要建立VPN连接，请按住按钮几秒钟，直到
信号输出闪烁。然后才松开按钮。
闪烁表示FL MGUARD已收到建立
并且正在建立VPN连接。一旦建立VPN连接，信号输出将持续点亮。
•要释放VPN连接，请按住按钮几秒钟，直到出现信号
输出闪烁或熄灭。然后才松开按钮。
信号输出一出来，VPN连接就被释放。
操作连接
开/关开关
•要建立VPN连接，请将开关设置为ON位置。
•要释放VPN连接，请将开关设置为关闭位置。
ACK LED如果信号输出关闭，则通常表示定义的VPN连接未关闭
目前VPN连接未建立或由于错误而失败。
如果ACK指示灯点亮，则表示存在VPN连接。
如果ACK指示灯闪烁，则表示正在建立或释放VPN连接。
信号触点（报警
输出）
信号触点监控FL MGUARD RS4000/RS2000的功能，因此
启用远程诊断。信号触点处的电压对应于电源
施加电压。监测输出电压时，报告以下内容：
–两个电源电压中至少一个出现故障。
–FL MGUARD RS4000/RS2000的电源低于极限值（电源电压1和/或2低于11 V）。
–以太网连接的链路状态监控（如果配置）。默认情况下，在交付时，不监视连接。可以设置监控（请参见
第52页）。
–自检期间出错。
在重新启动期间，信号触点断开，直到FL MGUARD RS4000/RS2000
它已经完全启动了。当信号触点手动设置为
软件配置中“手动配置”下的“关闭”。
启动
8334_en_02菲尼克斯电气23
3.3.4连接电源电压
电源电压通过COMBICON插入式连接器连接，该连接器位于
设备的顶部。
图3-2连接电源电压：FL MGUARD RS4000/FL MGUARD
RS2000
FL MGUARD RS4000具有冗余电源电压。如果您只连接一个电源
电压，您将收到错误消息。
•取下电源和维修触点的COMBICON连接器。
•不要将维修触点连接到外部电压源。
•将电源电压线连接到相应的COMBICON连接器（P1/P2）上
FL MGUARD。以0.5…0.8 Nm的扭矩拧紧螺钉接线盒上的螺钉。
•将COMBICON连接器插入顶部的预期COMBICON插座中
FL MGUARD（见图3-2）。
电源电压正确连接后，状态LED P1亮起绿色。
在FL MGUARD RS4000上，如果存在冗余电源，状态指示灯P2也会点亮
电压连接。
FL MGUARD引导固件。状态LED STAT闪烁绿色。FL
以太网插座指示灯一亮，MGUARD就可以运行。此外，
状态LED P1/P2亮起绿色，状态LED STAT在心跳时闪烁绿色。
冗余电源（FL MGUARD RS4000）
可以连接冗余电源电压。两个输入都是隔离的。负载不是
分发。具有冗余电源的电源单元具有较高的输出电压
仅为FL MGUARD RS4000供电。电源电压与
住房
如果电源电压不是冗余的，则FL MGUARD RS4000指示
通过信号触点提供电压。此消息可以通过馈送电源来防止
通过两个输入（P1/P2）或通过在
连接P1和P2。
警告：FL MGUARD RS4000/RS2000设计用于直流操作
电压为11伏直流电…36伏直流电/SELV，大1.5安。
因此，根据EN 60950-1，只有具有电压限制的SELV电路可以
连接到电源连接和信号触点。
在FL操作过程中拆下或插入COMBICON连接器时
直接关闭FL MGUARD。
+24V+0V+24V-0V
P1和P2
+24伏+0伏
FL MGUARD FL MGUARD P1
产品名称
24菲尼克斯电气8334_en_02
