CI865通过CEX总线由处理器单元供电，不需要任何额外的电源
额外的外部电源。没有现场设备由CI865供电。
使用以下步骤将ControlNet连接到的BNC接头
I/O系统和CI865模块。有关更多信息，请参阅的Satt I/O接口
AC 800M（3BSE042821*）。
BNC连接器位于：
•机架I/O-位于200-RACN模块后部。
•200系列I/O-位于200-ACN模块的前部。
•CI865-位于CI865模块的前部。
1.在距离控制网一米的范围内为分接头选择合适的位置
BNC连接器。选择分接位置时，请记住以下路径：
下降和主干电缆。它们不应靠近高压电缆布线
电缆。避免过度弯曲主干电缆。
2.水龙头可以以各种方式安装，例如使用DIN导轨或
拧入合适的结构中。即使龙头未安装在DIN导轨上，
应使用通用安装支架，以避免电气连接到
导电结构。
3.将分接电缆连接至BNC连接器。在启动系统之前
在系统中，应测试所有ControlNet电缆连接。检查牵引力
应用连接器的强度。
4.定义网络节点地址：
–机架I/O-通过转动200前面板上的两个开关（x10和x1）-
将RACN模块安装到正确的位置。范围02-99的节点地址
应为200个RACN选择。
–200系列I/O-通过单击面板前部的按钮开关
200-ACN模块。应选择02-99范围内的节点地址
对于200个ACN。
–CI865-节点地址固定为01。
第2节安装Modbus TCP接口CI867/TP867
3BSE036351-510 A 127
安装Modbus TCP接口CI867/TP867
CI867通过CEX总线由处理器单元供电，无需额外的电源
需要外部电源。
使用以下步骤安装CI867/TP867：
1.将装置安装到DIN导轨上，请参见第65页“将AC 800M装置安装到DinRail上”和“将PM86x/TP830处理器装置安装在单个导轨上”
第78页的配置。
2.将10/100Mbps以太网双绞线连接到上的CH1连接器
底板。
3.通过以下方式将以太网电缆的另一端连接到快速以太网网络：
标准以太网组件。
4.将10Mbps以太网双绞线连接到主机上的CH2连接器
底板。
5.通过标准电缆将以太网电缆的另一端连接到以太网网络
以太网组件。
以太网双绞线连接
快速10/100 Mbps以太网双绞线通过RJ45连接器连接
（CH1）位于TP867上。速度较慢的10 Mbps以太网双绞线通过
RJ45连接器（CH2）位于TP867上。
有关连接器的说明，请参见第84页的表5。
安装IEC 61850接口CI868第2节安装
128 3BSE036351-510 A
安装IEC 61850接口CI868
CI868由处理器单元通过CEX总线供电，无需额外的电源
需要外部电源。
要安装CI868：
1.将装置安装到DIN导轨上，参见第65页将AC 800M装置安装到DinRail上。
2.将100Mbps以太网双绞线连接到主机上的CH1连接器
底板。
3.通过以下方式将以太网电缆的另一端连接到快速以太网网络：
标准以太网组件。请参阅PTUST04-3211-交换机管理
适用于IEC 61850，适用于经IEC 61850认证的开关。
安装AF 100接口CI869
CI869单元由处理器单元通过CEX总线供电，无需任何电源
需要额外的外部电源。
要安装CI869：
1.将CI869装置安装到DIN导轨上。请参见将AC 800M装置安装到
第65页的DIN导轨。
2.将AF 100双绞线连接到CI869的4针触点。
如果是冗余介质，请将另一对AF 100双绞线连接到另一对
4针触点。
3.将双绞线的另一端连接到AF 100总线。
有关AF 100连接的详细信息，请参阅Advant Fieldbus 100用户手册
（3BSE000506*）。
