5X00031H08模块备件

5X00031H08

预先配置的用户可选测量
简化软件配置的类型
„密码保护，具有4个用户登录级别
用于定制访问
„上下文相关帮助消息地址
快速设置问题
„包括趋势、时间函数和顺序
分析和启动/滑行数据
用于全面设置。
„配置包括设置
基本预测能力，包括
故障排除和诊断主配置窗口
应用
用于机械保护的AMS 6500配置软件
允许您配置保护模块，实时查看
振动监测系统和传感器健康。
直观的配置过程从选择卡开始
类型接下来，配置软件提供了一个简单的表格
查看所有配置设置可见。选项卡帮助您排序
输入、输出和级机器之间的信息
诊断和管理任务。允许范围为：
对于每个必需的条目都可见，以帮助您了解
参数的边界。预设参数是自动设置的
使用艾默生传感器和转换器时加载。
系统配置期间可以显示实时数据
验证接线、板卡设置和仪表是否
健康且配置正确。实时信息，如
作为间隙电压、波形数据和整体振动数据
是可见的。
持续维护功能，如复位闭锁
可以轻松执行继电器或加载保存的配置
从软件。该软件可以在个人电脑或笔记本电脑上运行。
使用系统配置软件，以下监视器
可以配置A6000系列的：
A6110、A6120、A6125、A6140、A6150、A6151、A6210、A6220，
A6310、A6312、A6312-8、A6410、A6620、A6630、A6740，
A6740-10、A6824、A6824R
基本预测能力
AMS 6500配置软件具有内置功能
对于一些允许基本故障排除和预测的趋势
机器的。主要价值趋势显示为图形
表示以及卡运行状况和报警值。这个
软件显示振动信号的时间函数
FFT分析数据具有达400行的分辨率和FFT
相位数据。软件还显示上次启动或滑行
机器下面。配置软件可视化
数据和显示sp

5X00031H08

5X00031H08

Pre-configured user-selectable measurement types simplify software configuration „ Password protected with 4 user login levels for customized access „ Context-sensitive help messages address setup questions quickly „ Includes trend, time function, order analysis and startup/coast down data for comprehensive setup. „ Configuration includes setup for basic prediction capabilities, including troubleshooting and diagnostics Main Configuration Window Application The AMS 6500 configuration software for machinery protection allows you to configure protection modules, view real-time vibration monitor system and sensor health. The intuitive configuration process starts by selecting a card type. Next, the configuration software presents a simple tabular view with all configuration settings visible. Tabs help you sort information between inputs, outputs, advanced machine diagnostics and administrative tasks. Permissible ranges are visible for every required entry to help you understand the bounds of parameters. Preset parameters are automatically loaded when Emerson sensors and convertors are used. Real-time data can be displayed during system configuration to verify that wiring, card settings, and instrumentation are healthy and configured properly. Real-time information such as gap voltages, waveform data, and overall vibration data are viewable. On-going maintenance functions, such as resetting latching relays or loading a saved configuration, can be easily performed from the software. The software can run on PCs or laptops. With the system configuration software, the following monitors of the A6000 family can be configured: A6110, A6120, A6125, A6140, A6150, A6151, A6210, A6220, A6310, A6312, A6312-8, A6410, A6620, A6630, A6740, A6740-10, A6824, A6824R Basic Prediction Capabilities The AMS 6500 configuration software has built-in capabilities for some trends that allow basic troubleshooting and prediction of the machinery. The main value trend shows a graphical representation along with card health and alarm values. The software displays the time function of the vibration signal, the FFT analysis date with up to 400 lines resolution and the FFT phase data. The software also displays the last startup or coast down of the machine. The configuration software visualizes the data and shows sp
