1C31129G05模块备件

1C31129G05

VMEbus 2EST性能
2eSST协议提供了可用的VME总线
带宽敢达320MB/s，增加了8倍
通过VME64，同时保持向后兼容性
与VME64和VME32的组合
新的德州仪器VMEbus收发器和
Tundra Tsi148 VMEbus桥的遗留协议
支持允许客户集成MVME7100
串联到现有的基础设施中，提供
向后兼容性，从而保持其
对现有VMEbus板、背板的投资，
机箱和软件。
平衡性能
MVME7100系列不仅速度更快
VMEbus传输速率；它提供了平衡的性能
来自处理器、内存子系统、本地总线
以及I/O子系统。这加上大量的I/O
接口使MVME7100系列非常适合用作
特定于应用程序的计算刀片，或智能
I/O刀片/托架。飞思卡尔MPC864xD片上系统（SoC）处理器运行速度高达1.3 GHz，
非常适合I/O和数据密集型应用。
集成SoC设计创建了I/O密集型
先进的封装，结合双低
具有片上二级缓存和
双集成DDR2内存控制器，PCI
快速、DMA、以太网和本地设备I/O。这个
片上PCI Express接口和双DDR2存储器
总线与处理器匹配良好。确保
佳I/O性能，8x PCI Express端口为
连接到五端口PCI Express交换机。三个4x
PCI Express端口连接到PCI Express-to-PCI-X
提供独立PCI-X总线的网桥
两个PMC-X站点和VME总线接口。1x PCI
Express端口连接到PCI Express到PCI桥
其连接到USB芯片（商用
仅温度）。MVME7100还提供四路
千兆以太网接口、USB 2.0和五（5）个
RS-232串行连接。所有这些加起来就是一组
平衡良好、高性能的子系统
提供无与伦比的性能。

1C31129G05

1C31129G05

VMEbus 2eSST Performance The 2eSST protocol offers an available VME bus bandwidth of up to 320MB/s, an increase of up to 8x over VME64, while maintaining backward compatibility with VME64 and VME32. The combination of the latest Texas Instruments VMEbus transceivers and the Tundra Tsi148 VMEbus bridge’s legacy protocol support allows customers to integrate the MVME7100 series into their existing infrastructure providing backward compatibility and thereby preserving their investment in existing VMEbus boards, backplanes, chassis and software. Balanced Performance The MVME7100 series provides more than just faster VMEbus transfer rates; it provides balanced performance from the processor, memory subsystem, local busses and I/O subsystems. This coupled with a wealth of I/O interfaces make the MVME7100 series ideal for use as an application-specific compute blade, or an intelligent I/O blade/carrier. The Freescale MPC864xD system-onchip (SoC) processor, running at speeds up to 1.3 GHz, is well-suited for I/O and data-intensive applications. The integrated SoC design creates an I/O intensive state-of-the-art package that combines dual low power processing cores with on-chip L2 cache and dual integrated DDR2 memory controllers, PCI Express, DMA , Ethernet and local device I/O. The on-chip PCI Express interface and dual DDR2 memory busses are well matched to the processor. To ensure optimal I/O performance, the 8x PCI Express port is connected to a five-port PCI Express switch. Three 4x PCI Express ports are connected to PCI Express-to-PCI-X bridges which provide independent PCI-X busses for the two PMC-X sites and VME bus interface. A 1x PCI Express port is connected to a PCI Express-to-PCI bridge which is connected to the USB chip (commercial temperature only). The MVME7100 also offers quad Gigabit Ethernet interfaces, USB 2.0, and five (5) RS-232 serial connections. All of this adds up to a set of well-balanced, high-performance subsystems offering unparalleled performance.
