Woodward 9904-206模块备件

Woodward 9904-206

CI858K01驱动总线接口
套餐包括：
-CI858，通信接口
-TP858，底板，宽度=60 mm
3BSE018135R1
模式5
1条。
CI872K01 MOD5通信接口
安装在DIN导轨上。之间的通信接口
AC 800M和MOD5系统。
套餐包括：
-CI872，通信模块
-TP858，底板，宽度=60 mm
3BSE051129R1
客车配件
1条。
TK850V007 CEX总线延长电缆
长度=0.7米。
使用TK850V007需要TK851作为CEX总线终端。
3BSC950192R1
TB850 CEX总线终端器
带有25针DB25P公接头。用螺钉固定。
TB850 CEX总线终端必须始终安装在
CEX总线上的后一个单元。
3BSC950193R1
TB851 CEX总线终端器
带有25针DB25S母接头。用螺钉固定。
当通信接口单元安装在相邻
DIN导轨，通过CEX总线扩展连接
电缆（TK850），并使用TB851 CEX总线端接
终结者。
3BSC950194R1
BC810K02 CEX总线互连单元
包括：
-BC810，互连单元，2个单元
-TP857，底板，宽度=60 mm，2个单元
-TK851，互连电缆
-TB850，CEX总线终端，2台
3BSE031155R1
TK851V010连接电缆
长度=1.0米
用作：
-RCU链路电缆
-BC810互连电缆
3BSC950262R1

Woodward 9904-206

Woodward 9904-206

CI858K01 DriveBus Interface Package including: - CI858, Communication Interface - TP858, Baseplate, width = 60 mm 3BSE018135R1 MOD5 Article no. CI872K01 MOD5 Communication interface Installed on DIN rail. Communication interface between AC 800M and MOD5 system. Package including: - CI872,, Communication module - TP858, Baseplate, width = 60 mm 3BSE051129R1 Bus Accessories Article no. TK850V007 CEX-Bus Extension Cable Length = 0.7 m. Use of TK850V007 needs TK851 as CEX-bus terminator. 3BSC950192R1 TB850 CEX-Bus Terminator With 25-pin DB25P male connector. With screw fixing. A TB850 CEX-Bus terminator must always be installed on the last unit on the CEX-bus. 3BSC950193R1 TB851 CEX-Bus Terminator With 25-pin DB25S female connector. With screw fixing. When Communication Interface units are mounted on adjacent DIN rails, they are connected by means of a CEX-Bus extension cable (TK850) and terminated using a TB851 CEX-Bus terminator. 3BSC950194R1 BC810K02 CEX-Bus Interconnection Unit Including: - BC810, Interconnection Unit, 2 units - TP857, Baseplate, width = 60 mm, 2 units - TK851, Interconnection Cable - TB850, CEX-Bus Terminator, 2 units 3BSE031155R1 TK851V010 Connection Cable Length = 1.0 m Used as: - RCU Link Cable - BC810 Interconnection Cable 3BSC950262R1
