在后续章节中，您可能会遇到以下条款
描述驱动器的控制、运行和状态
泰晤士报。请仔细阅读本节。它会帮助你的
理解和使用要讨论的功能
正确地
4.1.1驱动器的控制模式
它定义了驱动器接收的物理通道
操作命令，如START、STOP、FWD、REV，
慢跑等。
面板控制：驱动器由运行、停止控制
以及操作面板上的点动键；
终端控制：驱动器由终端控制
FWD、REV和COM（2线模式），或通过终端Xi
（3线模式）；
主机控制：启动和停止等操作
可由主机PC控制。
可以通过参数F0.03选择控制模式，
面板上的面板/远程键和输入/数据键
操作面板和多功能输入端子（编号27，
28和29可通过F7.00~F7.07选择）。
警告：
用户必须确保选择的控制模式为：
适用于该应用。控件选择错误
模式可能导致设备损坏或人身伤害！
4.1.2参考选择器
在常见操作模式下，EV2000有6种可能
输入参考频率的方法，参考
频率可通过以下方式输入：
▲ 和▼ 面板上的键；
终端UP/DN；
串行端口；
模拟VCI；
模拟CCI；
脉冲终端（脉冲）
如何设置频率
输出频率在计算
来自上述6个频率中的一个或多个频率的值
设置方法，包括主和
辅助参考频率。
主参考频率：由F0.00设置，多速
（MS）或闭环控制。
主参考频率由优先级决定
运行模式。优先级为点动>关闭
回路>PLC>MS（多速）>普通运行，如
驱动器以MS模式运行，主要参考
频率是MS频率。
辅助参考频率：按F9.01~F9.04设置。
预设频率：主辅之和
频率乘以F9.05中设置的系数，以及
F9.06。请参考中的F9.05、F9.02和图5-59
第五章。
4.1.3运行状态
有3种运行状态：停止、电机
参数自动调整和操作。
停止状态：驱动器打开后
如果未接受任何操作命令或
执行停止命令，然后驱动器进入
停止状态。
运行状态：驱动器在以下情况下进入运行状态：
它接收操作命令。
电机参数自动调谐状态：如果存在
FH后的操作命令。09设置为1或2时，驱动器
然后进入电机参数自动调谐状态，以及
然后在自动调整过程完成后进入停止状态
结束
4.1.4运行模式
EV2000有5种工作模式，可以：
根据优先级排序：点动>闭环
操作>PLC操作>多步速度
操作>简单操作，如图4-1所示。
慢跑：
当驱动器处于停止状态时，它将运行
根据Jog fre

3A99166G0

3A99166G0

 the follow-up sections, you may encounter the terms
describing the control, running and status of drive many
times. Please read this section carefully. It will help you
to understand and use the functions to be discussed
correctly.
4.1.1 The Drive’s Control Modes
It defines the physical channels by which drive receives
operating commands like START, STOP, FWD, REV,
JOG and others.
Panel control: The drive is controlled by RUN, STOP
and JOG keys on the operation panel;
Terminal control: The drive is controlled by terminals
FWD, REV and COM (2-wire mode), or by terminal Xi
(3-wire mode);
Host control: The operations such as START and STOP
can be controlled by host PC.
The control modes can be selected by parameter F0.03,
PANEL/REMOTE key and ENTER/DATA key on the
operation panel and multi-function input terminal (No.27,
28 and 29 can be selected by F7.00~F7.07).
     Warning:
The user must ensure that the control mode selected is
suitable for the application. Wrong selection of control
mode may cause damage to equipment or human injury!
4.1.2 Reference Selector
In common operating modes, EV2000 has 6 possible
ways to input reference frequency, the reference
frequency can be input by:
▲ and ▼ keys on the panel;
Terminals UP/DN;
Serial port;
Analog VCI;
Analog CCI;
Pulse terminal (PULSE)
How to set Frequency
The output frequency is decided after calculating the
values from one or more of the above 6 frequency
setting methods, which involves the concept of main and
auxiliary reference frequency.
Main reference frequency: set by F0.00, multi-speed
(MS) or close loop control.
The main reference frequency is decided by the priority
of running mode. The priority level is Jog>close
loop>PLC>MS (multi-speed)>common running, e.g. if
the drive is running in MS mode, the primary reference
frequency is MS frequency.
Auxiliary reference frequency: set by F9.01~F9.04.
Preset frequency: the sum of main and auxiliary
frequency multiply a factor, which is set in F9.05 and
F9.06. Please refer to F9.05, F9.06 and Fig. 5-59 in
chapter 5.
4.1.3 Operating Status
There are 3 operating status: stopping, motor
parameters auto-tuning, and operating.
Stopping status: After the drive is switched on and
initialized, if no operating command is accepted or the
stopping command is executed, then the drive enters
stopping status.
Operating status: The drive enters operating status after
it receives the operating command.
Motor parameters auto-tuning status: If there is an
operating command after FH.09 is set to 1 or 2, the drive
then enters motor parameters auto-tuning status, and
then enters stopping status after auto-tuning process is
over.
4.1.4 Operating Modes
EV2000 has 5 kinds of operating modes which can be
sequenced according to the priority: Jog>Close loop
operation>PLC operation>Multi-step speed
operation>Simple operation, as shown in Fig. 4-1.
Jog:
When the drive is in stopping status, it will operate
according to Jog fre
