location Approval The following applies to products with IECEx certification (1794-IB16): • Are intended for use in areas in which explosive atmospheres caused by gases, vapors, mists, or air are unlikely to occur, or are likely to occur only infrequently and for short periods. Such locations correspond to Zone 2 classification to IEC -0. • The type of protection is Ex ec IIC T4 Gc according to IEC -0 and IEC -7. • Comply to Standards IEC -0, Explosive atmospheres Part 0: Equipment - General requirements, Edition 7, Revision Date 2017, IEC -7, 5.1 Edition revision date 2017, Explosive atmospheres - Part 7: Equipment protection by increased safety "e", reference IECEx certificate number IECEx UL 14.0066X. WARNING: Special Conditions for Safe Use: • This equipment shall be mounted in an UKEX/ATEX/IECEx Zone 2 certified enclosure with a minimum ingress protection rating of at least IP54 (in accordance with EN/IEC -0) and used in an environment of not more than Pollution Degree 2 (as defined in EN/IEC 60664-1) when applied in Zone 2 environments. The enclosure must be accessible only by the use of a tool. • This equipment shall be used within its specified ratings defined by Rockwell Automation. • Transient protection shall be provided that is set at a level not exceeding 140% of the peak rated voltage value at the supply terminals to the equipment. • The instructions in the user manual shall be observed. • This equipment must be used only with UKEX/ATEX/IECEx certified Rockwell Automation backplanes. • Earthing is accomplished through mounting of modules on rail. WARNING: Secure any external connections that mate to this equipment by using screws, sliding latches, threaded connectors, or other means provided with this product. Do not disconnect equipment unless power has been removed or the area is known to be nonhazardous. WARNING: When you insert or remove the module while backplane power is on, an electric arc can occur. This could cause an explosion in hazardous location installations. Be sure that power is removed or the area is nonhazardous before proceeding. Repeated electric arcing causes excessive wear to contacts on both the module and its mating connector. Worn contacts may create electrical resistance that can affect module operation. 4 Rockwell Automation Publication 1794-IN093G-EN-P - July 2022 FLEX I/O Digital Input Modules Installation Instructions North American Hazardous Location Approval The Following Information Applies When Operating This Equipment In Hazardous Locations. Informations sur l’utilisation de cet équipement en environnements dangereux. Products marked "CL I, DIV 2, GP A, B, C, D" are suitable for use in Class I Division 2 Groups A, B, C, D, Hazardous Locations and nonhazardous locations only. Each product is supplied with markings on the rating nameplate indicating the hazardous location temperature code. When combining products within a system, the most adverse temperature code (lowest "T" number) may be used to help determine the overall temperature code of the system. Combinations of equipment in your system are subject to investigation by the local Authority Having Jurisdiction at the time of installation. Les produits marqués "CL I, DIV 2, GP A, B, C, D" ne conviennent qu'à une utilisation en environnements de Classe I Division 2 Groupes A, B, C, D dangereux et non dangereux. Chaque produit est livré avec des marquages sur sa plaque d'identification qui indiquent le code de température pour les environnements dangereux. Lorsque plusieurs produits sont combinés dans un système, le code de température le plus défavorable (code de température le plus faible) peut être utilisé pour déterminer le code de température global du système. Les combinaisons d'équipements dans le système sont sujettes à inspection par les autorités locales qualifiées au moment de l'installation. WARNING: Explosion Hazard – • Do not disconnect equipment unless power has been removed or the area is known to be nonhazardous. • Do not disconnect connections to this equipment unless power has been removed or the area is known to be nonhazardous. Secure any external connections that mate to this equipment by using screws, sliding latches, threaded connectors, or other means provided with this product. • Substitution of components may impair suitability for Class I, Division 2. AVERTISSEMENT: Risque d’Explosion – • Couper le courant ou s'assurer que l'environnement est classé non dangereux avant de débrancher l'équipement. • Couper le courant ou s'assurer que l'environnement est classé non dangereux avant de débrancher les connecteurs. Fixer tous les connecteurs externes reliés à cet équipement à l'aide de vis, loquets coulissants, connecteurs filetés ou autres moyens fournis avec ce produit. • La substitution de composants peut rendre cet équipement inadapté à une utilisation en environnement de Classe I, Division 2. ATTENTION: • If this equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired. • Read this document and the documents listed in the Additional Resources section about installation, configuration, and operation of this equipment before you install, configure, operate, or maintain this product. Users are required to familiarize themselves with installation and wiring instructions in addition to requirements of all applicable codes, laws, and standards. • Installation, adjustments, putting into service, use, assembly, disassembly, and maintenance are required to be carried out by suitably trained personnel in accordance with applicable code of practice. • In case of malfunction or damage, no attempts at repair should be made. The module should be returned to the manufacturer for repair. Do not dismantle the module. • This equipment is certified for use only within the surrounding air temperature range of -20…+55 °C (-4…+131 °F) (1794-IB8 and 1794-IB16) or 0...55 °C (32…131 °F) (1794-IB32, 1794-IB32K).
