VMEbus 2EST性能
MVME6100系列是一台采用Tundra Tsi148设计的VMEbus单板计算机（SBC）™ VME总线
提供2EST VMEbus性能的接口芯片。2eSST（双边缘源同步传输）协议
导致VMEbus在大多数情况下以320MB/s的实际带宽运行。2eSST协议已经存在了
一段时间后（试用标准草案于1999年发布，并于2003年作为ANSI标准发布），但
到目前为止，2EST板无法在标准VMEbus背板中工作，因为现有的VMEbus收发器
无法支持所需的VMEbus 2EST信令速度。德州仪器公司开发了新的VMEbus
支持2eSST协议要求的VMEbus信号交换速度的收发器。组合
新的德州仪器VMEbus收发器和Tsi148 VMEbus传统协议支持允许客户：
将MVME6100系列集成到其现有基础设施中，提供向后兼容性，从而
保留对现有VMEbus板、背板、机箱和软件的投资。
平衡性能
MVME6100系列不仅提供更快的VMEbus传输速率；它从以下方面提供了平衡的性能：
处理器、内存子系统、本地总线和I/O子系统。运行速度为1.267 GHz的处理器为：
非常适合数据密集型应用。先进的主机桥，支持133 MHz主机总线和133
MHz DDR存储器总线与处理器很好地匹配。为了确保MVME6100系列能够处理
320MB/s数据速率为2EST，Tsi148 VMEbus接口芯片连接到上的133 MHz PCI-X总线之一
主桥。二条PCI-X总线有两个PMC-X站点，每个站点支持PMC或PMC-X卡，支持：
PCI总线速度从33到100MHz。MVME6100还提供双千兆以太网接口。所有这些加起来
为一组平衡良好、高性能的子系统提供无与伦比的性能。
应用优势：国防和航空
在国防和航空航天市场，MVME6100系列非常适合指挥和控制
使用商业级产品的应用，如海军防护系统、固定地面系统和
侦察机系统。MVME6100系列有助于为这些应用程序提供更高的性能
比以前的VME解决方案能够通过使用1.267GHz处理器提供的性能更高。这与双重
PCI-X总线能够为PMC模块提供100 MHz的速度，VME带宽增加8倍，消除了许多
当今指挥和控制解决方案面临的瓶颈。这些应用程序现在可以利用
密集计算配置中的新PowerPC处理器，无需尝试冷却
多处理器板和管理I/O和VME瓶颈。随着摩托罗拉处理器PMC的加入
（PrPMCs），可以为多处理器解决方案添加其他与PowerPC体系结构兼容的处理器
而不牺牲MVME6100系列的任何优点。
