完整的电源输入电源隔离。
d、 微型电源断路器单元（4）。
e、 保护接地配电端子（5）。
f、 主配电接线板（6）
配置
g、 DIN导轨端部止挡（1）。
2.连接输入电源、保护接地端子和电源
断路器和配电端子，如135页图42所示。
3.将所需的两个链节（7）、保险丝座（8）和跨接导线（9）安装到电缆上
配电终端。将所需的保险丝装入保险丝座（玻璃
管型，5 x 20毫米（0.2 x 0.8英寸））。
保护接地端子（2）装有刀状装置，以提供：
自动接地至DIN导轨。
2节：安装电源断路器装置
3BSE036351-510 A 135
如果出现以下情况，拆下保险丝座或跨接接头可提供视觉指示：
电源已断开。保险丝座具有内置的红色LED，用于：
表示保险丝断裂（有缺陷）。
图42.电源断路器组件的安装
干线
掌权
1.
2.
3.
4.
5.
6.
7.
8.
9
1.
PE–绿色/黄色
PE–绿色/黄色
PE–绿色/黄色
PE–绿色/黄色
供应
现场设备
掌权
供应
单位PE=保护接地
安装SS823/SS832表决单元2节安装
136 3BSE036351-510 A
安装SS823/SS832表决单元
SS8xx表决单元用于将两个冗余电源连接到
普通负载。根据系统配置要求
冗余电源可以连接到完全独立的主电源
或者连接到相同的主电源，如SS823137页图43所示，
SS832的138页图44和139页图45。
使用以下步骤安装投票单元SS8xx：
1.将表决单元SS8xx安装在DIN导轨上，靠近电源。
2.根据需要，将表决装置连接到选定的SD83x电源装置
配置有关详细信息，请参见138页的图44和139页的图45
SS832。
2节安装SS823/SS832表决器
3BSE036351-510 A 137
图43.SS823的冗余电源
安装SS823/SS832表决单元2节安装
138 3BSE036351-510 A
图44.10 A以下的SS832冗余配置
2节安装SS823/SS832表决器
3BSE036351-510 A 139
3.将SS82x投票单元连接到处理器单元。140页图46
显示冗余配置下与PM861/PM864/PM865的连接。
图45.20 A以下的SS832冗余配置
安装SS823/SS832表决单元2节安装
140 3BSE036351-510 A
图46为冗余CPU供电的冗余电源
从干线
断路器
保护地
2节安装SS823/SS832表决器
3BSE036351-510 A 141
供电监督
冗余配置中的电源状态可以通过
SS8xx表决单元。来自SS8xx的监控信号SA和SB为：
连接到CPU的相应端子。
+SA/SB上的24 V表示工作电源。SA/SB上的0 V表示出现故障
相应的电源错误和缺乏冗余。SA/SB信号
连接如140页的图46、141页的图47和图48所示
142页。
140页的图46显示了为AC 800M装置供电的冗余电源。
这里SA/SB信号还指示物理电源。
142页的图48显示了为AC 800M供电的一个冗余电源
一个用于为现场设备供电。不能显示SA/SB错误指示
指示发生故障的物理电源，仅表明存在故障。
图47.使用单电源连接SA/SB
为避免使用单个电源时SA/SB出现错误指示，应：
建议将CPU上的输入端子SA/SB连接到+24V，
请参见图47。
+24伏
0伏
安装SS823/SS832表决单元2节安装
142 3BSE036351-510 A
图48.冗余电源供电装置和现场设备
好的，好的
A+B+L+
SS822
++F
A和B
L+L-
L+L+L–L-
N L PE
好啊
SD821
L+L+L–L-
N L PE
好啊
SD821
好的，好的
A+B+L+
SS822
++F
A和B
L+L-
L+L+L–L-
N L PE
好啊
SD821
L+L+L–L-
N L PE
好啊
SD821
沙特阿拉伯
某人
L-
L+
监督
向
CPU单元通过TP830
+24伏
0伏
从干线
断路器
保护地
L-
L++24V
保护接地0 V
供电
领域
设备
供电
单位
从干线
断路器
2节安装SB821外部电池单元
3BSE036351-510 A 143
安装SB821外部电池单元
使用以下步骤连接外部电池单元：
1.将SB821外部电池单元安装在DIN导轨上的适当位置。
2.要连接SB821外部电池单元，请使用2m（2.2码）电缆
TK821V020。将一端插入电池单元，另一端插入外部电源
PM8xx处理器单元的电池电源插座（参见32页的图2）。
3.在包含两个PM861/PM的冗余CPU配置中
