未使用CI869模块中的桅杆LED。表44列出了其他指示。
表44.AF 100接口，CI869-指示和故障查找
指示、可能原因和纠正措施（针对故障）
R（un）和F（ault）
LED灯熄灭
可能原因1：CI869模块已连接
但配置不是
下载到该位置的控制器。
纠正措施1：确保CI869模块
在硬件树（在控件中）中配置
建筑商），并且该配置为：
下载到控制器。
可能原因2：CI869模块刚刚损坏
已通电或正在配置，并且
下载。
纠正措施2：让模块有时间：
初始化。
纠正措施3：如果故障后指示仍然存在
执行校正动作1和2
建议采取以下纠正措施：
•卸下CI869模块并将其插入到
CEX总线，并为其初始化留出时间。
•如果此CI869是系统上的模块
或者如果CEX总线已经包含
其他通信模块和所有LED
打开时，如果这些模块关闭，则其中一个
建议采取以下纠正措施：
-从PM8xx启动复位信号（INIT）
处理器单元。
-检查PM8xx内的CEX总线保险丝
处理器单元
纠正措施4：如果指示仍然存在
执行纠正措施1至3后，更换
CI869模块。
第5节维护AF 100接口-CI869
3BSE036351-510 A 229
F（故障）指示灯亮起可能原因1：CI869模块位于
升级固件的过程（如果升级成功
正在进行中）。
纠正措施1：等待固件安装完成
升级。
可能原因2：CI869模块中存在故障。
纠正措施2：热移除并热插入
CI869模块。
纠正措施3：如果故障后指示仍然存在
执行校正动作1和2
更换CI869模块。
Rx LED亮起（无
闪光）
CI869模块运行正常，正在接收信号
以及传输数据。
Rx指示灯闪烁，带有：
较少频率
可能原因1：双绞线对（TWP）损坏
未连接或未正确连接到
4针触点。
纠正措施1：检查TWP连接。
Rx指示灯闪烁，带有：
频率比
当TWP不存在时
有联系的
可能原因1：配置不正确
从硬件树（在控件中）下载
生成器）发送到控制器。
纠正措施1：确保CI869模块
在硬件树中为正确的
并将配置下载到
控制器。
Rx指示灯闪烁，带有：
频率比
当TWP不存在时
有联系的
可能原因：至少一个已配置的
DSP在轮询时不响应。
纠正措施：正确配置DSP。
表44.AF 100接口，CI869-指示和故障查找
指示、可能原因和纠正措施（针对故障）
AF 100接口-CI869第5节维护
230 3BSE036351-510 A
CI869模块在冗余配置下运行时，双LED亮起。
当CI869模块在冗余配置下运行时，主（ary）LED亮起，
并且它用作主模块。
注：即使备用CI869模块在以下情况下运行：
冗余配置中的错误或故障，Prim
中的主CI869模块中的LED仍亮起
冗余配置。
如果纠正措施是更换有故障的CI869模块，请将其更换为：
另一个具有相同硬件和固件版本的CI869模块。
CI869支持热插拔。
表44.AF 100接口，CI869-指示和故障查找
指示、可能原因和纠正措施（针对故障）
第5节PROFINET IO接口的维护-CI871
3BSE036351-510 A 231
PROFINET IO接口-CI871
表45.PROFINET IO接口，CI871-指示和故障查找
故障、可能原因和纠正措施
R（un）和F（ault）指示灯均不亮
这句话的意思是：
CI871装置正在进行以下操作：
配置如果该状况持续存在
CEX总线上没有其他单元LED点亮：
•检查是否安装了有效的硬件
包括CI871的配置是：
下载到控制器。
•检查电源内的CEX总线保险丝
PM8xx处理器单元。
•从控制器启动复位信号（INIT）
PM8xx处理器单元。
•更换CI871装置。
CI871装置上的F（ault）指示灯亮起，正在进行校准
重新启动。等待重新启动操作完成
完成
如果出现故障，更换装置

6087-H126

6087-H126

RxTx1/RxTx2 LED is OFF Reception and transmission of I/O data does not occur at the respective Ethernet channels. RxTx1/RxTx2 LED is flashing Reception and transmission of I/O data occurs normally at the respective Ethernet channels. PRIM is OFF The CI871 is not started by the application. PRIM is ON The CI871 is started by the application. DUAL is OFF Default, as no redundancy is supported with PROFINET IO. CI871 supports hot swap. MOD5 Interface - CI872 Section 5 Maintenance 232 3BSE036351-510 A MOD5 Interface - CI872 Table 46 provides the indications and possible causes, and the corrective actions for the faults, appearing in the MOD5 communication interface, type - CI872. Table 46. MOD5 Communication Interface, Type CI872 - Indications and Fault Finding Indication Possible Causes, and Corrective Actions (for faults) Both R(un) and F(ault) LED's are OFF Possible Cause 1: The CI872 module is connected to the controller and the configuration is not downloaded to the controller for that position. Corrective Action 1: Ensure that the CI872 module is configured in the Hardware Tree (in the Control Builder) for that position, and that the configuration is downloaded to controller. Possible Cause 2: The CI872 module is just powered up or it is being configured and downloaded. Corrective Action 2: Allow time for the module to initialize. Corrective Action 3: If the indication persists after performing the corrective actions 1 and 2, then one of the following corrective actions is recommended: • Remove and insert the CI872 module to the CEX-Bus and allow time for it to initialize. • If the CEX-Bus already contains other communication modules and all the LED's on those modules are OFF, or if this CI872 is the only module on the CEX-Bus, then check the CEX-Bus fuse inside the PM86x Processor Unit. Corrective Action 4: If the indication still persists after performing the corrective actions 1 to 3, replace the CI872 module. Section 5 Maintenance MOD5 Interface - CI872 3BSE036351-510 A 233 F(ault) LED is ON Possible Cause 1: The CI872 module is in the process of upgrading the firmware (if the upgrade is in progress). Corrective Action 1: Wait for the firmware to be upgraded. Possible Cause 2: Fault in the CI872 module. Corrective Action 2: Hot remove and hot insert the CI872 module. Corrective Action 3: If the indication persists after performing the corrective actions 1 and 2, then replace the CI872 module. R(un) LED is ON The green R(un) LED indicates that CI872 is operational. Rx/Tx1, Rx/Tx2, and Rx/Tx3 LEDs are flashing There is one LED corresponding to each port on the CI872 module. When the LED corresponding to a port flashes, it indicates that communication is happening on that particular port. Rx/Tx1, Rx/Tx2, Rx/Tx3 LED is OFF Possible Cause 1: The fiber optic cable is not connected or it is not connected properly to the port. Corrective action 1: Do any of the following: • Check the corresponding optical cable connections, that is, the connections for reversed transmitter and receiver optical cables for that particular port, and the connections on the DOW MOD5 controller. • Check the Network Controller Board (NCB) on the MOD5 Controller connected to that particular port. Possible Cause 2: The configuration is not downloaded from the Hardware Tree (in the Control Builder) to the controller. Corrective Action 2: Ensure that the module is configured in the Hardware Tree for the correct position and the configuration is downloaded to controller. Table 46. MOD5 Communication Interface, Type CI872 - Indications and Fault Finding (Continued) Indication Possible Causes, and Corrective Actions (for faults) MOD5 Interface - CI872 Section 5 Maintenance 234 3BSE036351-510 A DUAL LED is ON The yellow DUAL LED is illuminated when the CI872 module is run in redundant configuration. The module that has the DUAL LED illuminated is the primary [active] module in a redundant configuration. Note: Even if the backup CI872 module runs with errors or fails in redundant configuration, the DUAL LED is still ON in primary CI872 module in redundant configuration. DUAL LED is OFF The yellow DUAL LED is OFF when any of the following conditions are met: • CI872 is run in single configuration. • CI872 is run in redundant configuration, but it acts as a backup module. All LED's are OFF Possible Cause 1: Difference in the CI872 position in the Hardware Tree (in the Control Builder) as compared to the CI872 position on the CEX-Bus. Corrective Action 1: Check and correct the position of CI872 module in the Hardware Tree in accordance with the position on CEX-Bus, or vice-versa. Possible Cause 2: The CI872 module is hot inserted and the configuration is not downloaded to the controller. Corrective Action 2: Ensure that the module is configured in the Hardware Tree (in the Control Builder) for that position, and that the configuration is downloaded to controller. Possible Cause 3: The CI872 is just hot inserted and it is in the process of configuration. Corrective Action 3: Allow time for the module to initialize. Table 46. MOD5 Communication Interface, Type CI872 - Indications and Fault Finding (Continued) Indication Possible Causes, and Corrective Actions (for faults) Section 5 Maintenance MOD5 Interface - CI872 3BSE036351-510 A 235 Rx/Tx LED's are flashing, but there is no communication Possible Cause 1: MTMConnect and/or MTMReadCyc and/or MTMDefCyc are disabled. Corrective Action 1: Enable MTMConnect, MTMReadCyc, and MTMDefCyc function blocks. Possible Cause 2: MTMConnect and/or MTMReadCyc and/or MTMDefCyc function blocks show a bad status. Corrective Action 2: Check the reason for the bad status (see the status codes for MTMCommLib in the Online Help), and take the appropriate corrective action for the bad status. Possible Cause 3: The value for the Channel parameter in the MTMConnect function block is not in accordance with the position of the CI872 module in the Hardware Tree. Corrective Action 3: Ensure that the value of the Channel parameter in the function blo
