ABB P4LQA HENF209736R0003模块备件

ABB P4LQA HENF209736R0003

警告！即使电机停止，也会产生危险电压
在电源电路端子U1、V1、W1和U2、V2、V2和V2处，
并且根据帧大小，UDC+/BRK+和
UDC-/BRK-。
警告！输入功率不足时存在危险电压
有联系的。断开电源后，至少等待5分钟
在卸下盖子前几分钟。要检查，请测量零
直流端子处的电压，取决于机架
尺寸、UDC+/BRK+和UDC-/BRK-。
警告！即使当电源从输入端断开时
ACH550的端子可能存在危险电压（来自
外部电源）连接到继电器输出端
RO1…RO3，如果继电器扩展板包括在
安装，RO4…RO6。
警告！当两个或更多个控制端子驱动时
装置并联连接时，这些装置的辅助电压
控制连接必须来自单个源，该源：
可以是单元之一或外部电源。
警告！如果将驱动器安装在IT系统上（例如
电源系统未接地或高电阻接地[过电压]
30欧姆]电力系统）或配备有
剩余电流断路器），断开内部EMC
滤波器，否则系统将连接到地电位
通过EMC滤波电容器。这可能导致危险或危险
损坏驱动器。
如果将驱动器安装在角落接地TN系统上，
断开内部EMC滤波器的连接，否则系统将无法正常工作
通过EMC滤波电容器连接到地电位。
这将损坏驱动器。
注意：断开内部EMC滤波器会增加
传导发射，降低驱动器EMC兼容性
相当地。
10.本手册的内容
ACH550-01用户手册
有关断开EMC滤波器的连接，请参阅断开内部滤波器
EMC过滤器，第45页。
维修
警告！ACH550不是可现场维修的装置。从不
试图修复故障单元；联系您当地的ABB
更换代表。
驱动和电机的控制
警告！ACH550将在故障后自动启动
如果外部运行命令为on，则输入电压中断。
警告！请勿使用交流接触器或其他装置控制电机
断开装置（断开装置）；使用
控制面板（操作员键盘）启动（手动），自动）
和停止（关闭）键或外部命令（I/O或
现场总线）。电池的大允许充电循环次数
直流电容器（即

ABB P4LQA HENF209736R0003

ABB P4LQA HENF209736R0003
