注9：涂层厚度不能在盲板或板上控制
小直径深孔或溶液循环受限的地方。
7.2.3附着力：涂层应具有足够的附着力
以通过规定的粘附试验（见9.4
和试验方法B 571）。
7.2.4孔隙率：涂层应基本无孔
当根据9.6中的一种方法进行试验时
方法、试验持续时间和允许斑点数
应规定单位面积（见第5.1.10节和第9.6节）。
B 733-97
4.
7.3资格要求：这些要求包括：
放置在沉积物和工艺上，并在
试样，以确定沉积和电镀工艺。测试
对于这些认证要求，应执行：
每月或更频繁。
7.3.1 II、III、IV、V类沉积物的成分应为：
通过磷测试分析合金成分（参见
9.1). 磷的重量百分比应在以下范围内：
由类型分类指定（见4.1）。
7.3.2显微硬度——应通过试验方法B 578（努氏硬度计）测定2类沉积物的显微硬度。对于
对于2级涂层，显微硬度应等于或超过a
低850（HK100（或同等维氏硬度）（见4.3和
9.5). 使用表E 140将维氏硬度转换为努氏硬度
不推荐使用。
7.3.3氢脆：用于在高强度钢上沉积涂层的工艺应进行以下评估：
氢脆试验方法F 519。
8.抽样
8.1敦促买方和生产商在涂装过程中采用统计过程控制。正确执行
这将确保涂层产品具有令人满意的质量
减少验收数量。
8.1.1抽样计划只能筛选出不合格项
不保证任何产品都不被接受的产品。
(7)
8.2用于检验数量的抽样计划
涂层零件（批次）的试验方法应为B 602，除非：
买方在采购订单中另有规定，或
合同（见第5.1.11节和第S.11.1节）。
注10：通常，当收集涂层零件（检验批）时
8.2）检查是否符合零件上的要求
随机选择相对较少数量的零件，即样本
检查。然后，检验批被归类为合格或不合格
根据检查结果符合要求
样品样本大小和符合性标准如下：
由统计学的应用确定。该过程称为
抽样检查。三个标准试验方法B 602，指南B 697，
和试验方法B 762中包含的抽样计划是针对以下情况设计的：
涂料的抽样检验。
试验方法B 602包含四个抽样计划，其中三个用于试验
这是非破坏性的，一个用于破坏性测试。这个
买方和生产商可就使用的计划达成一致。如果它们没有，
测试方法B 602确定了要使用的计划。
指南B 697提供了大量计划，并给出了指导
关于计划的选择。当规定了指南B 697时
生产商需要就使用的计划达成一致。
试验方法B 762仅适用于以下涂层要求：
例如涂层厚度。后一个必须产生一个
必须满足数值和某些统计要求。测验
方法B 762包含多个计划，并给出了以下说明：
计算满足特殊需求的计划。买方和生产商可以：
商定要使用的计划。如果没有，则采用试验方法B 762
确定要使用的计划。
检验批应定义为涂层零件的集合
是按相同规格生产的同类产品，
其已由单个生产商一次或大约一次涂覆
同时，在基本相同的条件下，作为一组提交接受或拒绝。
8.3验收抽样计划中使用的所有试样
试验应使用相同的基础材料和相同的材料进行
根据本规范电镀的物品的冶金条件。
8.4所有试样应由买方提供，除非：
否则由生产商同意。
注11：自动催化镍工艺是动态的，每天都有一次
建议取样。对于需要合金分析的涂层
腐蚀试验应考虑每周取样。
9.试验方法
9.1磷的沉积分析：
9.1.1磷的测定-测定质量百分比
磷含量符合规程E 60的试验方法
E 352或测试方法E 156
溶于温暖的浓硝酸中。
9.1.2成分可通过原子吸收测定，
发射或X射线荧光光谱法。
注12：电感耦合等离子体技术可以确定
合金含量在0.5%以内。已经分析了以下分析波长线：
习惯于
