KJ4001X1-CJ1模块备件

KJ4001X1-CJ1

KJ3243X1-BA1系列2 ProfibusDP卡
危险大气
二、3g
Nemko No.02ATEX431U
EEx nA IIC T4
功率规格
600 mA时的本地总线额定功率12 VDC
现场电路功率per
卡片
没有一个
环境规范
环境温度-40至70摄氏度
冲击10g½正弦波持续11毫秒
振动：1毫米，峰间频率为5至16Hz；
0.5g，从16到150Hz
空运的
污染物
ISA-S71.04–1985机载
G3类污染物
相对湿度5-95%，不冷凝，IP 20
评级
接线盒键
位置
D3
注：序列号参见产品标签
以及制造地点和日期。还参考
板卡左侧的接线图。
警告：本产品具有以下特定说明：
危险环境中的安装、拆除和操作
地区。参考文件12P2046“DeltaV™
可扩展工艺系统2区安装
其他安装说明包括
在“安装您的DeltaV自动化”中提供
系统”手册。
移除和插入
此单元不能随系统一起移除或插入
电源已通电。
维护和调整
该装置不包含用户可维修部件，并且
不得因任何原因拆卸。
不需要校准。

KJ4001X1-CJ1

KJ4001X1-CJ1

KJ3243X1-BA1 Series 2 ProfibusDP Card Hazardous Atmosphere II 3 G Nemko No. 02ATEX431U EEx nA IIC T4 Power Specifications LocalBus power rating 12 VDC at 600 mA Field circuit power per card None Environmental Specifications Ambient Temperature -40 to 70 o C Shock 10g ½ Sinewave for 11 msec Vibration 1mm Peak to Peak from 5 to 16Hz; 0.5g from 16 to 150Hz Airborne Contaminants ISA-S71.04 –1985 Airborne Contaminants Class G3 Relative Humidity 5 to 95% Non-Condensing IP 20 Rating Terminal block key position D3 Note: Refer to the product label for serial number and location and date of manufacture. Refer also to the wiring diagram on the left side of the card. Warning: This product has specific instructions for installation, removal and operation in hazardous areas. Refer to document 12P2046 "DeltaV ™ Scalable Process System Zone 2 Installation Instructions". Other installation instructions are available in the "Installing Your DeltaV Automation System" manual. Removal and Insertion This unit cannot be removed or inserted with system power energized. Maintenance and Adjustment This unit contains no user serviceable parts and should not be disassembled for any reason. Calibration is not required.
