可以被命令移动电机。然后执行BZ命令
如上所述发布。例如在通电或断电时初始化X轴电机
复位时，可发出以下命令：
SHX；启用X轴电机
PRX=-1*（_BZX）；将X电机移到接近零换向相位
BGX；在X轴上开始运动
AMX；等待X轴上的运动完成
BZX=-1；驱动电机至换向相位零并离开
;发动
方法3.使用命令BC。该命令使用霍尔转换来确定：
换向阶段。理想情况下，霍尔传感器的过渡将被确地分隔开
60°以及与60°的任何偏差将影响该方法的度。如果大厅
传感器准确，建议使用此方法。指挥中心监视大厅
移动过程中的传感器，并监控霍尔传感器的过渡点。当
发生时，控制器计算换向相位并进行设置。例如
在通电或复位时初始化X轴电机，可发出以下命令：
SHX；启用X轴电机
BCX；启用无刷校准命令
PRX=50000；命令X轴上的相对位置移动
BGX；在X轴上开始运动。当霍尔传感器
; 如果检测到相变，则换向相位为：
;重新设置。
步骤8C。连接步进电机
在步进电机运行中，脉冲输出信号具有50%的占空比。步进电机在开路状态下运行
循环，不需要编码器反馈。当使用步进器时
Artisan技术集团-质量仪器…保证|（888）88-SOURCE| www.artistg.com
DMC-18x2第2章入门•21
对应的轴不可用于外部连接。如果编码器用于定位
反馈，将编码器连接到对应于该轴的主编码器输入。指挥
步进器的位置可以用RP或DE查询。编码器位置可以查询
使用TP。
步进电机脉冲的频率可以用滤波器参数KS平滑。KS
参数的范围在0.5到16之间，其中16表示大的平滑量。看见
关于KS的命令参考。
DMC-18x2轮廓仪命令步进电机放大器。所有DMC-18x2运动命令均适用
如PR、PA、VP、CR和JG。加速度、减速度、回转速度和平滑度也会受到影响
习惯于由于步进电机开环运行，PID滤波器不起作用，位置误差也不存在
生成。
要将步进电机与DMC-18x2连接，必须遵循以下步骤：
步骤A.安装SM跳线
将操作步进电机的DMC-18x2的每个轴必须具有
安装了相应的步进电机跳线。有关SM跳线的讨论，请参阅
第2节：在DMC-18x2上安装跳线。
步骤B.将步进和方向信号从控制器连接到电机放大器
从控制器到步进电机放大器上的相应信号。（这些信号是
在ICM-2900上标记为x轴的PWMX和SIGNX）。查阅文档
用于步进电机放大器。
步骤C.使用MT命令为电机类型配置DMC-18x2。您可以配置
DMC-18x2用于有源高或有源低脉冲。将命令MT 2用于激活低电平
步进电机脉冲和MT-2用于有源高阶步进电机的脉冲。请参见MT的说明
命令引用中的命令。
步骤9.调整伺服系统
使用伺服电机（标准或正弦）时，需要调整调谐参数
换向）。系统补偿可提供快速准确的响应，并实现以下功能：
演示提出了一种简单易行的补偿方法。更先进的设计方法是：
可使用Galil的软件设计工具，如伺服设计工具包（SDK软件）
该滤波器有三个参数：阻尼，KD；比例增益KP；和积分器KI。
应按此顺序选择参数。
首先，使用指令将积分器设置为零
KI 0（CR）积分器增益
并将比例增益设置为低值
KP 1（CR）比例增益
KD 100（CR）导数增益
为了获得更大的阻尼，您可以增加KD（大值为4095）。逐渐增加，然后停止
马达振动。振动可以通过声音或询问来察觉。如果您发送命令
TE X（CR）告诉错误
几次，得到不同的响应，特别是极性反转时，表示系统振动。
发生这种情况时，只需减少KD。
接下来，需要逐渐增加KP的值（允许的大值为1023）。您可以监视
使用Tell Error指令改善响应
KP 10（CR）比例增益
