*需要HAM许可证，特殊解锁程序，仅适用于选定型号！
注意
这些视频发射器能够进行射频传输，输出功率可能不高
允许在你的国家。
请始终检查您当地的射频法规，以根据以下要求设置频率和输出功率：
条例。
遥控飞机的一般规则是必须始终在视线范围内进行控制，请检查遥控飞机
法规与法规保持同步。
常见问题
如果您在阅读本手册后有任何问题，请访问TBS FAQ部分
笔记
本手册基于FW 1.16编写。如果某些功能不适用于您，请更新您的
统一到这些或更高版本。
更新
为了更新Unify32（而不是Nano32），您需要TBS代理X，您可以从
TBS商店。
要更新VTX，请通过USB端口连接VTX，然后通过代理X运行更新。
有关如何使用AgentButton菜单控件的详细说明，请参阅
菜单由类别和设置组成。按下按钮3秒将在以下两种模式之间切换：
类别，短时间按下可在设置之间切换。要进入菜单，请按住按钮3秒钟
几秒钟。LED颜色将显示菜单的状态，有关概述，请参阅菜单表。
解锁和电源选择模式
（仅限火腿用户！）按下按钮约30秒。红色LED将闪烁3次以确认。
您已解锁视频发射器，可用于所有频率（请参阅下面的频率表）。
注意：解锁仅在您位于波段选择菜单内时有效
现在可以访问电源选择模式。解锁后，您可以根据
下表。要锁定发射器，请返回频带选择菜单并按下按钮20至25
再过几秒钟。TBS统一PRO32 5G8信号选择的信道、频带和功率电平，使用以下启动序列：
LED代码。同样的顺序也在菜单中重复以使其统一。首先，红色LED闪烁至：
指示正在显示的项目。频道闪烁一次，波段闪烁两次，功率电平闪烁三次。
随后，蓝色LED将指示该值。
菜单表
*仅限Unify PRO32 HV
**仅限Unify PRO32 Nano
红色LED：指示项目-频道、频带或功率设置
蓝色LED：指示值
红色LED和蓝色LED
1x 2x 3x 4x 5x 6x 7x 8x
1x频道1、2、3、4、5、6、7、8
2次A、B、E波段无线电波比赛
3倍功率等级25mW 100mW 400mW 1000mW
4倍极限温度60 70 80 90 100 105
带内5x凹坑模式关闭
6x CRSF/SA/PWM关闭CRSF SA PWM**
7x*音频（麦克风）关闭打开
8.
信道/频带-频率表
灰色字段是默认出厂设置。
橙色的选择需要HAM许可证才能合法运营。黑色选项仅在上可用
特殊要求（经法律机构事先批准的大型活动定制固件）。视频发射器
确保您不会意外选择非法通道或功率级别：
● 当通过按钮控制时，您需要通过以下方式确认拥有HAM许可证：
上述步骤可解锁视频发射器
● 通过CORE PRO，您需要在“呼号”下输入您的HAM许可证号码
菜单，然后才能访问高功率传输设置和锁定频道
频道1、2、3、4、5、6、7、8
频带A 5865 5845 5825 5805 5785 5765 5745 5725 MHz
频带B 5733 5752 5771 5790 5809 5828 5847 5866 MHz
频带E 5705 5685 5665 5645 5885 5905 5925 5945 MHz
无线电波5740 5760 5780 5800 5820 5840 5860 5880 MHz
比赛频带5658、5695、5732、5769、5806、5843、5880、5917 MHz
功率等级25 100 400 1000+mW
9
安装/安装
安装Unify Pro32时，请确保有足够的气流，重要的是，确保传热。
这意味着安装Unify Pro32时，在一块平坦的碳上施加一点压力，将为您提供：
这是好的结果。确保将Unify的触点与碳隔离，以避免短路。
正确安装将允许视频发射器坐在屏幕上长时间运行
接地，而不降低输出功率

TEAM BL0170

TEAM BL0170

* requires HAM license, special unlocking procedure, available on selected models only!
Attention
These video transmitters are capable of radio frequency transmissions and output power that may be not
allowed in your country.
Please always check your local RF legislation to set the frequency and output power according to
the regulation.
A general rule for RC aircrafts is that they must be controlled always under sight of view, check your RC
regulation to keep up to date with regulations.
FAQ
If you got any question after reading this manual you should visit the TBS FAQ section
Note
This manual is written based on FW 1.16. If some functions are not available for you, please update your
Unify to these or later versions.
Updating
In order to update your Unify32 (not Nano32) you need the TBS Agent X, which you can download from
the TBS shop .
To update your VTX, connect it by the USB-port and run the update by Agent X.
For detailed instructions on how to use AgentButton menu control
The menu consists of categories and settings. Pressing the button for 3 seconds will toggle between
categories, pressing it for a short time toggles between settings. To enter the menu, hold the button for 3
seconds. LED colors will signal the state of the menu, for an overview see the menu table.
Unlock & power select mode
(FOR HAM USERS ONLY!) Press the button for about 30 seconds. The Red LED will flash 3 times to confirm.
You have unlocked the video transmitter for use with all frequencies (see frequency table below).
NOTE: Unlock only works if you are inside the band selection menu
The power select mode is now accessible. Once unlocked, you can select the power level according to the
table below. To lock the transmitter, go back into band select menu and press the button for 20 to 25
seconds again.The TBS UNIFY PRO32 5G8 signals selected channel, band and power levels using a startup sequence of
LED codes. The same sequence is also repeated in the menu to make it unified. First the RED LED flashes to
indicate the item being shown. One flash for channel, two flashes for band, three flashes for power level.
Subsequently, the BLUE LED will indicate the value.
Menu Table
* Unify PRO32 HV only
** Unify PRO32 Nano only
Red LED: Indicate item - Channel, band or power setting
Blue LED: Indicate value
RED LED BLUE LED
1x 2x 3x 4x 5x 6x 7x 8x
1x Channel 1 2 3 4 5 6 7 8
2x Band A B E Airwave Race
3x Power Level 25mW 100mW 400mW 1000mW
4x Limit Temp. 60 70 80 90 100 105
5x PIT Mode OFF IN-BAND
6x CRSF/SA/PWM OFF CRSF SA PWM**
7x* Audio (Mic) OFF ON
8
Channel/ Band - Frequency Table
Grey fields are the default factory setting.
The selections in orange requires HAM license to operate legally. Black selections are only available on
special request (custom firmware for large events with prior legal body approval). The video transmitter
ensures that you cannot select illegal channels or power levels by accident:
● When controlled by the push button, you will need to confirm having a HAM license by following
the steps described above to unlock your video transmitter
● Through the CORE PRO, you are required to enter your HAM license number under the “Callsign”
menu before you can access the high power transmission settings and the locked out channels
Channel 1 2 3 4 5 6 7 8
Band A 5865 5845 5825 5805 5785 5765 5745 5725 MHz
Band B 5733 5752 5771 5790 5809 5828 5847 5866 MHz
Band E 5705 5685 5665 5645 5885 5905 5925 5945 MHz
Airwave 5740 5760 5780 5800 5820 5840 5860 5880 MHz
Race Band 5658 5695 5732 5769 5806 5843 5880 5917 MHz
Power Level 25 100 400 1000+ mW
9
Installation / Mounting
When installing the Unify Pro32, please ensure adequate airflow and - most importantly - heat transfer.
This means mounting the Unify Pro32 with a bit of pressure against a flat piece of carbon will give you the
best results. Make sure to isolate the contacts of the Unify against the carbon to avoid short circuits.
Proper mounting will allow the video transmitter to run for extended periods of time while sitting on the
ground and without reducing output pow
