KJ4020X1-BD1模块备件

KJ4020X1-BD1

完整的DeltaV解决方案：从遗留系统迁移
当完成时，你会有一个完整的感觉
DeltaV解决方案，不是标准和自定义的组合
支持的硬件/软件。迁移的每一部分
面板是标准的DeltaV硬件，可以支持
相同的人员和备用设备
CHARMs和DeltaV安装使用。
即插即用I/O:DeltaV CIOC的设计目的是：
在物理安装及其软件工具中易于使用。
部件通过固定的DIN导轨闩锁和
互锁载体连接器。插入魅力和自动
感测节点以在中自动创建I/O定义
您的DeltaV配置数据库。符咒使用自动键控
自动为特定魅力设置频道的系统
类型用户不能错误地将符咒插入错误的
接线板。将所有、一个或任意数量的通道分配给
控制器，只需简单的点击和拖动。
魅力和端子板。
现场电源通过冗余24V直流总线提供给：
每个咒语，每个咒语多100 mA。高电流
离散通道可以通过集成电源供电
每个CHARM底板的局部注射总线。
产品描述
迁移硬件的电子编组包括：
„CHARM I/O载体（DIN导轨安装和支架
冗余的CHARM I/O卡对）。
„CHARM I/O卡（CIOC）提供以下各项之间的通信：
CHARMs和以太网I/O网络连接到M系列、S系列和S系列，
和PK控制器。CIOC有一个致命的弱点：沟通
认证级别1，重新设计的CIOC2有更多
计算能力和阿喀琉斯通信认证
二级。CIOC2是CIOC的替代品。
„CHARM底板（DIN导轨安装，带交错电源
以及总线连接器。支持12个字符及其终端
以及用于注入场功率的连接）。
„CHARM接线盒（可拆卸接线盒
为现场接线提供端子连接，以及
用于魅力的物理闩锁）。
„CHARMs（每个场信号的特征化模块。
提供基本的模数转换、连接
到冗余通信总线和故障隔离）。
DeltaV迁移电子编组2020年8月
www.emerson。com/deltav 3
„在载体安装中提供灵活性的电缆延长线。
„基板终端（为
冗余I/O总线）。
„19“迁移面板（提供两个DIN导轨安装
迁移CIOC或两个基板和电缆延长线
用于安装到标准19“传统机柜中）。
CIOC迁移面板
应安装CHARM I/O卡托架
在垂直DIN导轨上，可与多达
垂直安装或移动安装的八个CHARM底板
并通过延长电缆相互连接。
总线终端连接到后一块基板上。
基板迁移面板
每个CHARMs迁移基板组件为：
订购的预加载有24个接线盒，这些接线盒：
准备接收来自2线、3线和4线设备的现场导线。
电子编组消除了对
现场布线或划分I/O，以使信号与通道匹配
特定卡的类型。只需按顺序连接现场信号
根据需要设计。将适当的符咒插入每个
完成现场电路和信号的接线板
可供任何多达四个控制器使用。
对于每个迁移CIOC安装，您需要：
将数量和连接器电缆长度确定为：
以及适当数量的顶部和/或底部
基板终端。
迁移CIOC组件的高度为6个EIA单元
（10.5英寸），设计为安装在顶部
移民内阁和连接到魅力
穿过电缆和电缆延长线的底板组件。
应注意，CIOC可垂直安装
机柜中任何位置的DIN导轨（正面、背面、侧面、顶部、底部、底部、顶部、顶部），
中间，底部）并连接到CHARM底板
以相同的方式组装。注意：无法安装CIOC
在水平DIN导轨上。
Migration CHARM底板组件的高度为
3个EIA单元（5.25英寸），允许每次安装
以确定每个机柜内的安装位置。
用户可以决定重新使用现有的线路/电缆槽，
相邻安装每个组件，或使用
每个组件之间的间距。三角洲魅力允许
通过允许安装每个组件实现安装灵活性
根据需要实现be

KJ4020X1-BD1

KJ4020X1-BD1

Complete DeltaV solution: Migrate from your legacy system
with the comfort that when complete you will have a complete
DeltaV solution, not a combination of standard and custom
hardware/software to support. Every piece of the migration
panel is standard DeltaV hardware and can be supported with
the same personnel and spare equipment that every other
CHARMs and DeltaV installation uses.
Plug and play I/O: The DeltaV CIOC has been designed for
ease of use, both in physical installation and its software tools.
Components snap together with secure DIN-rail latches and
interlocking carrier connectors. Insert the CHARMs and auto
sense the node to create the I/O definition automatically in
your DeltaV configuration database. CHARMs use a self-keying
system to automatically set a channel for a specific CHARM
type. Users cannot mistakenly insert a CHARM into the wrong
terminal block. Assign all, one, or any number of channels to a
controller with a simple click and drag.
CHARM and Terminal Block.
Field power is provided through a redundant 24V DC bus to
each CHARM, with up to 100 mA per CHARM. Higher current
Discrete Channels can be powered through integrated power
injection bus local to each CHARM Baseplate.
Product Description
Electronic Marshalling for Migrations hardware includes:
„ CHARM I/O Carrier (DIN-rail mounted and supports
redundant pair of CHARM I/O Cards).
„ CHARM I/O Card (CIOC) provides communication between
CHARMs and the Ethernet I/O network to M-series, S-series,
and PK controllers. The CIOC has Achilles Communications
Certification Level 1 and the redesigned CIOC2 has more
computing power and Achilles Communications Certification
Level 2. The CIOC2 is a drop-in replacement for the CIOC.
„ CHARM Baseplate (DIN-rail mounted with interleaving power
and bus connectors. Supports 12 CHARMs and their terminal
blocks, as well as connection for injected field power).
„ CHARM Terminal Block (removable terminal block
providing terminal connections to field wiring and
physical latch for CHARM).
„ CHARMs (Characterization Module for each field signal.
Provides basic analog to digital conversion, connectivity
to redundant communication bus, and fault isolation).
DeltaV Electronic Marshalling for Migrations August 2020
www.emerson.com/deltav 3
„ Cable Extenders that provide flexibility in carrier mounting.
„ Baseplate terminators (provides bus terminations for
redundant I/O bus).
„ 19” Migration Panels (provides DIN-rail mounting for two
migration CIOC’s or two baseplates and cable extenders
for installation into your standard 19” legacy cabinets).
CIOC Migration Panel
The CHARM I/O card carrier is supposed to be mounted
on a vertical DIN-rail and can communicate with up to
eight CHARM Baseplates mounted vertically or on migration
panels and connected to each other through extender cables.
The bus terminators are attached to the last baseplate.
Baseplate Migration Panel
Each CHARMs Migration Baseplate Assembly is
ordered pre-loaded with 24 terminal blocks that are
ready to receive field wires from 2-, 3- , and 4-wire devices.
Electronic Marshalling eliminates the need to scramble the
field wiring or to partition the I/O to match signals to channel
types of specific cards. Simply connect field signals in an orderly
fashion as desired. Insert the appropriate CHARM into each
terminal block to complete the field circuit and the signal
is ready to be used by any, up to four controllers.
For each Migration CIOC installation you will need to
determine the quantity and connector cable length as
well as the appropriate quantity of top and/or bottom
baseplate terminators.
The Migration CIOC assembly has a height of 6 EIA units
(10.5 inches) and is designed to be mounted at the top
of the migration cabinet and connected to the CHARM
baseplate assemblies through the cables and cable extenders.
It should be noted that the CIOC can be mounted on vertical
DIN-rail anywhere in the cabinet (front, back, side, top,
middle, bottom) and connected to the CHARM baseplate
assembly the same way. NOTE: the CIOC cannot be mounted
on a horizontal DIN-rail.
The Migration CHARM baseplate assembly has a height of
3 EIA units (5.25 inches) which allows for each installation
to determine the mounting location within each cabinet.
The user can decide to reuse existing wire way / cable tray,
mount each assembly adjacent to each other, or mount with
spacing between each assembly. DeltaV CHARMs allow for
installation flexibility by allowing each assembly to be mounted
as needed to achieve the be
