8CH23154模块备件

8CH23154

ACS-AP-X辅助控制面板。级操作员键盘，用于：
与驱动器通信。
制动斩波器将来自驱动器中间电路的剩余能量传导至
必要时，可使用制动电阻器。当直流电压下降时，斩波器工作
链路电压超过某个大限制。电压上升是
通常由惯量电机的减速（制动）引起。
制动电阻器耗散由制动器传导的驱动剩余制动能量
切碎机加热。制动回路的重要部分。参见制动器
斩波器。
电容器组是指直流链路电容器。
控制板控制程序运行的电路板。
BAPO-01可选侧装辅助电源扩展模块
BCAN-11可选CANopen接口
BCBL-01可选USB至RJ45电缆
BREL-01可选侧装继电器输出扩展模块
BTAC-02可选侧装脉冲编码器接口模块
CCA-01可选冷配置适配器
直流链路整流器和逆变器之间的直流电路
直流链路电容器储能，稳定中间电路直流电压
用于控制交流电机的驱动变频器
嵌入式现场总线
电磁兼容
FBA现场总线适配器
FCAN-01/-01-M可选CANopen适配器模块
FCNA-01可选ControlNet适配器模块
FDNA-01可选DeviceNet适配器模块
FECA-01/-01-M可选EtherCAT适配器模块
FENA-11/-21/
-21米
可选以太网适配器模块，用于以太网/IP、Modbus TCP和
PROFINET IO协议
FEPL-02可选以太网POWERLINK适配器模块
FPBA-01/-01-M可选PROFIBUS DP适配器模块
帧（大小）是指驱动器的物理大小，例如R0和R1。类型
附在驱动器上的指定标签显示了驱动器的框架，
参见35页的类型指定键。
I/O输入/输出
IGBT绝缘栅双极晶体管
中间电路是指直流链路。
逆变器将直流和电压转换为交流和电压。
LRFI系列可选EMC滤波器
手册简介25
小有效字
驱动控制程序中参数的宏预定义默认值。每个
宏用于特定的应用程序。
NETA-21可选远程监控工具
基于通用工业协议的现场总线协议网络控制
（CIPTM），如DeviceNet和Ethernet/IP，表示对网络的控制
使用ODVA AC/DC驱动器的Net-Ctrl和Net-Ref对象驱动
轮廓有关更多信息，请参阅www.odva。org和以下内容
手册：
•FDNA-01设备网适配器模块用户手册（3AFE68573360
[英文]）
•FENA-01/-11/-21以太网适配器模块用户手册
（3UA000093568[英文]）
驱动器的参数用户可调操作说明，或测量的信号或
由驱动器计算
可编程逻辑控制器
PROFIBUS，
PROFIBUS DP，
PROFINET IO
PI的注册商标-PROFIBUS和PROFINET国际
R0，R1，…帧（大小）
剩余电流装置
整流器将交流电和电压转换为直流电和电压。
射频干扰
SIL安全完整性等级。参见121页的“安全扭矩关闭功能”。
STO安全扭矩关闭。请参阅121页的安全扭矩关闭功能。
术语/缩写说明
26.手册简介
硬件描述27
3.
硬件描述
本章内容
本章介绍了操作原理、布局、型号名称、标签和类型
指定信息。它显示了电源连接的一般图，以及
控制接口。
一般说明
ACS380是一种用于控制异步交流感应电机的久驱动器
磁同步电机和ABB同步磁阻电机（SynRM
电机）。它针对机柜安装进行了优化。
产品变体
该驱动器有三种主要产品变体：
•带有扩展I/O和Modbus模块的标准变型（ACS380-04xS）
•配置的变型（ACS380-04xC），其扩展模块，如
订购时选择预配置的现场总线适配器。
•基本变型（ACS380-04xN），不带预装扩展模块
参见35页的类型指定键。
28硬件说明
硬件概述
项目描述项目描述
1个前部选件模块（I/O和
Modbus或现场总线模块
取决于变型）
9压敏电阻接地螺钉
10 PE连接（电机）
11控制面板、显示器和状态LED
2个输入电源连接端子12个固定控制端子
3.电机和制动电阻连接
航空站
13通信模块的选件插槽1
（I/O或现场总线模块）
4冷却风扇14冷配置连接
CCA-01 5面板和PC工具端口（RJ45）
6.型号信息标签15：侧面安装选件的选件插槽2
7 EMC滤波器接地螺钉16前盖
8类型名称标签
1.
2.
3.
4.
5.
6.
7.
9
11
12
13
15
16
10
8 14
硬件描述29
控制连接
除了基本单元中的固定控制连接之外
连接取决于dri
