KJ4003X1-BD1模块备件

KJ4003X1-BD1

KJ4003X1-BE1右1宽垂直加
载波扩展器
KJ4003X1-BF1左1宽垂直加
载波扩展器
危险大气
二、3g
Nemko No.02ATEX431U
EEx nA IIC T4
功率规格
15 A时的本地总线电源12 VDC
环境规范
环境温度-40至70摄氏度
冲击10g½正弦波持续11毫秒
振动：1毫米，峰间频率为5至16Hz；
0.5g，从16到150Hz
空运的
污染物
ISA-S71.04–1985机载
G3类污染物
相对湿度5-95%，不冷凝，IP 20
评级
注：序列号参见产品标签
以及制造地点和日期。
警告：本产品具有以下特定说明：
危险环境中的安装、拆除和操作
地区。参考文件12P2046“DeltaV™
可扩展工艺系统2区安装
其他安装说明包括
在“安装您的DeltaV自动化”中提供
系统”手册。
移除和插入
此单元不能随系统一起移除或插入
电源已通电。
断开前必须断电
任何载波或本地总线扩展电缆。
不得拔下本产品，除非：
系统已断电或该区域处于：
已知是安全的。没有I/O载体的组合，以及
LocalBus扩展器的长度必须超过6.5
米。外壳之间的互连电缆
必须在导管中。
维护和调整
该装置不包含用户可维修部件，并且
不得因任何原因拆卸。
不需要校准。
其他安全批准

KJ4003X1-BD1

KJ4003X1-BD1

KJ4003X1-BE1 Right 1 Wide VerticalPLUS
Carrier Extender
KJ4003X1-BF1 Left 1 Wide VerticalPLUS
Carrier Extender
Hazardous Atmosphere
 II 3 G
Nemko No. 02ATEX431U
EEx nA IIC T4
Power Specifications
LocalBus Power 12 VDC at 15 A
Environmental Specifications
Ambient Temperature -40 to 70o C
Shock 10g ½ Sinewave for 11 msec
Vibration 1mm Peak to Peak from 5 to 16Hz;
0.5g from 16 to 150Hz
Airborne
Contaminants
ISA-S71.04 –1985 Airborne
Contaminants Class G3
Relative Humidity 5 to 95% Non-Condensing IP 20
Rating
Note: Refer to the product label for serial number
and location and date of manufacture.
Warning: This product has specific instructions for
installation, removal and operation in hazardous
areas. Refer to document 12P2046 "DeltaV ™
Scalable Process System Zone 2 Installation
Instructions". Other installation instructions are
available in the "Installing Your DeltaV Automation
System" manual.
Removal and Insertion
This unit cannot be removed or inserted with system
power energized.
Power must be de-energized before disconnecting
any carriers or LocalBus Extender cables.
This product must not be unplugged unless either
the system has been de-energized or the area is
known to be safe. No combination of I/O carriers and
LocalBus Extenders must exceed a length of 6.5
meters. Interconnecting cable between enclosures
must be in conduit.
Maintenance and Adjustment
This unit contains no user serviceable parts and
should not be disassembled for any reason.
Calibration is not required.
Other Safety Approvals
