标准连接器尺寸
下面的部分提供了尺寸、柔性电缆规格、以及，
以及各种1326电缆的互连信息。
图6
电机电源和反馈电缆尺寸
功率变换
连接器
大直径。
缆绳
大直径。溴
中国
电缆说明CH1
毫米（英寸）
BR2
毫米（英寸）
连接器
大直径。
没有-L
选项
连接器
大直径。
使用-L
选项
缆绳
大直径。
1326-CPB1-xxx用于1326AS-B3xxx的标准电力电缆
和1326AS-B4xxx
110.0 (4.3) 76.2 (3.0) 43.2 (1.70) 47 (1.85) 14.0 (0.55)
1326-CPB1T-xxx挠性电缆，适用于1326AS-B3xxx和
1326AS-B4xxx
110.0 (4.3) 104.1 (4.1) 43.2 (1.70) 47 (1.85) 10.4 (0.41)
1326-CPC1-xxx用于1326AS-B6xxx的标准电力电缆
和1326AS-B8xxx
128.0 (5.0) 76.2 (3.0) 54.1 (2.13) 57.2 (2.25) 16.3 (0.64)
1326-CPC1T-xxx柔性额定电力电缆，适用于1326ASB6xxx和1326AS-B8xxx
128.0 (5.0) 160.2 (6.3) 54.1 (2.13) 57.2 (2.25) 16.0 (0.63)
1326 CCU xxx标准换向反馈电缆
对于电机旋转变压器
110.0 (4.3) 50.8 (2.0) 36.6 (1.44) 40.4 (1.59) 11.0 (0.43)
1326 CCUT xxx挠性额定换向反馈电缆
对于电机旋转变压器
110.0 (4.3) 101.6 (4.0) 36.6 (1.44) 40.4 (1.59) 10.1 (0.40)
1326 CECU RAx xxx，
1326 CECU RBx xxx
高分辨率反馈，直角
（轴出口和后出口）在5，
15、30、60和90米。
87.4 (3.44) 115 (4.5) 36.6 (1.44) 40.4 (1.59) 11.5 (0.45)
1326 CECUT RAx xxx，
1326 CECUT RBx xxx
高柔性、高分辨率反馈，
直角（轴出口和后出口）为
有5米、15米、30米、60米和90米。
87.4 (3.44) 120 (4.7) 36.6 (1.44) 40.4 (1.59) 11.5 (0.45)
1.
CH被描述为电缆连接器高度。
2.
BR（弯曲半径）被描述为标准1326电缆组件的指定弯曲半径。BR可能因用户制造的电缆而异。对于
标准电缆，BR是一次性柔性应用。柔性电缆具有更高的BR以承受柔性应用。
安装前，所有电缆应悬挂或平放24小时。这将允许导体松弛到其自然状态并进行防护
防止内部扭曲。
10
出版物1326A-2.11-1998年5月
直角连接器尺寸
下表显示了连接器的高度和宽度。对于1326 xxxRAL xxx和1326 xxx RBL xxx电缆
并给出了接头波纹管。
电缆高度
毫米（英寸）
RA或RB
直径
毫米（英寸）
RAL或RBL
直径
毫米（英寸）
弯曲半径
1326 CCU RA xxx和-RB xxx 65.78（2.59）36.83（1.45）不适用50.8（2.0）
1326 CCUT RA xxx和-RB xxx 66.80（2.63）36.83（1.45）不适用101.6（4.0）
1326 CCU RAL xxx和-RBL xxx 66.80（2.63）40.38（1.59）38.61（1.52）50.8（2.0）
1326 CCUT RAL xxx和-RBL xxx 66.80（2.63）40.38（1.59）38.61（1.52）101.6（4.0）
1326 CECU RAL xxx和-RBL xxx 66.80（2.63）40.38（1.59）38.61（1.52）115（4.5）
1326 CECUT RAL xxx和-RBL xxx 66.80（2.63）40.38（1.59）38.61（1.52）120（4.7）
1326-CPB1-RA-xxx和-RB-xxx 68.58（2.70）43.18（1.70）不适用76.2（3.0）
1326-CPB1T-RA-xxx和-RB-xxx 68.58（2.70）43.18（1.70）不适用104.1（4.1）
1326-CPB1-RAL-xxx和-RBL-xxx 69.85（2.75）46.99（1.85）45.47（1.79）76.2（3.0）
1326-CPB1T-RAL-xxx和-RBL-xxx 69.85（2.75）46.99（1.85）45.47（1.79）104.1（4.1）
1326-CPC1-RA-xxx和-RB-xxx 84.07（3.31）54.36（2.14）不适用76.2（3.0）
1326-CPC1T-RA-xxx和-RB-xxx 84.07（3.31）54.36（2.14）不适用160.2（6.3）
1326-CPC1-RAL-xxx和-RBL-xxx 84.07（3.31）57.15（2.25）55.37（2.18）76.2（3.0）
1326-CPC1T-RAL-xxx和-RBL-xxx 84.07（3.31）57.15（2.25）55.37（2.18）160.2（6.3）
身高
直径
身高
直径
直径
在风箱处
1326 xxx RA xxx
和1326xxx RB xxx
1326 xxx RAL xxx
和1326 xxx RBL xxx
11
出版物1326A-2.11-1998年5月
隔板连接器尺寸
下表显示了1326 CCU Ex、1326的尺寸-
CPB1x-Ex和1326-CPC1x-Ex电缆。
注：无需将隔板电缆连接到机柜
墙，但您确实需要遵循中的信息
连接舱壁和双端的指南
电缆。
1326电缆螺钉
描述
直径
安装孔
毫米（英寸）
距离
中心
安装孔
毫米（英寸）
直径
连接器
毫米（英寸）
直径
连接器
开放
毫米（英寸）
弯曲半径
1326-CCU-E-xxx
1326-CCUT-E-xxx
1326 CCUT EE xxx
1326 CCU EL xxx
1326 CCUT EL xxx
4/40 3/8英寸3.353（0.132）26.975（1.062）28.575（1-125）30.163（1.188）CCU
11.0 (0.43)
长春工业大学
10.1 (0.40)
1326-CPB1-E-xxx
1326-CPB1T-E-xxx
1326-CPB1T-EE-xxx
1326-CPB1-EL-xxx
1326-CPB1T-EL-xxx
4/40 3/8英寸3.353（0.132）31.75（1.25）34.925（1.375）36.513（1.438）CPB1
140 (0.55)
CPB1Tx
10.4 (0.41)
1326-CPC1-E-xxx
1326-CPC1T-E-xxx
1326-CPC1T-EE-xxx
1326-CPC1-EL-xxx
1326-CPC1T-EL-xxx
6/32 3/8英寸3.810（0.150）39.675（1.562）43.637（1.718）45.225（1.781）CPC11
16.3 (0.64)
CPC1Tx
16.0 (0.63)
直径
安装孔
距离
中心之间
安装孔的数量
直径
连接器开口
墙面
4.623毫米（0.182英寸）
大宽度
柜体壁
AB
舱壁
连接器
直径
墙口
对于直径
连接器的设计
12
出版物1326A-2.11-1998年5月
布线信息
1326 CCU xxx标准

Woodward 5403-824

Woodward 5403-824
