注意：如果使用A系列模块，请勿使用配置选择
全范围位设置为0。单个通道恢复为4…20
位选择为全零的mA。这可能会导致不必要的或不必要的后果
这是一个错误的操作。
出版物1794-UM062B-EN-P-2020年3月
将配置写入模块39并从模块39读取状态
模块的映射数据、读写字和位/字描述描述了信息
写入模拟模块和从模拟模块读取。每个字由16位组成。
有关特定模块的完整数据列表，请参阅53页的数据表。
章节摘要：在本章中，您了解了配置和映射的数据和说明
您的FLEX I/O是高密度模拟模块。
出版物1794-UM062B-EN-P-2020年3月
40向模块写入配置并从模块读取状态
笔记：
41出版物1794-UM062B-EN-P-2020年3月
四章
与您的模块通信
概述：阅读本章以熟悉输入上的可配置功能
和输出模拟模块
关于DeviceNet Manager DeviceNet Manager™ 是用于配置FLEX I/O的软件工具
DeviceNet®适配器及其相关模块。此软件工具可以连接
通过DeviceNet网络连接到适配器。
您必须了解DeviceNetManager的工作原理，才能添加
将设备连接到网络。有关详细信息，请参阅DeviceNetManager软件联机帮助
有关使用DeviceNetManager软件的更多信息。
网络通信
I/O背板
FLEX I/O适配器通过网络与其他网络系统组件通信
网络。适配器通过网络与其I/O模块通信
背板。
模块的I/O映射分为读字和写字。阅读
字由输入和状态字组成，写字由输出和状态字构成
配置字。读字数或写字数可以是0或更多。
每个I/O模块的读字和写字的长度大小不同
取决于模块复杂度。每个I/O模块将支持至少1个输入
字或1个输出字。状态和配置是可选的，具体取决于
单元
例如，一个16点离散输入模块多有2个读字和1个读字
写一个单词。
检查每个模块的I/O映射以获得确映射。
有关详细信息，请参见页
关于DeviceNetManager 41
I/O背板41上的通信
轮询I/O结构42
默认值43
延迟
时间
延迟
时间1123
16点离散输入模块
出版物1794-UM062B-EN-P-2020年3月
42.与您的模块通信
适配器按照已安装I/O模块的顺序接收轮询I/O结构输出数据。
首先接收时隙0的输出数据，然后接收时隙的输出数据
直到槽7。
适配器发送的输入数据的一个字是适配器状态字。这
之后是来自每个插槽的输入数据，按安装的I/O顺序排列
模块。插槽0的输入数据首先位于状态字之后，然后是
从插槽2输入数据，依此类推到插槽7。
适配器输入状态字
输入状态字包括：
•输入/输出模块故障位-每个插槽1个状态位
•节点地址已更改-1位
•I/O状态-1位
适配器状态
插槽0输入数据
插槽1输入数据
插槽7输入数据
插槽0输出数据
插槽1输出数据
插槽7输出数据
读取数据
写入数据
网络阅读
网络写入
FLEX I/O适配器
插槽0
I/O模块读取
写入插槽1
输入/输出模块
插槽7
I/O模块。。。
...
...
...
...
46062
比特：15 10到15 8 7 6 5 4 3 2 1 0
I/O模块故障位
节点地址已更改位
插槽7
插槽6
插槽5
插槽4
插槽3
插槽2
插槽1
插槽0
9
I/O状态位
不用
46063
出版物1794-UM062B-EN-P-2020年3月
与您的模块43通信
适配器输入状态字位描述如表“字位”所示
43页的说明。
I/O模块故障的可能原因有：
•FLEX I/O背板上的传输错误
•出现故障的模块
•从其端子底座上拆下的模块
•插槽位置中插入的模块不正确
•插槽为空
节点地址更改位是在节点地址切换设置已更改时设置的
自通电后已更改。新节点地址直到
适配器已断电，然后重新通电。直到该功率
循环发生时，节点地址开关将与实际节点地址不匹配。
默认值每个I/O模块都有与其关联的默认值。默认情况下，每个模块
生成输入/状态，并期望输出/配置。
字位描述
位描述位解释
I/O模块故障0当在插槽位置0检测到错误时，此位被设置（1）。
1当在时隙位置1中检测到错误时，设置（1）该位。
2当在时隙位置2中检测到错误时，设置（1）该位。
3当在时隙位置3中检测到错误时，设置（1）该位。
4当在时隙位置4中检测到错误时，设置（1）该位。
5当在时隙位置5中检测到错误时，设置（1）该位。
6.当出现错误时，设置（1）该位
