3HAC16381模块备件

3HAC16381

静电敏感器件
标有此符号的设备需要特殊的搬运注意事项，如下所示：
如安装部分所述。
将军
警告
设备环境
所有部件，无论是在运输、操作或储存过程中，都必须：
在非腐蚀性环境中。
维护期间有触电危险
断开电源或采取预防措施，以确保维修时避免与通电部件接触。
具体的
警告
67页：安装在DIN导轨上时，AC 800M控制器和相关装置必须断电并断开！
68页：不允许在有电源的环境中操作CEX总线基板
以及运行系统。在更换或移除基板之前，所有CEX
必须删除该段上的模块。
72页：AC 800M装置必须与电源断开
在将其从DIN导轨上拆下之前！
72页：不允许在有电源的环境中操纵CEX总线基板
以及运行系统。在更换或移除基板之前，所有CEX
必须删除该段上的模块。
78页：对于PM861/PM864/PM865/PM866，将RCU链路端接插头TB852插入RCU链路连接器。必须安装端接插头
在单独运行时，始终用于PM861/PM864/PM865/PM866
配置当冗余处理器在单个配置中运行时，如果RCU链路终端插头
TB852不可用。
3BSE036351-510 A 19
安全摘要（续）
具体的
警告
（续）
124页：CI862基板没有锁定装置。仅插入
将CI862装置装入该底板。插入其他单元类型可能会导致
设备损坏。
191页：在尝试维护或故障排除之前，请阅读
13页的安全总结。不这样做可能导致人身伤害
对设备的伤害或损坏。
198页：不允许在供电和运行系统中操纵CEX总线基板。在更换或拆除底板之前，所有
必须移除该段上的CEX模块。
429页：爆炸危险-更换部件可能会损害
适用于I类2区。
429页：爆炸危险-除非电源断开，否则不要更换电池
已关闭或已知该区域无危险。
430页：爆炸危险-除非：
电源已关闭，或者已知该区域无危险。
具体的
告诫
68页：为防止损坏销，请确保基板插头和
插座在单元互连时完全对齐。在任何情况下都不要过度使用武力！
68页：锁紧装置必须置于锁紧位置
避免振动和/或间歇性故障引起的可能问题的位置
接地。
73页：为了提供足够的通道和拆卸空间，请注意：
必须在与待拆除装置相邻的装置底板上执行滑动顺序。
73页：通过以下方式可轻松将装置底板彼此断开：
用螺丝刀轻轻撬开它们（参见页的图23
74).
20 3BSE036351-510 A
安全总结
具体的
告诫
（续）
76页：不要操纵锁定装置。ABB对操作锁定装置引起的错误不承担任何责任。
-79和92页：不要将内部备用电池放入电池中
保持架，直到AC 800M控制器正常通电，并且
内存备份功能已激活，即B（电池）
LED闪烁。如果没有正常电源连接到处理器单元
电池就位后，CPU内存将立即启动
消耗电池电量。
90页：请注意，在冗余CPU配置中，不能使用COM3和基板上的电气模块总线。
91页：请注意，必须使用且不能使用RCU链路电缆TK851
可以用类似的电缆代替。使用另一根电缆将禁用CB和操作员站中CPU的识别。在单一配置下运行时，RCU链路电缆TK851可临时用于：
执行端接插头的功能。
98页：不要连接两个CEX总线段，用
BC810与CEX总线扩展电缆TK850相互连接。
98页：在AC 800M高完整性控制器中，要求连接BC810的外部电源输入，并关闭电源
根据图33或图34进行严格配置
并且也不允许例如通过改变配置来改变配置
模块之间的单独断路器。
99页：位于主控制器或单个控制器CPU旁边的BC810热插拔，否则称为“直接BC810”，可能会危及整个系统
除非控制器上的每个模块
CEX总线处于非工作状态。注：在AC 800M HI控制器中
这是无条件且有意地导致控制器关闭。
112页：不可能通过热插拔更换CI851单元，因此
不是全部

3HAC16381

3HAC16381

Electrostatic Sensitive Device Devices labeled with this symbol require special handling precautions as described in the installation section. GENERAL WARNINGS Equipment Environment All components, whether in transportation, operation or storage, must be in a noncorrosive environment. Electrical Shock Hazard During Maintenance Disconnect power or take precautions to insure that contact with energized parts is avoided when servicing. SPECIFIC WARNINGS Page 67: The AC 800M Controller and associated units must be unpowered and disconnected when being mounted onto a DIN-rail! Page 68: It is not allowed to manipulate CEX bus baseplates in a powered and running system. Before changing or removing a baseplate, all CEX modules on that segment must be removed. Page 72: AC 800M units must be disconnected from the power source before removing them from a DIN-rail! Page 72: It is not allowed to manipulate CEX bus baseplates in a powered and running system. Before changing or removing a baseplate, all CEX modules on that segment must be removed. Page 78: For PM861/PM864/PM865/PM866 insert the RCU Link Termination plug TB852, at the RCU Link connector. The termination plug must always be used for PM861/PM864/PM865/PM866 when running in single configuration. When a redundant processor is running in a single configuration use the RCU Link Cable TK851, if the RCU Link Termination plug TB852 is not available. 3BSE036351-510 A 19 Safety Summary (continued) SPECIFIC WARNINGS (continued) Page 124: The CI862 baseplate has no locking device. Insert only the CI862 unit into this baseplate. Insertion of other unit types may cause damage to the equipment. Page 191: Before attempting maintenance or troubleshooting, read the Safety Summary on page 13. Failure to do so could lead to personal injury or damage to equipment. Page 198: It is not allowed to manipulate CEX bus baseplates in a powered and running system. Before changing or removing a baseplate, all CEX modules on that segment must be removed. Page 429: Explosion hazard - Substitution of components may impair suitability for Class I, Zone 2. Page 429: Explosion hazard - Do not replace batteries unless the power has been switched off or the area is known to be non-hazardous. Page 430: Explosion hazard - Do not disconnect equipment unless the power has been switched off or the area is known to be non-hazardous. SPECIFIC CAUTIONS Page 68: To prevent damage to the pins, be sure the baseplate plugs and sockets are fully aligned as the units interconnect. Under no circumstances use excessive force! Page 68: It is essential that the locking device be placed in the LOCKED position to avoid possible problems caused by vibration and/or intermittent grounding. Page 73: In order to provide adequate access and removal space, note that the SLIDE sequence must be carried out on the unit baseplates adjacent to the unit that is to be removed. Page 73: The unit baseplates are easily disconnected from each other by gently prying them apart with a blade screwdriver (see Figure 23 on page 74). 20 3BSE036351-510 A Safety Summary SPECIFIC CAUTIONS (continued) Page 76: Do not manipulate the locking device. ABB will take no responsibility for errors caused by manipulating locking devices. -79 and Page 92: Do not place the internal back-up battery in the battery holder until the AC 800M Controller has been powered-up normally and the memory back-up function has been activated, that is, the B(attery) LED flashes. If no normal power supply is connected to the processor unit with the battery in place, then the CPU memory will immediately start to consume battery power. Page 90: Note that in redundant CPU configuration, COM3 and the electrical ModuleBus on the baseplate can not be used. Page 91: Note that the RCU Link Cable TK851 must be used and can not be replaced by a similar cable. Using another cable will disable the identification of the CPUs in the CB and Operator Station. When running in single configuration the RCU Link Cable TK851 might temporarily be used to perform the function of a termination plug. Page 98: Do not connect the two CEX-Bus segments, separated with BC810, to each other with CEX-Bus extension cable TK850. Page 98: In AC 800M High Integrity Controllers it is required that the external supply input of BC810 is connected and that the power supply is strictly configured either according to Figure 33 or according to Figure 34 and nor is it allowed to change the configuration by way of for instance individual circuit breakers between modules. Page 99: Hot swap of the BC810 located next to a primary or single controller CPU, otherwise called “direct BC810”, might jeopardize the whole controller and should not be performed unless every module on the CEX-Bus are in a non-operating state. Note: In an AC 800M HI controller this is unconditionally and intentionally leading to a shutdown of the controller. Page 112: It is not possible to change the CI851 unit via hot swap and it is not allowed
