KJ3004X1-EA1模块备件

KJ3004X1-EA1

KJ4001X1-CK1 40引脚质量接线板
危险大气
二、3g
EEx nA IIC T4
Nemko No.02ATEX431U
功率规格
输入30 VDC，每个通道1 A
环境规范
环境温度0至70摄氏度
冲击10 g半正弦波持续11 ms
振动1 mm，从2到
13.2Hz；0.7 g，从13.2到150 Hz
空运的
污染物
ISA-S71.04–1985机载
G3类污染物
相对湿度5-95%，不冷凝，IP 20
评级
注：序列号参见产品标签
以及制造地点和日期。还参考
板卡左侧的接线图。
警告：本产品具有以下特定说明：
危险环境中的安装、拆除和操作
地区。参考文件12P2046，DeltaV
可扩展工艺系统2区安装
说明书其他安装说明包括：
可在“安装您的DeltaV自动化”中找到
系统手册。
移除和插入
旋转键控系统确保兼容性
I/O卡和接线板之间
安装完成。该接线盒必须：
为要使用的I/O卡设置密钥
具有
维护和调整
该装置不包含用户可维修部件，并且
不得因任何原因拆卸。
不需要校准。
其他安全批准

KJ3004X1-EA1

KJ3004X1-EA1

KJ4001X1-CK1 40-Pin Mass Termination Block Hazardous Atmosphere II 3 G EEx nA IIC T4 Nemko No. 02ATEX431U Power Specifications Input 30 VDC at 1 A per channel Environmental Specifications Ambient Temperature 0 to 70 oC Shock 10 g half-sine wave for 11 ms Vibration 1 mm peak to peak from 2 to 13.2 Hz; 0.7 g from 13.2 to 150 Hz Airborne Contaminants ISA-S71.04 –1985 Airborne Contaminants Class G3 Relative Humidity 5 to 95% Non-Condensing IP 20 Rating Note: Refer to the product label for serial number and location and date of manufacture. Refer also to the wiring diagram on the left side of the card. Warning: This product has specific instructions for installation, removal and operation in hazardous areas. Refer to document 12P2046, DeltaV  Scalable Process System Zone 2 Installation Instructions. Other installation instructions are available in the Installing Your DeltaV Automation System manual. Removal and Insertion A rotary keying system ensures compatibility between I/O cards and terminal blocks after installation is complete. This terminal block must have the keys set for the I/O card it is to be used with. Maintenance and Adjustment This unit contains no user-serviceable parts and should not be disassembled for any reason. Calibration is not required. Other Safety Approvals
