纠正措施4：如果该情况在以下情况下仍然存在：
执行纠正措施1至3，然后热移除和
将CI872模块热插入CEX总线，并留出时间
以便模块初始化。
如果纠正措施是更换有故障的CI872模块，请将其更换为：
另一个具有相同硬件和固件版本的CI872模块。
CI872支持热插拔。
表46.CI872型MOD5通信接口-指示和故障查找（续）
指示可能的原因和纠正措施（针对故障）
以太网/IP接口-CI873第5节维护
236 3BSE036351-510 A
以太网/IP接口-CI873
表47.以太网/IP通信接口CI873-指示和故障
发现
故障、可能原因和纠正措施
行动
CI873装置上的R（un）和F（ault）指示灯均未亮起。正在安装
配置。等待配置完成
完成。如果该状况持续存在
没有显示CEX总线上的其他单元LED
关于：
•检查电源内的CEX总线保险丝
PM8xx处理器单元。
•从以下位置启动复位信号（INIT）：
PM8xx处理器单元。
•更换CI873装置。
CI873装置上的F（ault）指示灯亮起，正在进行校准
重新启动。等待重新启动操作
完成。
如果故障依然存在，请更换单元。
RxTx1/RxTx2（1）指示灯熄灭，没有接收或发送活动
相应的以太网信道。
RxTx1/RxTx2（1）指示灯闪烁，接收或发送活动如下：
各个以太网信道正常。
第5节维护以太网/IP接口-CI873
3BSE036351-510 A 237
CI873模块在冗余模式下运行时，双LED亮起
配置
基本（ary）指示灯亮起。CI873模块在冗余模式下运行
并且它用作
主要模块。
注：即使备份CI873模块
在冗余模式下运行时出错或失败
在配置中，Prim LED仍亮起
主CI873模块处于冗余状态
配置
（1） 可通过禁用CH2通道关闭LED。
CI873支持热插拔。
表47.以太网/IP通信接口CI873-指示和故障
发现
故障、可能原因和纠正措施
行动
以太网/IP接口-CI873第5节维护
238 3BSE036351-510 A
3BSE036351-510 A 239
附录A硬件单元
PM851/PM856/PM860和TP830–处理器单元
主要特征
•在48 MHz下运行的MPC860微处理器。
•带内部或外部电池的8 MB RAM
备用设施。
•12个S800输入/输出装置可连接至
电气模块总线。
•四个车载通信端口：
–CN1+CN2，以太网端口
（IEEE 802.3，10BaseT）
–COM3，带调制解调器的串行端口（RS-232C）
支持
–COM4，用于服务的串行端口（RS-232C）
工具
•基本通信可通过以下方式扩展：
附加通信接口单元。
本节不适用于System 800xA 5.1的功能包版本。
参见第245页的PM851A/PM856A/PM860A和TP830–处理器单元。
PM851的数据与PM856的数据相同，只是不支持CN2。
PM856的数据与PM860的数据相同，只是性能不同
应用程序执行，见第244页的性能数据。
技术数据附录A硬件单元
240 3BSE036351-510 A
•紧凑型闪存接口，支持应用程序加载和冷保存
数据存储。
技术数据
PM851/PM856/PM860和TP830的技术数据如表48所示
第240页。
表48.PM851/PM856/PM860和TP830——技术数据
项目价值
内存•2 MB闪存PROM（固件存储）。
•8 MB的SDRAM。
典型功耗为5 W
典型10 W（包括ModuleBus和CEXBus的全电源，见附录B，功耗）。
典型电流消耗为180 mA（大300 mA）
（不包括模块总线和CEX总线的供应，见附录
B、 功耗）。
电源输入接头四针螺纹接头L+、L-、SA和SB。
电源
要求
指定为L+和L–24 V标称输入，变化
在19.2V DC和30V DC之间。
冗余功率
供应状态输入
输入指定为SA、SB
•大输入电压30 V
•高电平15 V的小输入电压
•低电平8 V的大输入电压
这些输入是状态输入。阈值水平为：
逻辑“0”或“1”输入限制，而不是电源故障限制。
电源储液器处理器单元具有内部5ms电源储液罐，
足以使CPU进行受控断电。
根据EN6052，防护等级为IP20
