MOTOROLA MVME147S-1模块备件

MOTOROLA MVME147S-1

电阻器提供了连续监测开关电流的方法。信号
晶体管用于驱动开关2的栅极。它为开关2提供负栅极
电压，以小化其导通电阻，并用于在以下情况下保持开关2导通：
辅助门控制失去电源。
开关2的栅极和源极之间的齐纳二极管仅用于保护电源
栅极从漏极上的大电压尖峰开始，当
开关1和开关2处于断开状态。
与开关1的栅极和信号晶体管串联的电阻器用于保护电路
恶意开关故障时的驱动逻辑。上拉电阻器限定栅极
无电时的电压。
1.9.1.开关诊断
在正常操作期间，开关1和开关2保持接通。在此状态下，开关1
开关2表现出低电阻。
为了确定系统通过开关1和开关2控制负载的能力
一次一个地调制栅极电压。当栅极电压被调制时
监测信号以可预测的方式同步变化。本地DSP分析
这些小交流信号的相对振幅和相位来确定导通电阻
每个开关的阈值电压。
不需要完全中断到负载的电流以获得稳定的电流
晶体管关断能力的置信水平。对于TMR开关
在接通状态的配置中一次只需要调制一个故障安全开关，
而另外两个承受负载电流。
1.说明：可信TMR 24Vdc数字输出模块–40信道
1014期罗克韦尔自动化出版物ICSTT-RM280N-EN-P
1.9.2.短路保护
根据IEC 61131-2，输出信道被分类为受保护信道，特别是“受保护信道”
“产出和需求”。
通电时，监测通道输出电流以保护通道开关
防止因持续过流状况而造成损坏。在检测到持续过电流状况后，锁定短路故障状态，并使输出断电。
在断电时，输出可选择性地配置为检测短路场
故障（电阻小于24Ω) 通过System.INI文件配置。检测
断电时的短路依赖于励磁电路的部分通电
确定信道负载电阻。设计了磁场电路的部分激励
以将场电压或电流的任何变化分别限制为小于2V或100mA。
锁定短路故障状态可通过操作系统故障复位按钮清除
或者通过转换命令的信道状态。
输出还包括不可更换的熔断丝，以提供对保护。
