KJ3242X1-FA1模块备件

KJ3242X1-FA1

订购信息
模拟输入卡和接线板
描述型号
8信道4-20 mA，HART
标准I/O接线盒VE4003S2B1
冗余标准I/O接线盒VE4033S2B1
带保险丝的I/O接线盒VE4003S2B2
四线I/O接线盒VE4003S2B3
16引脚质量接线盒VE4003S2B4
24针质量接线盒VE4003S2B5
16信道4-20 ma，HART，Plus卡
系列2加上VE4003S2B9的16通道2线AI接线板
系列2加上VE4003S2B10的16通道4线AI接线板
用于系列2和VE4033S2B10的冗余16通道2线和4线AI接线盒
系列2 Plus的48针AI质量接线板（与DeltaV信号调节卡一起使用，用于：
用于DeltaV DCS的PLC-5 AI或P+F HiD/HiC IS屏障和端子板）
VE4003S2B11
用于系列2 Plus的48引脚AI质量接线板，包括16通道模拟质量连接板*VE4053S2B11
用于系列2 Plus的冗余48针AI质量接线盒（用于DeltaV信号调节
用于PLC-5 AI或P+F HiD/HiC IS屏障的板卡和用于DeltaV DCS的端子板）
VE4033S2B11
用于系列2 Plus的冗余48引脚AI质量接线盒，包括16通道模拟
质量连接板*VE4083S2B11
8通道热电偶，mV
标准I/O接线盒VE4003S4B1
冷端补偿（CJC）接线盒VE4003S5B1
模拟输入卡：8通道RTD
电阻温度装置（RTD）接线盒VE4003S6B1
隔离输入卡
隔离输入端子块VE4003S7B1
*有关质量连接板和连接电缆的更多详细信息，请参阅M系列质量连接解决方案PDS。
DeltaV M系列传统I/O，2022年8月
www.emerson。com/deltav 32
模拟输出卡和接线板
描述型号
8信道4-20 mA，HART
标准I/O终端块VE4005S2B1
冗余标准I/O终端块VE4035S2B1
带保险丝的I/O接线盒VE4005S2B2
16引脚质量接线盒VE4005S2B3
16信道4-20 mA，HART，Plus卡
系列2加上VE4005S2B4的16通道AO接线盒
用于系列2和VE4035S2B4的冗余16通道AO接线盒
系列2 Plus的48引脚AO质量接线盒
（用于P+F HiD或HiC IS屏障和DeltaV DCS的终端板）
VE4005S2B5
用于系列2 Plus的48引脚AO质量接线板，包括16通道模拟质量连接板*VE4055S2B5
用于系列2 Plus的冗余48引脚AO质量接线盒
（用于P+F HiD或HiC IS屏障和DeltaV DCS的终端板）
VE4035S2B5
用于系列2 Plus的冗余48引脚AO质量接线盒，包括16通道模拟
质量连接板*
VE4085S2B5
„8通道接线盒
„熔断8通道接线盒
„AI 8通道接线盒
„2线AI加16通道接线板
„4线AI加16通道接线板
„AO Plus 16通道接线盒
„DI 32通道接线盒
„DI Plus 32通道接线盒
„DO Plus 32通道接线盒
„隔离输入端子排
„RTD/电阻接线盒
„热电偶接线盒
以下冗余I/O端子块可用：
在某些I/O接口上，允许安装一对卡
作为冗余对。
„冗余AI 8通道接线盒
„冗余AI加16通道接线盒
„冗余AO 8通道接线盒
„冗余AO加16通道接线盒
„冗余离散8通道接线盒
„冗余DI加32通道接线盒
冗余DO加32通道接线盒
下页的表列出了兼容的
每个卡的接线板以及卡
独特的关键位置。列出的一个端子排
是推荐的接线板。
除标准信号布线外，某些板卡还可能
订购允许这些卡的大量接线板
连接到M系列质量连接解决方案
或来自Phoenix的三方布线解决方案或if IS屏障
由Pepperl和Fuchs提供，安装在相邻的
满足特殊信号调节或优化的机柜
现场布线解决方案。请参阅联盟计划
网站，以获取关于已批准的三方产品的详细信息。
„10针质量接线盒（仅单工）
„16针质量接线盒（仅单工）
„24针质量接线盒（仅单工）
„40引脚质量接线板（单工和冗余）
„48针质量接线盒（单工和冗余）通道，24V直流，隔离。
DeltaV M系列传统I/O，2022年8月
www.emerson。com/deltav 21
SOE板卡规格，16通道，24V直流，干触点
信道数16
On>2 mA的检测电平
Off＜0.25 mA的检测电平
输入阻抗5K欧姆（近似值）
润湿电压24V DC
所有16个信道的信道扫描速率为0.25毫秒
时间戳精度（仅适用于启用SOE的信道）*0.25毫秒，来自同一板卡
来自同一控制器的1msec
本地总线电流（标称直流12V）75 mA典型值，100

KJ3242X1-FA1

KJ3242X1-FA1

Ordering Information
Analog Input Cards and Termination Blocks
Description Model Number
8 Channels 4-20 mA, HART
Standard I/O Termination Block VE4003S2B1
Redundant Standard I/O Termination Block VE4033S2B1
Fused I/O Termination Block VE4003S2B2
4-wire I/O Termination Block VE4003S2B3
16-Pin Mass Termination Block VE4003S2B4
24-Pin Mass Termination Block VE4003S2B5
16 Channels 4-20 ma, HART, Plus Card
16-Channel 2-Wire AI Terminal Block for Series 2 Plus VE4003S2B9
16-Channel 4-Wire AI Terminal Block for Series 2 Plus VE4003S2B10
Redundant 16-Channel 2- & 4-Wire AI Terminal Block for Series 2 Plus VE4033S2B10
48-pin AI Mass Termination Block for Series 2 Plus (to be used with DeltaV Signal Conditioning Cards for
PLC-5 AI, or P+F HiD/HiC IS barriers and terminal boards for DeltaV DCS)
VE4003S2B11
48-pin AI Mass Termination Block for Series 2 Plus including 16-channel Analog Mass Connection Boards* VE4053S2B11
Redundant 48-pin AI Mass Termination Block for Series 2 Plus (to be used with DeltaV Signal Conditioning
Cards for PLC-5 AI, or P+F HiD/HiC IS barriers and terminal boards for DeltaV DCS)
VE4033S2B11
Redundant 48-pin AI Mass Termination Block for Series 2 Plus including 16-channel Analog
Mass Connection Boards* VE4083S2B11
8 Channels Thermocouple, mV
Standard I/O Termination Block VE4003S4B1
Cold Junction Compensated (CJC) Termination Block VE4003S5B1
Analog Input Card: 8 Channels RTD
Resistant Temperature Device (RTD) Termination Block VE4003S6B1
Isolated Input Card
Isolated Input Terminal Block VE4003S7B1
*For more details on the Mass Connection Boards and connection cables, please refer to the M-series Mass Connection Solutions PDS.
DeltaV M-series Traditional I/O August 2022
www.emerson.com/deltav 32
Analog Output Cards and Termination Blocks
Description Model Number
8 Channels 4-20 mA, HART
Standard I/O Termination Block VE4005S2B1
Redundant Standard I/O Termination Block VE4035S2B1
Fused I/O Termination Block VE4005S2B2
16-Pin Mass Termination Block VE4005S2B3
16 Channels 4-20 mA, HART, Plus Card
16-Channel AO Terminal Block for Series 2 Plus VE4005S2B4
Redundant 16-Channel AO Terminal Block for Series 2 Plus VE4035S2B4
48-pin AO Mass Termination Block for Series 2 Plus
(to be used with P+F HiD or HiC IS barriers and termination boards for DeltaV DCS)
VE4005S2B5
48-pin AO Mass Termination Block for Series 2 Plus including 16-channel Analog Mass Connection Boards* VE4055S2B5
Redundant 48-pin AO Mass Termination Block for Series 2 Plus
(to be used with P+F HiD or HiC IS barriers and termination boards for DeltaV DCS)
VE4035S2B5
Redundant 48-pin AO Mass Termination Block for Series 2 Plus including 16-channel Analog
Mass Connection Boards*
VE4085S2B5
„ 8-Channel terminal block
„ Fused 8-Channel terminal block
„ AI 8-Channel terminal block
„ 2-wire AI Plus 16-Channel terminal block
„ 4-wire AI Plus 16-Channel terminal block
„ AO Plus 16-Channel terminal block
„ DI 32-Channel terminal block
„ DI Plus 32-Channel terminal block
„ DO Plus 32-Channel terminal block
„ Isolated Input terminal block
„ RTD/Resistance terminal block
„ Thermocouple terminal block
The following redundant I/O terminal blocks are available
on some I/O interfaces, allowing a pair of cards to be installed
as a redundant pair.
„ Redundant AI 8-Channel terminal block
„ Redundant AI Plus 16-Channel terminal block
„ Redundant AO 8-Channel terminal block
„ Redundant AO Plus 16-Channel terminal block
„ Redundant Discrete 8-Channel terminal block
„ Redundant DI Plus 32-Channel terminal block
„ Redundant DO Plus 32-Channel terminal block
The table on the following page lists the compatible
terminal blocks for each card, along with the cards
unique key positions. The first terminal block listed
is the recommended terminal block.
In addition to standard signal wiring, some cards may also
be ordered with Mass Terminal blocks that allow these cards
to be connected to the M-series Mass Connection Solutions
or third party wiring solutions from Phoenix or if IS Barriers
are required from Pepperl and Fuchs, mounted in an adjacent
cabinet to meet special signal conditioning or for optimizing
field wiring solutions. Please refer to the Alliance Program
website for details on approved third-party products.
„ 10-pin Mass Termination Block (simplex only)
„ 16-pin Mass Termination Block (simplex only)
„ 24-pin Mass Termination Block (simplex only)
„ 40-pin Mass Termination Block (simplex and redundant)
„ 48-pin Mass Termination Block (simplex and redundant)channel, 24V DC, Isolated.
DeltaV M-series Traditional I/O August 2022
www.emerson.com/deltav 21
Specifications for SOE Card, 16-channel, 24V DC, Dry Contact
Number of Channels 16
Detection Level for On >2 mA
Detection Level for Off <0.25 mA
Input Impedance 5K ohm (approximate)
Wetting Voltage 24V DC
Channel Scan Rate 0.25 msec for all 16 channels
Time Stamp Accuracy (for SOE enabled channels only)* 0.25 msec from same card
1 msec from same controller
LocalBus Current (12V DC nominal) 75 mA typical, 100 mA maximum
Field Circuit Power per Card 75 mA at 24V DC
Isolation Each channel is optically isolated from the system
and factory tested to 1500V DC
