输出模块故障通过前面板上的视觉指示器报告给用户
并通过状态变量，该状态变量可在
应用程序和外部系统通信接口。一般来说
用户必须修复两种类型的故障：外部接线和模块故障。
外部接线故障需要在现场采取纠正措施以修复故障状况。
模块故障需要更换输出模块。
5.2.现场接线故障
通过测量输出通道电压和电流，模块自动检测
现场接线和负载故障。当磁场信号失效、断路、短路或无故障时
连接现场电源电压时，输出状态指示器将显示配置的LED
模式下，将报告相应的输出状态以及该模式的线路故障状态
频道将设置为“1”。除以下情况外，所有其他输出通道将不受影响：
现场常见原因接线和电源电压故障。
可以监控磁场输出电压和电流变量，以确定实际电压
每个输出通道的操作条件。该附加信息有助于用户：
确定特定类型的接线故障。
一旦识别并纠正了特定的现场接线故障，输出状态
变量和输出状态指示器将显示现场设备的正常开/关状态。
5.3.模块故障
广泛的诊断功能可自动检测模块故障。TMR
输出模块的体系结构和执行的诊断验证了所有参数的有效性
关键电路。使用TMR架构提供了一种容错方法
模块上一次出现故障，并继续正常输出控制，无故障
系统或过程中的中断。故障通过健康网络报告给用户
模块前面板上的状态指示灯，通过INFO和HKEEPING
变量。在正常操作下，所有三个健康指示灯均为绿色。当发生故障时
发生时，其中一个健康指示灯将闪烁红色。建议：
调查情况，如果故障在模块内，则应予以更换。
模块更换活动取决于所选备用模块配置的类型
当系统被配置和安装时。该模块可以配置有
专用备用插槽或带有备用更换模块的智能插槽。
5.故障查找和维护可信TMR 24Vdc数字输出模块–40信道
3014期罗克韦尔自动化出版物ICSTT-RM280N-EN-P
5.4.配对槽
对于配对插槽配置，将配置受信任机箱中的两个相邻插槽
对于相同的输出模块功能。一个插槽是主插槽，另一个是插槽
辅助（或备用）插槽。这两个插槽在受信任机箱的后部通过一个
双宽I/O接口电缆，将两个插槽连接到公共现场布线
终止。在正常操作期间，主插槽包含有源模块组件
由模块前面板上的激活指示灯指示。辅助时隙是
可用于通常为备用模块的备用模块，如所示
模块前面板上的备用指示灯。
根据安装情况，可能已经安装了热备盘模块，或者安装了热备用模块
坯件将安装在备用插槽中。如果已安装热备盘模块，则转移
当在激活模块中检测到模块故障时，将自动发生对备用模块的故障
单元如果未安装热备盘，系统将继续从激活状态运行
直到安装备用模块。
5.5.智能插槽
对于SmartSlot配置，辅助插槽对于每个主插槽不是的。相反
单个辅助插槽在许多主插槽之间共享。该技术提供了
在给定物理空间中安装的模块的高密度。在受信任区域的后部
在机箱中，单个宽I/O电缆将辅助插槽直接连接到I/O线缆
已连接到发生故障的主模块。利用备用模块

RAMIX PMC008A 700502

RAMIX PMC008A 700502

Output Module faults are reported to the user through visual indicators on the Front Panel of the Module and through status variables which may be automatically monitored in the application programs and external system communications interfaces. There are generally two types of faults that must be remedied by the user: external wiring and Module faults. External wiring faults require corrective action in the field to repair the fault condition. Module faults require replacement of the Output Module. 5.2. Field Wiring Faults By measuring the output channel voltage and current, the Module automatically detects field wiring and load faults. When a field signal fails open circuit, short circuit or there is no field supply voltage connected, the output status indicator will display the configured LED mode, the corresponding output state will be reported and the line fault status for that channel will be set to ‘1’. All other output channels will be unaffected, except in the case of common cause wiring and supply voltage faults in the field. The field output voltage and current variables can be monitored to determine the actual operating conditions of each output channel. This additional information assists the user in determining the specific type of wiring fault. Once the specific field wiring fault has been identified and corrected, the output status variables and output status indicator will display the normal on/off status of the field device. 5.3. Module Faults Extensive diagnostics provide the automatic detection of Module faults. The TMR architecture of the Output Module and the diagnostics performed verify the validity of all critical circuits. Using the TMR architecture provides a Fault Tolerant method to withstand the first fault occurrence on the Module and continue normal output controls without interruption in the system or process. Faults are reported to the user through the Healthy status indicators on the Front Panel of the Module and through the INFO and HKEEPING variables. Under normal operations all three Healthy Indicators are green. When a fault occurs, one of the Healthy Indicators will be flashing red. It is recommended that this condition is investigated and if the fault is within the Module, it should be replaced. Module replacement activities depend on the type of spare Module configuration chosen when the system was configured and installed. The Module may be configured with a Dedicated Standby Slot or with a SmartSlot for a spare replacement Module. 5. Fault Finding and Maintenance Trusted TMR 24Vdc Digital Output Module – 40 Channel 30 Issue 14 Rockwell Automation Publication ICSTT-RM280N-EN-P 5.4. Companion Slot For a Companion Slot configuration, two adjacent slots in a Trusted Chassis are configured for the same Output Module function. One slot is the primary slot and the other a unique secondary (or spare) slot. The two slots are joined at the rear of the Trusted Chassis with a double-wide I/O Interface Cable that connects both slots to common field wiring terminations. During normal operations, the primary slot contains the Active Module as indicated by the Active indicator on the Front Panel of the Module. The secondary slot is available for a spare Module that will normally be the Standby Module as indicated by the Standby indicator on the Front Panel of the Module. Depending on the installation, a hot-spare Module may already be installed, or a Module blank will be installed in the Standby slot. If a hot-spare Module is already installed, transfer to the Standby Module occurs automatically when a Module fault is detected in the Active Module. If a hot-spare is not installed, the system continues operating from the Active Module until a spare Module is installed. 5.5. SmartSlot For a SmartSlot configuration, the secondary slot is not unique to each primary slot. Instead, a single secondary slot is shared among many primary slots. This technique provides the highest density of Modules to be fitted in a given physical space. At the rear of the Trusted Chassis, a single-wide I/O Cable connects the secondary slot directly to the I/O Cable connected to the failed primary Module. With a spare Module
