Woodward 9906-124模块备件

Woodward 9906-124

e就位。
如有必要，向上推锁片以锁定。
6 ControlNet模块中继器中距离光纤模块
9904-5.4-1998年2月
5.如“拆卸”中所示，拆下保护背板盖
保护帽”，见第7页。
6.连接到DIN导轨后，将模块向左滑动以配合
中继器适配器或另一中继器模块。
30043–M
!
注意：确保适配器和中继器
模块用DIN导轨锚固件固定在一起。
否则可能导致通信中断
和/或对模块造成损坏。
可连接到中继器适配器的模块总数
不能超过四个或模块的总功耗可以
不超过1.6A@5VDC，以先到者为准。
重要事项：如果超出模块或功率限制，可能会导致
中继器适配器和模块损坏。
重要事项：如果这是右侧模块，则DIN导轨闩锁必须为
用于光纤模块的右侧。
7.按照“布线光纤模块”中所示连接模块布线，显示背光CCFL/LED背光带调光功能
CPU 316或416 MHz RISC CPU（英特尔Xscale）
内存，闪存32 MB（英特尔StrataFlash）
内存，RAM 64 MB
应用程序闪存12 MB
实时时钟是的
电源+24 C14 20-30 V
环境温度0°C至+50°C
相对湿度5-85%，不凝结
外壳材料粉末涂层铝
正面材料Autotex F250/F157（键盘），（PP865S不锈钢316/1.4401）
外围设备
串行端口RS422/RS485，内螺纹，25引脚D-Sub，RS232C，外螺纹，9引脚D-Sub
以太网屏蔽RJ45 10/100 Mbit/sec
USB主机类型A（功耗大500 mA），设备类型B
PROFIBUS DP的PROFIBUS扩展槽
面板800的环境数据
垂直安装的气候操作条件：0°C至+50°C
水平安装：0°至+40°C
储存温度-20°C至+70°C
相对湿度5-85%，非冷凝
防护等级前面板密封IP 66
后面板密封IP 20
电磁兼容性和CE标志符合EMC指令2004/108/EC
根据EN61000-6-4（2007）测试电磁辐射
根据EN61000-6-2（2005）测试电磁抗扰度
电气安全UL508
UL 1604第I类、第2类A、B、C、D和T4类危险分类位置
海事证书ABS、DNV、GL、RINA
规格：PP820A、PP826A、PP836A和PP846A
显示器尺寸-5,7“6,5”10,4”
显示器有效面积，宽x高127.0 x 33.8 mm
分辨率240 x 64像素320 x 240像素640 x 480像素800 x 600像素
交互类型功能键功能键功能按键功能键
LED 16（2色）16（2颜色）16（1色）20（2色）
功耗（正常/大）0,15 A 0,3 A 0,4 A/0,9 A 0,5 A/1 A
尺寸
前面板，宽x高x深202 x 187 x 57毫米275 x 168 x 57毫米285 x 177 x 60毫米382 x 252 x 60 mm
切口尺寸166 x 149 mm 240 x 130 mm 246 x 139 mm 343 x 208 mm
安装深度57毫米58毫米55毫米58毫米
重量：0875 kg 1,11 kg 1,3 kg 2,3 kg
规格：PP815A、PP825A、PP835A、PP845A、PP865A
显示尺寸3,8“5,7”6,5”10,4“15”
分辨率：320 x 240像素320 x 240象素640 x 480象素800 x 600象素1024 x 768象素
交互类型电阻触摸电阻触摸电阻式触摸电阻式接触电阻式触摸
发光二极管-
功耗（正常/大）0,15 A 0,25 A 0,4 A/0,9 A 0,5 A/1 A 1,2 A/1

Woodward 9906-124

Woodward 9906-124

e in place.
If necessary, push up on the locking tab to lock.
6 ControlNet Modular Repeater Medium-distance Fiber Module
9904-5.4 — February 1998
5. Remove the protective backplane cap as shown in “Removing the
Protective Caps” on page 7.
6. Once attached to the DIN rail, slide modules to the left to mate with
the repeater adapter or another repeater module.
30043–M
!
ATTENTION: Make certain that the adapter and repeater
modules are secured together with DIN rail anchors.
Failure to do so may result in the loss of communications
and/or cause damage to the modules.
The total number of modules that can be attached to the repeater adapter
can not exceed four or the total power consumption of the modules can
not exceed 1.6A @ 5VDC, whichever comes first.
Important: If you exceed the module or power limit, you may cause
damage to the repeater adapter and modules.
Important: If this is the right–most module, a DIN rail latch must be
used on the right–side of the fiber module.
7. Connect the module wiring as shown in “Wiring The Fiber Module”Display backlight CCFL/LED backlight with dimming function
CPU 316 or 416 MHz RISC CPU (Intel Xscale)
Memory, flash 32 MB (Intel StrataFlash)
Memory, RAM 64 MB
Flash memory for application 12 MB
Real time clock YES
Power supply +24 C14 20-30 V
Ambient temperature 0 ° to +50 °C
Relative humidity 5 - 85 % non-condensing
Housing material Powder-coated aluminium
Front side material Autotex F250 / F157 (keyboard), (PP865S in Stainless Steel 316/1.4401)
Peripherals
Serial Ports RS422/RS485, female, 25-pin D-Sub, RS232C, male, 9-pin D-Sub
Ethernet Shielded RJ45 10/100 Mbit/sec
USB Host type A (power consumption max. 500 mA), Device type B
PROFIBUS Expansion slot for PROFIBUS DP
Environmental Data for Panel 800
Climatic Operating Conditions Vertical installation: 0 ° to +50 °C
Horizontal installation: 0 ° to +40 °C
Storage temperature -20 °C to +70 °C
Relative humidity 5 - 85 % non-condensed
Protection class Front panel seal IP 66
Rear panel seal IP 20
Electromagnetic Compatibility and CE-mark Meets EMC directive 2004/108/EC
Electromagnetic Emission Tested according to EN61000-6-4 (2007)
Electromagnetic Immunity Tested according to EN61000-6-2 (2005)
Electrical Safety UL508
Hazardous Classified Locations UL 1604 Class I, Div 2 Groups A, B, C, D, T4
Marine Certificates ABS, DNV, GL, RINA
Specifications PP820A PP826A PP836A PP846A
Display size - 5,7" 6,5" 10,4"
Active area of display, W x H 127,0 x 33,8 mm
Resolution 240 x 64 pixels 320 x 240 pixels 640 x 480 pixels 800 x 600 pixels
Interaction type Function key Function key Function key Function key
LED 16 (2 color) 16 (2 color) 16 (2 color) 20 (2 color)
Power consumption (normal/max) 0,15 A 0,3 A 0,4 A / 0,9 A 0,5 A / 1 A
Dimensions
Front panel, W x H x D 202 x 187 x 57 mm 275 x 168 x 57 mm 285 x 177 x 60 mm 382 x 252 x 60 mm
Cut-out dimensions 166 x 149 mm 240 x 130 mm 246 x 139 mm 343 x 208 mm
Mounting depth 57 mm 58 mm 55 mm 58 mm
Weight 0,875 kg 1,11 kg 1,3 kg 2,3 kg
Specifications PP815A PP825A PP835A PP845A PP865A
Display size 3,8" 5,7" 6,5" 10,4" 15"
Resolution 320 x 240 pixels 320 x 240 pixels 640 x 480 pixels 800 x 600 pixels 1024 x 768 pixels
Interaction type Resistive Touch Resistive Touch Resistive Touch Resistive Touch Resistive Touch
LED - - - - -
Power consumption (normal/max) 0,15 A 0,25 A 0,4 A / 0,9 A 0,5 A / 1 A 1,2 A / 1
