如MOTLoad固件包用户手册中所述，在
附录C，相关文档，远程启动允许用户获得
有关目标板的信息，下载代码和/或数据，修改
并执行下载的程序。这些
在MVME6100的情况下，事务发生在VMEbus上。
MOTLoad使用Tsi148 VME控制器中的四个邮箱之一作为
主机和之间的板间通信地址（IBCA）
目标
由MOTLoad配置的CR/CSR从属地址根据以下分配：
连接到背板中的安装插槽，如VME64所示
规格以下数值仅供参考：
有关CR/CSR空间的更多详细信息，请参阅VME64
附录C相关文件中列出的规范。
MVME6100使用Discovery II作为其VME网桥。偏移量
Discovery II用户手册中定义了Discovery II中的邮箱，
插槽位置CS/CSR起始地址
1 0x0008.0000
2 0x0010.0000
3 0x0018.0000
4 0x0020.0000
5 0x0028.0000
6 0x0030.0000
7 0x0038.0000
8 0x0040.0000
9 0x0048.0000
A 0x0050.0000
B 0x0058.0000
C 0x0060.0000
3-20计算机组文献中心网站
非负载固件
3.
在附录C相关文件中列出，但此处注明
参考：
邮箱0位于CR/CSR空间中的偏移量7f348处
邮箱1位于CR/CSR空间中的偏移量7f34C处
邮箱2位于CR/CSR空间中的偏移量7f350处
邮箱3位于CR/CSR空间中的偏移量7f354处
在个人上选择远程启动使用的邮箱
MVME6100由全局环境变量的设置确定
（GEV）。默认邮箱为零。另一个GEV控制是否
远程启动已启用（默认）或禁用。请参阅远程启动
MOTLoad固件包远程用户手册中的附录
从GEV定义开始。
MVME6100的IBCA需要通过
大师的VMEbus桥。例如，要使用远程启动，请使用邮箱
0在插槽5中安装的MVME6100上，主机将需要映射
支持在VME CR/CSR空间中读取和写入地址0x002ff348
（0x280000+0x7f348）。
备用启动映像和安全启动
一些更高版本的MOTLoad支持备用启动映像和
安全启动恢复程序。如果安全启动在
MVME6100，支持备用启动映像。带备用靴子
映像支持，引导块中的引导加载程序代码检查
8MB的闪存库，用于备用启动映像。如果找到图像，
控制传递给图像。
复位后的固件启动顺序
MOTLoad复位后的固件启动顺序为：
❏ 初始化缓存、MMU、FPU和其他CPU内部项
❏ 初始化内存控制器
