VMIVME-7805/VME-7805RC*是功能齐全的奔腾4处理器-M
单插槽中的兼容单板计算机（SBC），被动冷却，
Eurocard外形尺寸，采用Intel®852GM的先进技术
运行400 MHz前端总线速率的芯片组。VMIVME-7805/
VME-7805RC符合VMEbus规范版本C.1和功能
一个透明的PCI到VME桥接器，允许电路板作为一个系统运行
多CPU系统中的控制器或外围CPU。
VMIVME-7805/VME-7805RC提供了桌面上常见的功能
系统，例如：
•达1 GB的PC1600 DDR SDRAM
•内部SVGA和DVI控制器
•两个内置以太网控制器
•IDE驱动器支持（VME P2）
•软盘驱动器支持（VME P2）
•两个性能16550兼容串行端口（COM1和COM2）
•前面板通用串行总线（USB）连接版本2.0
•实时时钟/日历
•前面板复位开关
•微型扬声器
•键盘/鼠标端口
VMIVME-7805/VME-7805RC能够执行当今的许多功能
桌面操作系统，如Microsoft®的Windows®XP、Windows 2000和，
以及各种基于Linux®的操作系统。标准桌面
VMIVME-7805/VME-7805RC的特性在2章标准中进行了描述
功能，本手册25页。
VMIVME-7805/VME-7805RC提供了对嵌入式系统有用的功能
应用程序，例如：
•I2C总线支持
•远程以太网引导
•达1 GB的CompactFlash（可选）
•四个通用可编程定时器（两个16位和两个32位）
•带复位的软件可选看门狗定时器
•32 KB非易失性RAM
此外，VMIVME-7805/VME-7805RC还提供了一个PMC扩展站点，其中包含：
前面板通道。VMIVME-7805/VME-7805RC能够执行以下操作：
当今的许多嵌入式操作系统，如VxWorks®、QNX®、Linux®，
LynxOS®和微软的Windows XP。系统的嵌入式功能
VMIVME-7805/VME-7805RC在3章嵌入式PC/RTOS中进行了描述
功能，本手册39页。
8 VMIVME-7805/VME-7805RC硬件参考手册
VMIVME-7805/VME-7805RC适用于各种应用，
例如：电信、仿真、仪表、工业控制、，
过程控制和监控、工厂自动化、自动化测试系统、数据
采集系统和任何具有性能处理的地方
需要单个VME插槽中的功率。
英特尔852GM芯片组
VMIVME-7805/VME-7805RC采用了新的英特尔芯片组技术，
852GM。Intel 852GM芯片组是一种优化的集成图形解决方案
具有400 MHz系统总线和集成的32位3D核，频率为133 MHz，具有：
动态视频存储技术（DVMT）。芯片组具有低功耗设计，
级电源管理，支持敢达1 GB的DDR系统内存。
852GM是图形存储器控制器集线器组件（GMCH），
提供处理器接口、系统存储器接口（DDR SDRAM）、集线器
接口、CRT和数字视频输出（DVO）端口。
852GM的主要功能：
•400 MHz处理器系统总线控制器
•图形控制器接口
•一个数字视频输出端口
•支持DDR200内存技术
•速加速集线器架构接口，用于与
ICH4-M（I/O控制器）
概述9
图1 VMIVME-7805/VME-7805RC框图
注
Intel 82540EM用于VMIVME-7805，Intel 82541PI用于VME-7805RC（RoHS）。
10 VMIVME-7805/VME-7805RC硬件参考手册
组织
本手册由以下章节和附录组成：
概述提供了VMIVME-7805/VME-7805RC的一般说明，以及
一般安全术语和符号。
1章“搬运和安装”介绍了开箱、检查和硬件
跳线设置、连接器定义、安装、系统设置和操作
VMIVME-7805/VME-7805RC。
2章“标准特性”从标准PC的角度描述了单元设计
内存和I/O映射，以及标准中断架构。
3章-嵌入式PC/RTOS功能介绍了以下单元功能：
超出标准功能。
维护部门提供与护理和维修相关的GE联系信息
设备的维护。
法规遵从性提供了有关法规遵从性的适用信息。
附录A连接器引脚说明并定义了本规范中包含的连接器
设备的I/O端口。
附录B-AMI BIOS描述了与
美国Megatrends，Inc.（系统）BIOS。
附录C-系统驱动程序软件提供了f
