Modbus RTU/TCP
黄金RX/PX/CX/SD，第三代C/D
适用于程序版本1.05及更新版本
概述
ModBus可以访问单个地址或多个地址
同时读取或写入单个位值
或16位值。
ModBus地址包含1位离散值或
16位整数值。
ModBus数据格式
ModBus数据类型为1位值和16位值。
支持的ModBus命令
GOLD空气处理单元支持这些ModBus命令。
存在多个寄存器
GB.ModBus480.120417
16
读取线圈状态
读取输入状态
读保持寄存器
读取输入型寄存器
单线圈力
当前单个寄存器
诊断。仅子功能00-返回查询数据（循环）。
01
02
03
04
强迫多结肠
05
06
08
15
离散输入
16位输出寄存器
16位输入寄存器
0x
1x
4x
3x
ModBus类型描述参考
作用
密码
描述
大肠杆菌状态
输入状态
持有登记簿
输入寄存器
离散输出
运行模式1 3x0085抽气过滤器压力等级3x0053 EA/室温3x0029
通信操作模式4x0175 EA过滤器压力水平限制3x0054 EA/室温设定点4x0042
运行模式2 3x0086 SA小温度设定点4x0043
操作输出1x0008 SA高温度设定点4x0044
低速输出1x0004 EA管道压力3x0007
高速输出1x0005 EA低速压力设定点4x0013
风门输出1x0009 EA高速压力设定值4x0014 SA管道压力3x0005
当前跳闸报警3x0079 SA低速压力设定值4x0009
A-报警1x0006 SA高速压力设定点4x0010
B-报警1x0007
报警复位0x0001
SA温度3x0028
SA温度设定点4x0041
EA气流3x0003 ERS 1差异4x0033
EA风机等级3x0014
EA低速气流设定值4x0005
EA高速气流设定点4x0006
室外温度3x0030
供气过滤器压力等级3x0050
SA过滤器压力等级限制3x0051
换热调节器3x0091
SA气流3x0001
