The BAPO-01 auxiliary power extension module (option +L534) enables the use of
an external auxiliary power supply with the drive. You need an external auxiliary
power supply to keep the drive on during a power outage. Connect the auxiliary
voltage supply to the +24V and DGND terminals on the drive.
If you change the drive parameters when the control board is energized with the
BAPO module, force parameter saving with parameter 96.07 PARAM SAVE by
setting the value to (1) SAVE. Otherwise, changed data will not be saved.
Layout
1. BAPO module
2. Locking screw hole
3. Internal X100 connector
4. Internal X102 connector
5. Grounding rail
4
1
2
3
5
BAPO-01 auxiliary power extension module 159
Mechanical installation
Refer to To install a side option on page 69.
Electrical installation
Connect the auxiliary voltage supply to the +24V and DGND terminals on the drive.
Refer to Auxiliary voltage connection on page 67. The BAPO module has internal
connections to provide back-up power to the control board (I/O, fieldbus).
Start-up
To configure the BAPO module:
1. Power up the drive.
2. Set the parameter 95.04 Control board supply to 1 (External 24V).
160 BAPO-01 auxiliary power extension module
Technical data
Voltage and current rating for the auxiliary power supply
Refer to Auxiliary voltage connection on page 67.
Power loss
Power losses with maximum load 4 W.
3AXD50000031166 rev. A
Further information
Product and service inquiries
Address any inquiries about the product to your local ABB representative, quoting
the type designation and serial number of the unit in question. A listing of ABB sales,
support and service contacts can be found by navigating to
www.abb.com/searchchannels.
Product training
For information on ABB product training, navigate to new.abb.com/service/training.
Providing feedback on ABB Drives manuals
Your comments on our manuals are welcome. Navigate to
new.abb.com/drives/manuals-feedback-form.
Document library on the Internet
You can find manuals and other prod(BREL).
3. Use the control panel on the drive and set the parameters for relay outputs 2 to 5
in 15 I/O extension module. Refer to ACS380 Firmware manual
(3AXD50000029275 [English]) for parameter descriptions.
Configuration parameters
The configuration parameters of the BREL module are in group 15 I/O extension
module.
No. Name/Value Description Def/FbEq16/32
15 I/O extension module
15.01 Extension module
type
Sets the connected side-mounted extension module. None
BREL Basenut relay extension module 5
15.02 Detected extension
module
I/O extension module detected on the drive. None
BREL Basenut relay extension module 5
15.04 RO status Status of the relay outputs. 1=1
Bit 0 RO2 Relay 2 output status. 1 = open / 0 = closed
Bit 1 RO3 Relay 3 output status. 1 = open / 0 = closed
Bit 2 RO4 Relay 4 output status. 1 = open / 0 = closed
Bit 3 RO5 Relay 5 output status. 1 = open / 0 = closed
15.05 RO force selection Selection of relay outputs for forcing. 1=1
Bit 0 RO2 Relay 2 output status. 1 = selected to force / 0 = normal
Bit 1 RO3 Relay 3 output status. 1 = selected to force / 0 = normal
Bit 2 RO4 Relay 4 output status. 1 = selected to force / 0 = normal
Bit 3 RO5 Relay 5 output status. 1 = selected to force / 0 = normal
15.06 RO forced data Relay output forcing. 1=1
Bit 0 RO2 Relay 2 output status. 1 = open / 0 = closed
Bit 1 RO3 Relay 3 output status. 1 = open / 0 = closed
Bit 2 RO4 Relay 4 output status. 1 = open / 0 = closed
Bit 3 RO5 Relay 5 output status. 1 = open / 0 = closed
15.07 RO2 source Relay output 2 source selection.
Relay output 2 is open. 0
Relay output 2 is closed 1
For complete parameter list, refer to ACS380 Firmware
manual (3AXD50000029275 [English])
...
BREL-01 relay output extension module 155
15.08 RO2 ON delay Sets the activation delay for relay output 2. 0.0 s
0.0...3000.0 s Activation delay for relay output 2. 10 = 1 s
15.09 RO2 OFF delay Sets the |
