1X00093G05模块备件

1X00093G05

lel端口功率要求
（安装了IPMC的MVME6100上的额外电力负荷）
转换模块I/O连接器
板尺寸
所有模块环境安全
所有印刷线路板（PWB）的制造均具有易燃性
UL认可制造商的额定值为94V-0。
电磁兼容性（EMC）
拟用于满足以下规定的系统：
摩托罗拉计算机集团主板产品在
代表系统符合以下标准，结果待定：
控制器：PC97307
配置：8位双向，完全支持IEEE 1284；
Centronics兼容（减去EPP和
MVME712M上的ECP）
模式：仅主模式
IPMC761 IPMC712
+5V：大0.5A.大0.5A。
+3.3V：大0.75A.大0.75 A。
MVME761 MVME712M
异步串行端口：两个DB-9标记为COM1和COM2三个DB-25标记为串行1、串行2和串行3
同步串行端口：两个，HD-26标记为串行3和串行4（用户可通过安装SIMs进行配置）；
MVME761平面上的两个60针连接器用于
安装两个模拟仪表
一个，DB-25标记为序列4
并行端口：HD-36，与Centronics兼容D-36，Centronics兼容性
以太网：10BaseT或100BaseTX，RJ-45不可用
SCSI：8位或16位、50针或68针连接器，通过P2适配器8位、标准SCSI D-50
高度：233.4毫米（9.2英寸）
深度：80.0毫米（3.1英寸）
前面板高度：261.8毫米（10.3英寸）
前面板宽度：MVME761:19.8毫米（0.8英寸）
MVME712M:39.6毫米（1.6英寸）
运行和非运行
温度：0°C至+55°C
（进气温度。
带强制空气冷却）
-40°C至+85°C
湿度（NC）：5%-90%5%-90%
振动：2 Gs RMS，
20-2000赫兹随机
6GS RMS，
20-2000赫兹随机
U、 S.：FCC15部分B子部分，A类（非住宅）
加拿大：ICES-003，A类（非住宅）
符合欧洲EMC指令89/336/EEC的CE标志
修正案；排放：EN55022 B类；抗扰度：EN55024
www.motorola.com/computer
摩托罗拉计算机集团
区域办事处
北美：亚利桑那州坦佩市1 800 759 1107或+1 602 438 5720
欧洲：英国拉夫堡+44 1509 634300
东地中海：以色列特拉维夫+972 3 568 4388
亚洲：中国上海+86 21 5292 5693
环太平洋地区：日本东京+81 3 5424 3101
亚太地区：香港+852 2966 3210
订购信息
订购信息
零件号说明
MVME6100-0161 1.267 GHz MPC7457处理器，512MB DDR内存，128MB闪存，扫描处理
MVME6100-0163 1.267 GHz MPC7457处理器，512MB DDR内存，128MB闪存，IEEE手柄
MVME6100-0171 1.267 GHz MPC7457处理器，1GB DDR内存，128MB闪存，扫描处理
MVME6100-0173 1.267 GHz MPC7457处理器，1GB DDR内存，128MB闪存，IEEE手柄
相关产品
PMCSPAN2-002带IEEE喷射器手柄的主PMCSPAN
PMCSPAN2-010带IEEE喷射器手柄的辅助PMCSPAN
PMCSPAN 1-002带SCANBE推出器手柄的主PMCSPAN
PMCSPAN 1-010带SCANBE推出器手柄的辅助PMCSPAN
速度：DDR266（133 MHz）
容量：高达2GB，板上所有内存
配置：两个存储体，512MB或1GB配置
发布时可用
类型：EEPROM，板载可编程
容量：128MB焊接闪存在两排
每个64MB
写保护：闪存可通过跳线进行写保护
容量：32KB（用户可用4KB）
电池储存寿命：55℃下50年
电池容量寿命：25°C下100%工作循环下5年
可拆卸电池：是
符合性：ANSI/VITA 1-1994 VME64（IEEE标准
1014），ANSI/VITA 1.1-1997 VME64
扩展，VITA 1.5-199x 2EST
控制器：Tundra Tsi148
DTB主机：A16、A24、A32、A64；D08-D64，SCT，BLT，
MBLT，2eVME，2eSST
DTB从站：A16、A24、A32、A64；D08-D64，SCT，BLT，
MBLT、2eVME、2eSST、UAT
仲裁人：RR/PRI
打断
处理器/生成器：
IRQ 1-7/七个IRQ中的任何一个
系统控制器：是，可跳转或自动检测
位置监视器：两个，LMA32
MVME6100系列5
以太网接口
异步串行端口
双IEEE P1386.1 PCI夹层卡插槽
PCI扩展连接器
计数器/定时器
板尺寸和重量
功率要求
平均无故障时间
178403小时，使用Bellcore标准：6期方法1计算，
案例3
IPMC模块PMC接口
SCSI总线
注：16位SCSI操作不允许使用某些PMC插槽2
信号。
异步串行端口
同步串行端口
控制器：集成到主机中的以太网控制器
桥两个千兆以太网接口
接口速度：10/100/1000Mb/s
连接器：一个接至前面板RJ-45；一
布线至前面板RJ-45或可选
路由至P2（10/100路由至RJ-45
用于IPMC模式的MVME761，千兆位路由
至P2用于PMC模式）
控制器：ST16C554DCQ64
端口数量：两个，16550兼容
配置：EIA-574 DTE
异步波特率，b/s
大值。：
38.4K EIA-232，115Kb/s原始数据
连接器：一个接至前面板RJ-45；一对
平面供开发使用
地址/数据：A32/D32/D64，PMC PN1，PN2，PN3，PN4
连接器
PCI总线时钟：33 MHz、66 MHz或100 MHz
信号：3.3V，5V耐受
电源：+3.3V、+5V、±12V
模块类型：两个单宽或一个双宽，正面
面板或P2 I/O、PMC和PrPMC支持
地址

1X00093G05

1X00093G05

lel Port Power Requirements
(Additional power load placed on MVME6100 with IPMC installed)
Transition Modules I/O Connectors
Board Size
All Modules Environmental Safety
All printed wiring boards (PWBs) are manufactured with a flammability
rating of 94V-0 by UL recognized manufacturers.
Electromagnetic Compatibility (EMC)
Intended for use in systems meeting the following regulations:
Motorola Computer Group board products are tested in a
representative system to the following standards, results pending:
Controller: PC97307
Configuration: 8-bit bi-directional, full IEEE 1284 support;
Centronics compatible (minus EPP and
ECP on MVME712M)
Modes: Master only
IPMC761 IPMC712
+5V: 0.5 A max. 0.5 A max.
+3.3V: 0.75 A max. 0.75 A max.
MVME761 MVME712M
Asynchronous Serial Ports: Two, DB-9 labeled as COM1 and COM2 Three, DB-25 labeled as Serial 1, Serial 2 and Serial 3
Synchronous Serial Ports: Two, HD-26 labeled as Serial 3 and Serial 4 (userconfigurable via installation of SIMs);
two 60-pin connectors on MVME761 planar for
installation of two SIMs
One, DB-25 labeled as Serial 4
Parallel Port: HD-36, Centronics compatible D-36, Centronics compatible
Ethernet: 10BaseT or 100BaseTX, RJ-45 Not available
SCSI: 8- or 16-bit, 50- or 68-pin connector via P2 adapter 8-bit, standard SCSI D-50
Height: 233.4 mm (9.2 in.)
Depth: 80.0 mm (3.1 in.)
Front Panel Height: 261.8 mm (10.3 in.)
Front Panel Width: MVME761: 19.8 mm (0.8 in.)
MVME712M: 39.6 mm (1.6 in.)
Operating Non-operating
Temperature: 0° C to +55° C
(inlet air temp.
w/forced air cooling)
–40° C to +85° C
Humidity (NC): 5% to 90% 5% to 90%
Vibration: 2 Gs RMS,
20-2000 Hz random
6 Gs RMS,
20-2000 Hz random
U.S.: FCC Part 15, Subpart B, Class A (non-residential)
Canada: ICES-003, Class A (non-residential)
CE Mark per European EMC Directive 89/336/EEC with
Amendments; Emissions: EN55022 Class B; Immunity: EN55024
www.motorola.com/computer
Motorola Computer Group
Regional Offices
NORTH AMERICA: Tempe, AZ 1 800 759 1107 or +1 602 438 5720
EUROPE: Loughborough, UK +44 1509 634300
EAST MEDITERRANEAN: Tel Aviv, Israel +972 3 568 4388
ASIA: Shanghai, China +86 21 5292 5693
PACIFIC RIM: Tokyo, Japan +81 3 5424 3101
ASIA/PACIFIC: Hong Kong +852 2966 3210
Ordering Information
ORDERING INFORMATION
Part Number Description
MVME6100-0161 1.267 GHz MPC7457 processor, 512MB DDR memory, 128MB Flash, Scanbe handles
MVME6100-0163 1.267 GHz MPC7457 processor, 512MB DDR memory, 128MB Flash, IEEE handles
MVME6100-0171 1.267 GHz MPC7457 processor, 1GB DDR memory, 128MB Flash, Scanbe handles
MVME6100-0173 1.267 GHz MPC7457 processor, 1GB DDR memory, 128MB Flash, IEEE handles
Related Products
PMCSPAN2-002 Primary PMCSPAN with IEEE ejector handles
PMCSPAN2-010 Secondary PMCSPAN with IEEE ejector handles
PMCSPAN1-002 Primary PMCSPAN with SCANBE ejector handles
PMCSPAN1-010 Secondary PMCSPAN with SCANBE ejector handles
Speed: DDR266 (133 MHz)
Capacity: Up to 2GB, all memory on board
Configurations: Two banks, 512MB or 1GB configurations
available at release
Type: EEPROM, on-board programmable
Capacity: 128MB soldered Flash in two banks of
64MB each
Write Protection: Flash is write protectable via jumper
Capacity: 32KB (4KB available for users)
Cell Storage Life: 50 years at 55° C
Cell Capacity Life: 5 years at 100% duty cycle, 25° C
Removable Battery: Yes
Compliance: ANSI/VITA 1-1994 VME64 (IEEE STD
1014), ANSI/VITA 1.1-1997 VME64
Extensions, VITA 1.5-199x 2eSST
Controller: Tundra Tsi148
DTB Master: A16, A24, A32, A64; D08-D64, SCT, BLT,
MBLT, 2eVME, 2eSST
DTB Slave: A16, A24, A32, A64; D08-D64, SCT, BLT,
MBLT, 2eVME, 2eSST, UAT
Arbiter: RR/PRI
Interrupt
Handler/Generator:
IRQ 1-7/Any one of seven IRQs
System Controller: Yes, jumperable or auto detect
Location Monitor: Two, LMA32
MVME6100 Series 5
Ethernet Interface
Asynchronous Serial Ports
Dual IEEE P1386.1 PCI Mezzanine Card Slots
PCI Expansion Connector
Counters/Timers
Board Size and Weight
Power Requirements
Mean Time Between Failure
178,403 hours, calculated using Bellcore Standard: Issue 6, Method 1,
Case 3
IPMC Modules PMC Interface
SCSI Bus
Note: 16-bit SCSI operation precludes the use of some PMC slot 2
signals.
Asynchronous Serial Ports
Synchronous Serial Ports
Controller: Ethernet controller integrated into host
bridge; two Gigabit Ethernet interfaces
Interface Speed: 10/100/1000Mb/s
Connector: One routed to front panel RJ-45; one
routed to front panel RJ-45 or optionally
routed to P2 (10/100 routed to RJ-45 on
MVME761 for IPMC mode, Gigabit routed
to P2 for PMC mode)
Controller: ST16C554DCQ64
Number of Ports: Two, 16550 compatible
Configuration: EIA-574 DTE
Async Baud Rate, b/s
max.:
38.4K EIA-232, 115Kb/s raw
Connector: One routed to front panel RJ-45; one on
planar for development use
Address/Data: A32/D32/D64, PMC PN1, PN2, PN3, PN4
connectors
PCI Bus Clock: 33 MHz, 66 MHz or 100 MHz
Signaling: 3.3V, 5V tolerant
Power: +3.3V, +5V, ±12V
Module Types: Two single-wide or one double-wide, front
panel or P2 I/O, PMC and PrPMC support
Address/Data: A32/D32/D64
PCI Bus Clock: 33/66 MHz
Signaling: 5V
Power: +3.3V, +5V, ±12V
Connector: 114-pin connector located on MVME6100
planar, same location as on MVME5500
planar
TOD Clock Device: ST (SGS-Thompson) M4T28
Real-Time
Timers/Counters:
Four, 32-bit programmable
Watchdog Timer: Time-out generates reset
Height: 233.4 mm (9.2 in.)
Depth: 160.0 mm (6.3 in.)
Front Panel Height: 261.8 mm (10.3 in.)
Width: 19.8 mm (0.8 in.)
Max. Component
Height:
14.8 mm (0.58 in.)
Weight: 425 g/15 oz. (Scanbe handles); 468 g/16.5
oz. (IEEE handles)
(Not including power required by PMC or IPMC modules)
+5V ± 5%
MVME6100: 8.4 A typ., 10.2 A max.
MVME6100 with
MVME761:
9.2 A typ., 11.2 A ma
