3IF671模块备件

3IF671

CI856由处理器单元通过CEX总线供电，需要：
因此没有额外的外部电源。
使用以下步骤安装CI856/TP856：
1.将装置安装在DIN导轨上，请参阅将AC 800M装置安装到DIN导轨上
第65页，并在单个处理器中安装PM86x/TP830处理器单元
第78页的配置。
2.将S100 I/O电缆TK575/TK580连接至基板上的触点。A.
必须使用总线扩展器DSBC174/DSBC176/DSBC173A。
S100 I/O连接和安装
将S100 I/O机架电缆TK575/TK580连接到“I/O标签”36引脚
中心线微型带状连接器位于TP856上。
S100 I/O的安装
有关S100 I/O相关组件的安装，请参阅S100 I/O文档。
请注意，CI856单元没有单元冗余。
第2节安装INSUM接口，CI857/TP853
3BSE036351-510 A 121
安装INSUM接口，CI857/TP853
CI857由处理器单元通过CEX总线供电，需要：
因此没有额外的外部电源。
使用以下步骤安装CI857/TP853：
1.将装置安装在DIN导轨上，请参阅将AC 800M装置安装到DIN导轨上
第65页，并在单个处理器中安装PM86x/TP830处理器单元
第78页的配置。
2.将以太网双绞线电缆连接到主机上的COM1连接器
底板（COM2不用于连接INSUM）。
3.通过以下方式将以太网电缆的另一端连接到INSUM设备：
以太网/LON网关。
以太网双绞线连接
以太网双绞线通过位于网络上的10BaseT RJ45连接器连接
TP853.有关连接器的说明，请参见第84页的表5。
请注意，CI857单元没有单元冗余。
安装驱动总线接口，CI858/TP858第2节安装
122 3BSE036351-510 A
安装驱动总线接口，CI858/TP858
CI858由处理器单元通过CEX总线供电，需要：
因此没有额外的外部电源。该装置安装在水平支架上
铁轨上的嘈杂声。
将装置安装到DIN导轨上，请参阅上的“将AC 800M装置安装在DIN导轨上”
第65页，在上以单配置安装PM86x/TP830处理器单元
第78页和第313页的CI858和TP858–驱动总线接口。
光纤接口
CI858板通过三个光接收器/发射器连接到驱动系统
对。HP/Agilent Technologies多功能链路系列（HFBR系列）光纤
使用发射器/接收器。光纤的传输速度为4Mbit/s。
表16.光学连接器
连接器名称和说明
驱动总线TxD传输数据
驱动总线RxD接收数据
I/O总线TxD传输数据
I/O总线RxD接收数据
PC工具TxD传输数据
PC工具RxD接收数据
请注意，CI858单元没有单元冗余。
第2节安装基金会现场总线高速以太网接口，
3BSE036351-510 A 123
安装基金会现场总线高速以太网
接口，CI860/TP860
CI860由处理器单元通过CEX总线供电，需要：
因此没有额外的外部电源。
使用以下步骤安装CI860/TP860：
1.将装置安装在DIN导轨上，请参阅将AC 800M装置安装到DIN导轨上
第65页，并在单个处理器中安装PM86x/TP830处理器单元
第78页的配置。
2.将以太网双绞线电缆连接到主机上的COM连接器
底板。
3.通过标准电缆将以太网电缆的另一端连接到以太网网络
以太网组件。
4.请确保满足基金会现场总线高速以太网要求
网络和网络设备的规范。
以太网双绞线连接
以太网双绞线通过位于TP860上的RJ45连接器连接。
有关连接器的说明，请参见第84页的表5。
安装TRIO现场总线接口CI862第2节安装
124 3BSE036351-510 A
安装TRIO现场总线接口CI862
CI862由处理器单元通过CEX总线供电，不需要任何额外的电源
额外的外部电源。没有现场设备由CI862供电。
使用以下步骤安装CI862：
1.将装置安装到DIN导轨上。
2.将现场总线电缆连接到LAN连接器（右边的连接器）。看见
CI862 TRIO现场总线安装手册指南、电缆类型和
长
手持式监视器（如果使用）连接到HHM接头。
装置至基板阿尔法密码锁
CI862装置和底板因以下原因拆除了锁定装置：
将电子元件放置在装置内。电子设备将不允许使用CI862
装置应安装在带有锁定装置的任何底板中。然而，其他单位
可以插入到CI862基板中。
总线终端
必须将适当的端接电阻器连接到起点和终点
在公共汽车上。表142列出了每种类型电缆的特性阻抗。
如果CI862位于总线的任一端

3IF671

3IF671

The CI856 is powered from the processor unit via the CEX-Bus and requires therefore no additional external power source. Use the following procedure to install the CI856/TP856: 1. Mount the unit on the DIN-rail, see Mounting AC 800M Units onto DIN-Rail on page 65 and Installing the PM86x/TP830 Processor Unit in Single Configuration on page 78. 2. Connect the S100 I/O cable, TK575/TK580, to the contact on the baseplate. A bus extender, DSBC174/DSBC176/DSBC173A, must be used. S100 I/O Connection and Installation Connect the S100 I/O rack cable TK575/TK580 to the “I/O-labeled” 36-pin centerline miniature ribbon connector located on TP856. Installation of S100 I/O For installation of the S100 I/O-related components, see S100 I/O documentation. Note that there is no unit redundancy for the CI856 unit. Section 2 Installation Installing the INSUM Interface, CI857/TP853 3BSE036351-510 A 121 Installing the INSUM Interface, CI857/TP853 The CI857 is powered from the processor unit via the CEX-Bus and requires therefore no additional external power source. Use the following procedure to install the CI857/TP853: 1. Mount the unit onto the DIN-rail, see Mounting AC 800M Units onto DIN-Rail on page 65 and Installing the PM86x/TP830 Processor Unit in Single Configuration on page 78. 2. Connect the Ethernet twisted pair cable to the COM1 connector on the baseplate (COM2 is not used for connection to INSUM). 3. Connect the other end of the Ethernet cable to the INSUM equipment via Ethernet/LON Gateway. Ethernet Twisted Pair Connection The Ethernet twisted pair is connected via the 10BaseT RJ45 connector located on TP853. For a description of the connector see Table 5 on page 84. Note that there is no unit redundancy for the CI857 unit. Installing the DriveBus Interface, CI858/TP858 Section 2 Installation 122 3BSE036351-510 A Installing the DriveBus Interface, CI858/TP858 The CI858 is powered from the processor unit via the CEX bus and requires therefore no additional external power source. The unit is mounted onto a horizontal DIN rail. Mount the unit onto the DIN-rail, see Mounting AC 800M Units onto DIN-Rail on page 65, Installing the PM86x/TP830 Processor Unit in Single Configuration on page 78 and CI858 and TP858 – DriveBus Interface on page 313. Optical Connectors The CI858 board connects to the drive system via three optical receiver/transmitter pairs. HP/Agilent Technologies Versatile Link Series (HFBR family) optical transmitter/receivers are used. Transmission speed of the optical fibres is 4 Mbit/s. Table 16. Optical Connectors Connector Designation Description DriveBus TxD Transmit data DriveBus RxD Receive data I/O Bus TxD Transmit data I/O Bus RxD Receive data PC Tools TxD Transmit data PC Tools RxD Receive data Note that there is no unit redundancy for the CI858 unit. Section 2 Installation Installing the FOUNDATION Fieldbus High Speed Ethernet Interface, 3BSE036351-510 A 123 Installing the FOUNDATION Fieldbus High Speed Ethernet Interface, CI860/TP860 The CI860 is powered from the processor unit via the CEX-Bus and requires therefore no additional external power source. Use the following procedure to install the CI860/TP860: 1. Mount the unit onto the DIN-rail, see Mounting AC 800M Units onto DIN-Rail on page 65 and Installing the PM86x/TP830 Processor Unit in Single Configuration on page 78. 2. Connect the Ethernet twisted pair cable to the COM connector on the baseplate. 3. Connect the other end of the Ethernet cable to Ethernet network via standard Ethernet components. 4. Please make sure to meet the FOUNDATION Fieldbus High Speed Ethernet specification of the network and the network devices. Ethernet Twisted Pair Connection The Ethernet twisted pair is connected via the RJ45 connector located on TP860. For a description of the connector see Table 5 on page 84. Installing the TRIO Fieldbus Interface CI862 Section 2 Installation 124 3BSE036351-510 A Installing the TRIO Fieldbus Interface CI862 The CI862 is powered from the processor unit via the CEX-Bus and requires no additional external power source. No field device is powered from the CI862. Use the following procedure to install the CI862: 1. Mount the unit onto the DIN-rail. 2. Connect the field bus cable to the LAN connector (right most connector). See the CI862 Installation book for TRIO field bus guidelines, cable types and length. The Hand-Held Monitor, if used, is connected to the HHM connector. Unit to Baseplate Alpha Code Lock The CI862 unit and baseplate have the locking device removed because of the placement of the electronics inside the unit. The electronics will not allow the CI862 unit to be installed in any baseplate with a locking device. However, other units could be inserted into the CI862 baseplate. Bus Termination The appropriate terminating resistor must be attached to both the beginning and end of the bus. The characteristic impedance for each type of cable is listed in Table 142. If the CI862 is at either end of the bus, the characteristic resistance is set by a switch on the Field Bus Interface Module, Table 17. If a TRIO module is at the beginning or end of the bus, the bus can be terminated with a resistor or a terminating resistance plug, 6202FP00150 for 150 W
