I/O；Tx1 LED亮起（未亮起
闪光）
该单元不传输数据。
•检查断路器是否有故障信息。
•如果CB中没有故障信息
更换CI858单元。
I/O；Tx1 LED熄灭、装置配置不正确或装置错误。
•检查断路器是否有故障信息。
•如果没有故障信息，则更换
CI858单元。
CI858支持热插拔。
表38.驱动总线CI858–故障查找（续）
故障、可能原因和纠正措施
第5节维护基金会现场总线高速以太网-CI860
3BSE036351-510 A 221
基金会现场总线高速以太网-CI860
表39.基金会现场总线高速以太网CI860——故障查找
故障、可能原因和纠正措施
无论是R（un）还是F（ault）LED
是吗
CI860板正在安装中
重新启动或配置。留出时间，以便：
后确定。
如果该情况持续存在，并且没有其他单元指示灯亮起
CEX总线点亮：
•检查有效的硬件配置，包括：
CI860被下载到控制器。
•检查日志文件
•检查CPU单元内的CEX总线保险丝。
•从CPU启动复位信号（INIT）
单元
•更换CI860装置。
F（故障）指示灯亮起。检查所有电缆和接头是否损坏和损坏
连接松动或不良。
必要时进行维修。
R（un）指示灯闪烁。检查相关装置是否正在发送数据。
检查CI860板是否正在运行
正在重新启动或配置。如果是这样，请留出时间
这项工作有待完成。
如果该情况持续存在：
•停止应用程序并启动
重新启动。
•检查日志文件
•更换CI860板。
如果RxTx LED闪烁，则100Mbit/s点亮：
建立了100Mbit/s的有效连接。
基金会现场总线高速以太网-CI860第5节维护
222 3BSE036351-510 A
如果RxTx LED闪烁，则100Mbit/s关闭：
建立了10 MBit/s的有效连接。
RxTx LED位于与相应以太网设备的链路上
建立。不支持以太网包
发送/接收。
RxTx指示灯闪烁。连接到相应以太网设备的链接为：
建立。发送/接收以太网包
RxTx指示灯熄灭。与相应以太网单元的链路未熄灭
确立
•检查日志文件
•检查连接到以太网的以太网电缆
对应的以太网设备。
•检查相应的以太网设备。
•检查CI860装置。
PRIM黄色LED指示灯，用于指示主设备处于工作状态
冗余配置。
双：黄色LED指示灯表示冗余
配置
CI860支持热插拔。
表39.基金会现场总线高速以太网CI860——故障查找
（续）
故障、可能原因和纠正措施
第5节维护三重接口-CI862
3BSE036351-510 A 223
三重接口-CI862
表40.三重接口CI862-故障查找
指示、可能原因和纠正措施
既不是R（联合国）也不是
F（故障）指示灯亮起
CI862正在重新启动，或
配置。留出时间完成这项工作。
如果该情况持续存在，并且CEXbus上的所有其他单元都有不亮的LED：
•检查有效的硬件配置，包括：
将CI862下载到控制器。
•检查PM8xx内的CEX总线保险丝
处理器单元。
•从PM8xx启动复位信号（INIT）
处理器单元。
•更换CI862。
F（故障）指示灯亮起。检查CI862是否正在启动
重新启动。留出时间完成这项工作。
检查是否没有从中报告任何配置故障
CBM中的CI862。如果状态保持不变，则启动复位信号
（初始化）从PM8xx处理器单元。如果状态仍然是
复位后保持不变。更换CI862。
通信错误指示灯亮起
这句话的意思是：
µGenie从站的现场总线通信错误
单元
主发光二极管熄灭。CI862正在重新启动，或
配置。留出时间完成这项工作。
检查是否没有从中报告任何配置故障
CBM中的CI862。
双LED熄灭或点亮
两个都是CI862
CI862正在重新启动，或
配置。留出时间完成这项工作。
检查此模块的冗余是否设置在以下范围内：
CBM，并下载配置。
