未使用CI869模块中的桅杆LED。表44列出了其他指示。
表44.AF 100接口，CI869-指示和故障查找
指示、可能原因和纠正措施（针对故障）
R（un）和F（ault）
LED灯熄灭
可能原因1：CI869模块已连接
但配置不是
下载到该位置的控制器。
纠正措施1：确保CI869模块
在硬件树（在控件中）中配置
建筑商），并且该配置为：
下载到控制器。
可能原因2：CI869模块刚刚损坏
已通电或正在配置，并且
下载。
纠正措施2：让模块有时间：
初始化。
纠正措施3：如果故障后指示仍然存在
执行校正动作1和2
建议采取以下纠正措施：
•卸下CI869模块并将其插入到
CEX总线，并为其初始化留出时间。
•如果此CI869是系统上的模块
或者如果CEX总线已经包含
其他通信模块和所有LED
打开时，如果这些模块关闭，则其中一个
建议采取以下纠正措施：
-从PM8xx启动复位信号（INIT）
处理器单元。
-检查PM8xx内的CEX总线保险丝
处理器单元
纠正措施4：如果指示仍然存在
执行纠正措施1至3后，更换
CI869模块。
第5节维护AF 100接口-CI869
3BSE036351-510 A 229
F（故障）指示灯亮起可能原因1：CI869模块位于
升级固件的过程（如果升级成功
正在进行中）。
纠正措施1：等待固件安装完成
升级。
可能原因2：CI869模块中存在故障。
纠正措施2：热移除并热插入
CI869模块。
纠正措施3：如果故障后指示仍然存在
执行校正动作1和2
更换CI869模块。
Rx LED亮起（无
闪光）
CI869模块运行正常，正在接收信号
以及传输数据。
Rx指示灯闪烁，带有：
较少频率
可能原因1：双绞线对（TWP）损坏
未连接或未正确连接到
4针触点。
纠正措施1：检查TWP连接。
Rx指示灯闪烁，带有：
频率比
当TWP不存在时
有联系的
可能原因1：配置不正确
从硬件树（在控件中）下载
生成器）发送到控制器。
纠正措施1：确保CI869模块
在硬件树中为正确的
并将配置下载到
控制器。
Rx指示灯闪烁，带有：
频率比
当TWP不存在时
有联系的
可能原因：至少一个已配置的
DSP在轮询时不响应。
纠正措施：正确配置DSP。
表44.AF 100接口，CI869-指示和故障查找
指示、可能原因和纠正措施（针对故障）
AF 100接口-CI869第5节维护
230 3BSE036351-510 A
CI869模块在冗余配置下运行时，双LED亮起。
当CI869模块在冗余配置下运行时，主（ary）LED亮起，
并且它用作主模块。
注：即使备用CI869模块在以下情况下运行：
冗余配置中的错误或故障，Prim
中的主CI869模块中的LED仍亮起
冗余配置。
如果纠正措施是更换有故障的CI869模块，请将其更换为：
另一个具有相同硬件和固件版本的CI869模块。
CI869支持热插拔。
表44.AF 100接口，CI869-指示和故障查找
指示、可能原因和纠正措施（针对故障）
第5节PROFINET IO接口的维护-CI871
3BSE036351-510 A 231
PROFINET IO接口-CI871
表45.PROFINET IO接口，CI871-指示和故障查找
故障、可能原因和纠正措施
R（un）和F（ault）指示灯均不亮
这句话的意思是：
CI871装置正在进行以下操作：
配置如果该状况持续存在
CEX总线上没有其他单元LED点亮：
•检查是否安装了有效的硬件
包括CI871的配置是：
下载到控制器。
•检查电源内的CEX总线保险丝
PM8xx处理器单元。
•从控制器启动复位信号（INIT）
PM8xx处理器单元。
•更换CI871装置。
CI871装置上的F（ault）指示灯亮起，正在进行校准
重新启动。等待重新启动操作完成
完成
如果出现故障，更换装置

6111-H015

6111-H015
The Mast LED in the CI869 module is not used. Table 44 lists the other indications.
Table 44. AF 100 Interface, CI869 - Indications and Fault Finding
Indication Possible Cause and Corrective Action (for faults)
Both R(un) and F(ault)
LED's are OFF
Possible Cause 1: The CI869 module is connected
to the controller, but the configuration is not
downloaded to the controller for that position.
Corrective Action 1: Ensure that the CI869 module
is configured in the Hardware Tree (in the Control
Builder) for that position, and that the configuration is
downloaded to controller.
Possible Cause 2: The CI869 module is just
powered up or it is being configured and
downloaded.
Corrective Action 2: Allow time for the module to
initialize.
Corrective Action 3: If the indication persists after
performing the corrective actions 1 and 2, then one
of the following corrective actions is recommended:
• Remove and insert the CI869 module to the
CEX-Bus and allow time for it to initialize.
• If this CI869 is the only module on the
CEX-Bus, or if the CEX-Bus already contains
other communication modules and all the LED's
on those modules are OFF, then one of the
following corrective actions is recommended:
- Initiate a reset signal (INIT) from the PM8xx
processor unit.
- Check the CEX-Bus fuse inside the PM8xx
processor Unit
Corrective Action 4: If the indication still persists
after performing the corrective actions 1 to 3, replace
the CI869 module.
Section 5 Maintenance AF 100 Interface - CI869
3BSE036351-510 A 229
F(ault) LED is ON Possible Cause 1: The CI869 module is in the
process of upgrading the firmware (if the upgrade is
in progress).
Corrective Action 1: Wait for the firmware to be
upgraded.
Possible Cause 2: Fault in the CI869 module.
Corrective Action 2: Hot remove and hot insert the
CI869 module.
Corrective Action 3: If the indication persists after
performing the corrective actions 1 and 2, then
replace the CI869 module.
Rx LED is ON (without
flashing)
The CI869 module is operational, and it is receiving
and transmitting data.
Rx LED is flashing with
less frequency
Possible Cause 1: The twisted wire pair (TWP) is
not connected or it is not connected properly to the
4-pin contact.
Corrective action 1: Check the TWP connections.
Rx LED is flashing with
50% more frequency than
when the TWP is not
connected
Possible Cause 1: The configuration is not
downloaded from the Hardware Tree (in the Control
Builder) to the controller.
Corrective Action 1: Ensure that the CI869 module
is configured in the Hardware Tree for the correct
position and the configuration is downloaded to
controller.
Rx LED is flashing with
75% more frequency than
when the TWP is not
connected
Possible Cause: At least one of the configured
DSPs does not respond when polled.
Corrective Action: Configure the DSPs correctly.
Table 44. AF 100 Interface, CI869 - Indications and Fault Finding
Indication Possible Cause and Corrective Action (for faults)
AF 100 Interface - CI869 Section 5 Maintenance
230 3BSE036351-510 A
Dual LED is ON The CI869 module is run in redundant configuration.
Prim(ary) LED is ON The CI869 module is run in redundant configuration,
and it functions as the primary module.
Note: Even if the backup CI869 module runs with
errors or fails in redundant configuration, the Prim
LED is still ON in the primary CI869 module in
redundant configuration.
If the corrective action is to replace the faulty CI869 module, replace it with
another CI869 module which has the same version of hardware and firmware.
 CI869 supports hot swap.
Table 44. AF 100 Interface, CI869 - Indications and Fault Finding
Indication Possible Cause and Corrective Action (for faults)
Section 5 Maintenance PROFINET IO Interface - CI871
3BSE036351-510 A 231
PROFINET IO Interface - CI871
Table 45. PROFINET IO Interface, CI871 - Indications and Fault Finding
Fault Possible Cause and Corrective Action
Neither R(un) nor F(ault) LEDs are
ON
The CI871 unit is in the process of
configuration. If the condition persist, and
no other unit LED on the CEX-Bus is ON:
• Check that a valid hardware
configuration including the CI871 is
downloaded to the controller.
• Check the CEX-Bus fuse inside the
PM8xx processor unit.
• Initiate a reset signal (INIT) from the
PM8xx processor unit.
• Replace the CI871 unit.
F(ault) LED is ON The CI871 unit is in the process of being
restarted. Wait until the restart operation is
complete.
Replace unit if the cond
