KJ3221X1-BA1模块备件

KJ3221X1-BA1

KJ4001X1-CJ1 32通道接线盒
危险大气
二、3g
Nemko No.02ATEX431U
EEx nA IIC T4
功率规格
额定电压30 VDC
大电流1 A
环境规范
环境温度0至60摄氏度
冲击10g½正弦波持续11毫秒
振动：1毫米，峰间频率为5至16Hz；
0.5g，从16到150Hz
空运的
污染物
ISA-S71.04–1985机载
G3类污染物
相对湿度5-95%，不冷凝，IP 20
评级
注：序列号参见产品标签
以及制造地点和日期。
警告：本产品具有以下特定说明：
危险环境中的安装、拆除和操作
地区。参考文件12P2046“DeltaV
可扩展工艺系统2区安装
其他安装说明包括
在“安装您的DeltaV自动化”中提供
系统”手册。
移除和插入
旋转键控系统确保兼容性
I/O卡和接线板之间
安装完成。该接线盒必须：
为要使用的I/O卡设置密钥
具有
维护和调整
该装置不包含用户可维修部件，并且
不得因任何原因拆卸。
不需要校准。

KJ3221X1-BA1

KJ3221X1-BA1

KJ4001X1-CJ1 32 Channel Terminal Block Hazardous Atmosphere II 3 G Nemko No. 02ATEX431U EEx nA IIC T4 Power Specifications Voltage rating 30 VDC Maximum current 1 A Environmental Specifications Ambient Temperature 0 to 60o C Shock 10g ½ Sinewave for 11 msec Vibration 1mm Peak to Peak from 5 to 16Hz; 0.5g from 16 to 150Hz Airborne Contaminants ISA-S71.04 –1985 Airborne Contaminants Class G3 Relative Humidity 5 to 95% Non-Condensing IP 20 Rating Note: Refer to the product label for serial number and location and date of manufacture. Warning: This product has specific instructions for installation, removal and operation in hazardous areas. Refer to document 12P2046 "DeltaV  Scalable Process System Zone 2 Installation Instructions". Other installation instructions are available in the "Installing Your DeltaV Automation System" manual. Removal and Insertion A rotary keying system ensures compatibility between I/O cards and terminal blocks after installation is complete. This terminal block must have the keys set for the I/O card it is to be used with. Maintenance and Adjustment This unit contains no user serviceable parts and should not be disassembled for any reason. Calibration is not required.
