EV1000-4T0015G模块备件

EV1000-4T0015G

对于驱动器，确保调整保护阈值
以确保电机得到适当保护。
在50Hz以上运行
当电机在50Hz以上运行时，将出现
振动和噪声增加。速率
电机提供的扭矩与此相反
与其运行速度的增加成比例。确保
电机仍然可以向负载提供足够的扭矩。
机械设备的润滑
随着时间的推移，机械设备中的润滑剂，如
当低速运行时，
这将恶化。建议频繁维护。
制动力矩
在以下情况下，在机器中产生制动扭矩：
驱动器正在向下提升负载。驱动器将在以下情况下跳闸：
无法处理消耗的再生能量
负载。因此，具有适当的制动装置
需要在驱动器中设置参数。
负载的机械谐振点
驱动系统可能会遇到机械谐振
在一定范围内运行时，负载：
输出频率。跳过频率已设置为
避免它。
驱动器应通过其控制装置启动和停止
终端。禁止启动和停止驱动器
直接通过输入线路接触器
频繁操作会损坏驱动器。
电机绝缘
在使用驱动器之前，电机的绝缘必须
检查，尤其是使用或
它已经储存了很长时间。这是为了减少
驱动器有被穷人损坏的风险
电机的绝缘。接线图如图所示。
1-1.请使用500V绝缘测试仪测量
绝缘电阻。不应小于5MΩ。
发动机
兆欧表
接地
导体
图1-1电机绝缘检查
1.3.2关于变速驱动
用于提高功率的压敏电阻或电容器
因素
不要将任何变阻器或电容器连接到输出端
驱动器的端子，因为驱动器的输出电压
波形为脉搏波，否则跳闸或损坏
可能出现组件的故障；此外，不要安装电路
驱动器输出侧的断路器或接触器
如图1-2所示。
M
U
五、
W
EV2000
图1-2禁止使用电容器。
连接到驱动器输出的断路器
如果需要连接断路器或接触器
在驱动器和电机之间，确保运行
这些断路器或接触器，当驱动器具有
无输出，以避免损坏驱动器。
在额定电压范围外使用
驱动器不适合在指定范围之外使用
工作电压范围。如果需要，请使用
适用于电压调节装置。
从三相变为两相
不建议将驱动器从三相更改为三相
输入至2相输入。如果需要在两个上使用
相位，驱动器的缺相保护功能
应禁用。为此，驱动器必须降额
活动对于功率大于30kW的电机，如果：
它变为2相输入，然后输入相位
必须处于相位R和相位T，否则驱动器将
这不是工作。
在三相输入变为两相输入之后，
总线电压和电流纹波可能会增加，但不会
不仅影响电解电容器的寿命，而且
会降低驱动器的性能。驱动器
工作电流应降低，不应
超过额定值的67%。
防雷
驱动器内部有瞬态浪涌抑制器
从而保护其免受雷击。

EV1000-4T0015G

EV1000-4T0015G

with the drive, be sure to adjust the protective threshold
to ensure the motor is properly protected.
Operate above 50Hz
When running the motor above 50Hz, there will be
increase in vibration and noise. The rate at which the
torque is available from the motor is inversely
proportional to its increase in running speed. Ensure that
the motor can still provide sufficient torque to the load.
Lubrication of mechanical devices
Over time, the lubricants in mechanical devices, such as
gear box, geared motor, etc. when running at low speed,
will deteriorate. Frequent maintenance is recommended.
Braking Torque
Braking torque is developed in the machine when the
drive is hoisting a load down. The drive will trip when it
cannot cope with dissipating the regenerative energy of
the load. Therefore, a braking unit with proper
parameters setting in the drive is required.
The mechanical resonance point of load
The drive system may encounter mechanical resonance
with the load when operating within certain band of
output frequency. Skip frequencies have been set to
avoid it.
The drive should be started and stopped via its control
terminals. It is prohibited to start and stop the drive
directly through input line contactors, which may
damage the drive with frequent operations.
Insulation of Motors
Before using the drive, the insulation of the motors must
be checked, especially, if it is used for the first time or if
it has been stored for a long time. This is to reduce the
risk of the Drive from being damaged by the poor
insulation of the motor. Wiring diagram is shown in Fig.
1-1. Please use 500V insulation tester to measure the
insulating resistance. It should not be less than 5MΩ.
Motor
Mega-Ohm-Meter
Earthing
conductor
Fig. 1-1 Checking the insulation of motor
1.3.2 About Variable Speed Drive
Varistors or Capacitors Used to Improve the Power
Factor
Don't connect any varistor or capacitor to the output
terminals of the drive, because the drive's output voltage
waveform is pulse wave, otherwise tripping or damaging
of components may occur; in addition, don't install circuit
breaker or contactor at the output side of the drive as
shown in Fig.1-2.
M
U
V
W
EV2000
Fig. 1-2 Capacitors are prohiBited to be used.
Circuit breakers connected to the output of the drive
If circuit breaker or contactor needs to be connected
between the drive and the motor, be sure to operate
these circuit breakers or contactor when the drive has
no output, to avoid damaging of the drive.
Using outside the range of rated voltage
The drive is not suitable to be used out of the specified
range of operation voltage. If needed, please use
suitable voltage regulation device.
Change from 3-phase to 2-phase
It is not recommended to change the drive from 3-phase
input to 2-phase input. If it is necessary to use on two
phases, the phase-loss protection function of the drive
should be disabled. The Drive must be derated for this
operation. For motors at which power is above 30kW, if
it is changed into 2-phase input, then the input phases
must be at phase R and phase T, or else the drive will
not work.
After the 3-phase input is changed into 2-phase input,
bus-voltage and current ripple may increase, which not
only influences the life of electrolytic capacitor but it also
deteriorates the performance of the drive. The drive’s
operating current should be derated and should not
exceed 67% of rated value.
Protection against lightning strike
There are transient surge suppressors inside the Drive
which protects it against lighting strike.
