EV1000-4T0055G模块备件

EV1000-4T0055G

无以下操作
指示可能导致个人
受伤或死亡。
! 注意操作，无以下操作：
指示可能导致个人
产品或其他的伤害或损坏
设备
1.2安装注意事项
危险
·请将驱动器安装在阻燃材料上。
·保持驱动器远离易燃材料
·保持驾驶远离爆炸性气体
·只有合格的人员才能连接驱动器
·除非输入交流电源为：
完全断开
·驱动器必须正确接地，以减少
电气事故
·在打开驱动器之前安装盖子，以便
减少电击和爆炸的危险。
·对于存储时间超过2年的驱动器
多年来，逐渐增加其输入电压
向其提供全额定输入电压，以便
避免触电和爆炸
·不要用裸露的触摸带电控制终端
手
·请勿用湿手操作驱动器
·确认以下情况后，执行维护工作：
充电LED熄灭或直流母线电压为
低于36V。
·只有经过培训的专业人员才能更改
部件，禁止留下电线或金属
驱动器内部的部件，以避免火灾风险。
·具有以下功能的控制板的参数设置：
已更改必须修改，否则发生意外
这可能发生。
·电力电缆的裸露部分必须捆扎
用绝缘带。
! 注意
·不要拿着驱动器的盖子。封面不能
支撑驱动器的重量，可能会掉落。
·请在强力支持下安装驱动器，失败
驱动器可能会脱落。
·不要将驱动器安装在有水管的地方
可能漏到它上面。
·不允许螺钉、垫圈和其他金属异物
要落在驱动器内，否则会出现
火灾或损坏的危险；
·如果部件不完整，请勿操作驱动器，
否则存在火灾或人身伤害的危险；
·请勿在阳光直射下安装驱动器，
否则可能会损坏；
·不要使P1/PB和端子（-）短路，否则
存在火灾危险，或驱动器可能存在
损坏
·电缆接线头必须连接到主端子
坚决地
·不要将电源电压（AC 220V或更高）施加到
除终端TA、TB和TC之外的控制终端。
1.3使用EV2000的注意事项
使用EV2000时，请注意以下问题：
驾驶
1.3.1关于电机和负载
与工频操作相比
EV2000系列驱动器为电压型变速驱动器
驾驶输出电压为PWM波，其中
谐波。因此，温度升高、噪音和
电机振动较大。
恒转矩低速旋转
长时间低速驱动公共电机，
驱动器的寿命将因恶化而缩短
散热效果好，所以特殊变频
如果长时间恒定运行，则需要电机
需要扭矩。
电机超温保护阈值
该驱动器可以保护电机不受温度过高的影响。
如果驱动电机的额定值为m

EV1000-4T0055G

EV1000-4T0055G

Operations without following
instructions can cause personal
injury or death.
! Attention Operations without following
instructions can cause personal
injury or damage to product or other
equipment.
1.2 Notes for Installations
Danger !
·Please install the drive on fire-retardant material.
·Keep the drive away from combustible materials
·Keep the drive away from explosive gas
·Only qualified personnel shall wire the drive
·Never wire the drive unless the input AC supply is
totally disconnected
·The drive must be properly earthed to reduce
electrical accident
·Install the cover before switching on the drive, to
reduce the danger of electric shock and explosion.
·For drives that have been stored for longer than 2
years, increase its input voltage gradually before
supplying full rated input voltage to it, in order to
avoid electric shock and explosion
·Don't touch the live control terminals with bare
hands
·Don’t operate the drive with wet hands
·Perform the maintenance job after confirming that
the charging LED is off or the DC Bus voltage is
below 36V.
·Only trained professionals can change the
components, it is prohibited to leave wires or metal
parts inside the drive so as to avoid the risk of fire.
·Parameter settings of the control board that has
been changed must be revised, otherwise accidents
may occur.
·The bare portions of the power cables must be bound
with insulation tapes.
! Attention
·Don’t carry the drive by its cover. The cover cannot
support the weight of the drive and may drop.
·Please install the drive on a strong support, failing
which the drive may fall off.
·Don’t install the drive in places where water pipes
may leak onto it.
·Don't allow screws, washers and other metal foreign
matters to fall inside the drive, otherwise there is a
danger of fire or damage;
·Don't operate the drive if parts are not complete,
otherwise there is a danger of a fire or human injury;
·Don't install the drive under direct sunshine,
otherwise it may be damaged;
·Don’t short circuit P1/PB and terminal (-), otherwise
there is a danger of fire or the drive may be
damaged.
·Cable lugs must be connected to main terminals
firmly
· Don’s apply supply voltage (AC 220V or higher) to
control terminals except terminals TA, TB and TC.
1.3 Notes for Using EV2000
Pay attention to the following issues when using EV2000
drive.
1.3.1 About Motor and Load
Compared to the power frequency operation
EV2000 series drives are voltage type variable speed
drive. The output voltage is in PWM wave with some
harmonics. Therefore, temperature rise, noise and
vibration of motor are higher.
Low Speed Rotating with Constant Torque
Driving a common motor at low speed for a long time,
the drive’s life will be reduced due to the deteriorating
heat dissipation effect, so a special variable frequency
motor is needed if long time operation with constant
torque is required.
Motor’s over-temperature protecting threshold
The drive can protect the motor from over-temperature.
If the ratings of the driven m
