正在建立或中止配置的VPN连接。
LAN/WAN上的LAN绿色LED位于LAN/WAN插座中（10/100和双工LED）
以太网状态。指示LAN或WAN端口的状态。一旦设备
已连接到相关网络，连续指示灯指示存在
连接到LAN或WAN中的网络伙伴。当数据包是
传输时，LED短暂熄灭。
万绿安
产品名称
14菲尼克斯电气8334_en_02
2.2 FL MGUARD SMART2
图2-2 FL MGUARD SMART2上的操作元件和LED
LED 2
救援按钮
（位于开口中。
可以用
拉直的回形针，
例如）LED 1 LED 3
表2-2 FL MGUARD SMART2上的LED
LED状态含义
1局域网上的绿色：存在到网络伙伴的连接
闪烁LAN：数据传输处于活动状态
2红色/绿色
甚至
正在闪烁启动进程。当设备刚刚连接到电源时。之后
几秒钟后，这导致心跳状态发生变化。
绿色闪烁着心跳。设备已正确连接并运行。
红色闪烁系统错误。重新启动设备。
•按下救援按钮（持续1.5秒）。
•或者，短暂断开设备电源，然后再次连接。
如果错误仍然存在，请启动恢复程序（参见第324页的“执行恢复程序”）或联系经销商。
3 WAN上的绿色：存在到网络伙伴的连接
闪烁的广域网：数据传输处于活动状态
1、2、3种LED灯
代码
恢复模式。按下救援按钮后。
请参见第323页的“注意：重启、恢复程序和刷新固件”
操作元件和LED
8334_en_02菲尼克斯电气15
2.3 FL MGUARD PCI4000
图2-3 FL MGUARD PCI4000上的操作元件和LED
广域网1 LED
SD卡插槽（配置
内存）
复位按钮
RJ45插座（LAN 1）用于
连接内部
网络
RJ45插座（广域网1）用于
连接外部
网络/因特网
局域网1 LED
电池（可更换）
静态LED
局域网2 LED
广域网1 LED
表2-3 FL MGUARD PCI4000 SD上的LED
LED状态含义
广域网1
局域网1
全双工绿色
半双工
广域网2
局域网2
10 Mbps时为黄色
闪烁10 Mbps，数据传输激活
100 Mbps上的绿色
闪烁100 Mbps，数据传输激活
局域网1
局域网2
广域网1
各种LED灯
代码
恢复程序/闪蒸
请参见第323页的“注意：重启、恢复程序和刷新固件”
红色/
绿色
正在闪烁启动进程。当设备刚刚连接到电源时。几天后
秒，这指示灯变为心跳状态。
绿色闪烁着心跳。FL MGUARD已正确连接并准备运行。
红色闪烁系统错误。重新启动设备。
•按下复位按钮（持续1.5秒）。
•或者，短暂断开设备电源，然后再次连接。
如果错误仍然存在，则启动恢复过程（请参阅“执行恢复
步骤”（第324页）或联系您的经销商。
产品名称
16菲尼克斯电气8334_en_02
2.4 FL-MGUARD-DELTA-TX/TX
图2-4上的操作元件和LED
SD卡插槽（配置
内存）
RJ45插座（局域网1）
用于连接
内部网络
RJ45插座（广域网1）
用于连接
外部网络
复位按钮
LED LAN 2/WAN 2
发光二极管
局域网1/广域网1
发光二极管
表2-4 FL MGUARD DELTA TX/TX上的LED
LED状态含义
广域网1
局域网1
全双工绿色
半双工
广域网2
局域网2
10 Mbps时为黄色
闪烁10 Mbps，数据传输激活
100 Mbps上的绿色
闪烁100 Mbps，数据传输激活
PWR绿色电源电压正常
状态绿色闪烁，FL MGUARD已准备好运行。
系统错误时出现红色错误
FL MGUARD在启动或闪烁状态下出现故障红色
信息未使用
