MVME172-313A模块备件

MVME172-313A

TVME7100 SystemPak
I/O选项
•基于PMC的I/O选项，包括：
•快速和千兆以太网端口
•SCSI、音频、视频、DI/O、A/D、D/A、数据采集，
运动控制
•Mil标准1553、Arinc 429、AFDX
•基于RTM的I/O选项
•异步串行端口：四个，RJ-45，标记为COM 2-5
•10/100/1000以太网BaseTX，RJ-45端口
•用于增加I/O能力的PMC载波卡
单板计算机
•SBC采用英特尔和飞思卡尔的新产品
6U Eurocard形状因数处理器
•用于后部I/O连接的后部过渡模块–直接连接
RTM可用
以太网交换机
•以太网交换机可提供8到30个端口
前面板和后面板组合，通过RJ45端口和
底板
•6U欧洲卡外形系数。
•10/100/1000铜端口或光纤端口
•第3层托管交换机和第2层非托管交换机
•用于后部I/O连接的后部过渡模块–直接连接
RTM可用
存储
•基于固态驱动器的存储，用于坚固耐用的环境
良性环境的要求和旋转驱动器
•6U Eurocard和PMC外形系数。
•PATA（IDE）、SATA和SCSI驱动器选项
•6U网络连接（NAS）RAID存储
移动塔
•2U、3U、4U或6U x 84HP（卡盒宽度和度）
•基于VITA的3、5、7和12插槽系统平台（VME、VME64x
VPX和VXS）
•级EMC屏蔽（可选），以满足CE和FCC的要求
•广泛的PSU输入（90-264伏交流电，48伏直流电）
•带冗余热插拔的固定安装或前端可插拔PSU
选择权
•直流电压、风扇故障和超温的系统监控
（可选）
•连接器选项：3排（96针）、5排（160针）、5行+P0
坚固的选项
•所有Elma底盘和有效载荷产品都有坚固的外壳
版本包括传导冷却模型，扩展
温度和扩展冲击与振动模型
•保形涂层
•坚固的系统可以进行测试，以满足特定的环境要求
全应用负载下的要求
Elma Electronic提供多种嵌入式存储产品，帮助您构建能够满足您需求的系统。考虑一下
选择选项后，请与我们的嵌入式计算架构师合作，使用自定义
背面的配置键。
Elma Electronic |215.956.1200sales@elma.comwww.elma。com| www.acttechnico.com
TVME7100 SystemPak
ACT/Technico标志和产品品牌是Elma Electronic股份有限公司的注册商标。
说明订单号
•单板计算机
•以太网交换机
•SATA PMCDisk
•32型底盘
•VxWorks启动映像，运行
时间许可证和驱动程序集
S32V6NP4NPCXNVN-711
自定义配置密钥
不同的配置是可能的，尽管并非所有选项都兼容。请联系我们的嵌入式计算架构师进行讨论
具体要求并了解其他嵌入式系统解决方案，或访问我们的网站www.acttechnico.com

MVME172-313A

MVME172-313A
