表5-3驱动器类型和载波频率（CWF）
CWF
类型
高
（kHz）
低的
（kHz）
工厂
设置（kHz）
G型：5.5kW~45kW
P型：7.5kW~55kW 15 3 8
G型：55kW~90kW
P型：75kW~110kW 10 1 3
G型：110kW~220kW
P型：132kW~280kW 6 0.7 2
表5-4 CWF特性
CWF减少或增加
电机噪声↑ ↓
漏电流↓ ↑
骚乱↓ ↑
笔记：
为了实现更好的控制性能
大工作频率的载波频率
驱动器不应小于36。
F3.11 CWF范围的自动调整：0.1【1】
0:禁用
1： 启用
启用此功能后，驱动器可以调整
根据内部温度自动进行CWF
驱动器的。此时，驱动器的实际大CWF为
受F3.10限制。
F3.12电机音调调整范围：0~10【0】
F3.12可用于调整电机的音调，并且
仅对低于6kHz的CWF有效。
如果此参数设置为0，则禁用该功能。
F3.13点动操作
频率
范围：0.10~50.00Hz
【5.00Hz】
F3.14点动间隔
操作范围：0.0~100.0s【0.0s】
F3.15点动的Acc时间
活动
范围：0.1~60.0s
【6.0/20.0】
F3.16十二月点动时间
活动
范围：0.1~60.0s
【6.0/20.0】
F3.13~F3.16定义点动的相关参数
活动
如图5-19所示，t1和t3为实际Acc时间
和Dec时间。t2是点动操作时间；t4
是微动操作的间隔（F3.14）；f1是慢跑
工作频率（F3.13）。
实际Acc时间t1可通过以下公式确定：
微动操作的实际Dec时间t3也是如此。
t1=F3.13×F3.15
F0.05
点动命令点动命令
f1
t1
t3
t2t4
时间
频率
时间
图5-19点动操作参数
点动操作间隔（F3.14）是从
后一次点动操作命令结束的时间
下一个点动操作命令为：
执行。
间隔期间发送的jog命令将不会：
执行。如果此命令存在，直到
间隔，它将被执行。
注：
1.在点动操作过程中，驱动器根据
启动模式0，并根据停止模式0停止。
Acc/Dec时间单位为秒。
2.点动操作可通过面板、端子和
串行端口。
F3.17 Acc时间2范围：0.1~3600s（分钟）【6.0s/20.0s】
F3.18 12月时间2范围：0.1~3600s（分钟）【6.0s/20.0s】
F3.19 Acc时间3范围：0.1~3600s（分钟）【6.0s/20.0s】
F3.20十二月时间3范围：0.1~3600s（分钟）【6.0s/20.0s】
F3.21 Acc时间4范围：0.1~3600s（分钟）【6.0s/20.0s】
F3.22 12月4日时间范围：0.1~3600s（分钟）【6.0s/20.0s】
可以定义三种Acc/Dec时间，并且
驱动器的Acc/Dec时间1~4可通过以下方式选择：
控制终端的组合，参见
F7.00~F7.07的定义介绍
用于选择Acc/Dec时间的终端。
注：
1.在F0.10和F0.11中定义了Acc/Dec时间1。
2.对于30kW或以上的驱动器，其出厂设置为
Acc/Dec时间为20.0s。
F3.23预设
频率1
范围：频率下限
~频率上限【5.00Hz】
F3.24预设
频率2
范围：频率下限
~频率上限【10.00Hz】
52第5章参数介绍
EV2000系列通用变速驱动用户手册
F3.25预设
频率3
范围：频率下限
~频率上限【20.00Hz】
F3.26预设
频率4
范围：频率下限
~频率上限【30.00Hz】
F3.27预设
频率5
范围：频率下限
~频率上限【40.00Hz】
F3.28预设
频率6
范围：频率下限
~频率上限【45.00Hz】
F3.29预设
频率7
范围：频率下限
~频率上限【50.00Hz】
这些频率将用于简单的PLC操作
和多步速度操作，参见介绍
F7.00~F7.07和F4组参数。
F3.30跳频1范围：0.00~650.00Hz
【0.00Hz】
F3.31箕斗范围
频率1
范围：0.00~30.00Hz
【0.00Hz】
F3.32跳频2范围：0.00~650.00Hz
【0.00Hz】
F3.33箕斗范围
频率2
范围：0.00~30.00Hz
【0.00Hz】
F3.34跳频3范围：0.00~650.00Hz
【0.00Hz】
F3.35箕斗范围
频率3
范围：0.00~30.00Hz
【0.00Hz】
F3.30~F3.35定义将导致的输出频率
应避免与负载共振。
因此，驱动器将跳过上述频率，如
如图5-2020所示。多可以使用3个跳频
设置
调整预置
频率
跳过
频率3
跳过
频率2
跳过
频率1
跳过
范围3
跳过
范围2
预设
频率
跳过范围1
图5-20跳频和跳频范围
5.5 PLC运行参数（F4组）
简单的PLC功能可以使驱动器改变其
自动操作频率和方向
根据运行时间，以满足
制造要求。在此之前，此函数是
通过PLC实现，现在驱动器本身可以实现
如图5-21所示。
F1
f2
F3
f 4
f 5
f6
F7
T1 T2 T3 T4 T5 T6 T7
a1
a2
a3
d3
a4 d5
a5
a6
d7
d7
简单的PLC操作
co的500ms指示信号

5X00419G01

5X00419G01

Table 5-3 Drive’s type and carrier wave frequency (CWF)
 CWF
Type
Highest
(kHz)
Lowest
(kHz)
Factory
setting (kHz)
Type G:5.5kW~45kW
Type P:7.5kW~55kW 15 3 8
Type G:55kW~90kW
Type P:75kW~110kW 10 1 3
Type G:110kW~220kW
Type P:132kW~280kW 6 0.7 2
Table 5-4 CWF characteristics
CWF Decrease Increase
Motor’s noise ↑ ↓
Leakage current ↓ ↑
Disturbance ↓ ↑
     Notes:
In order to achieve better control performances, the ratio of
carrier frequency to the maximum operating frequency of
the drive should not be less than 36.
F3.11 Auto adjusting of CWF Range:0. 1【1】
0: disabled
1: enabled
When this function is enabled, the drive can adjust the
CWF automatically according to the internal temperature
of the drive. At this time, the drive’s actual Max CWF is
restricted by F3.10.
F3.12 Motor tone adjustment Range:0~10【0】
F3.12 can be used to adjust the motor’s tone, and is
only effective for the CWF below 6kHz.
If this parameter is set to 0, the function is disabled.
F3.13 Jog operating
frequency
Range:0.10~50.00Hz
【5.00Hz】
F3.14 Interval of Jog
operation Range:0.0~100.0s【0.0s】
F3.15 Acc time of Jog
operation
Range:0.1~60.0s
【6.0s/20.0s】
F3.16 Dec time of Jog
operation
Range:0.1~60.0s
【6.0s/20.0s】
F3.13~F3.16 define the relevant parameters of Jog
operation.
As shown in Fig. 5-19, t1 and t3 are the actual Acc time
and Dec time respectively. t2 is the Jog operating time; t4
is the interval of Jog operation(F3.14); f1 is the Jog
operating frequency(F3.13).
Actual Acc time t1 can be determined by the following
formula, so does the actual Dec time t3 of jog operation.
t1= F3.13×F3.15
F0.05
Jog command Jog command
f1
t1
t3
t2 t 4
Time
Frequency
Time
Fig. 5-19 Jog operating parameters
Interval of Jog operation (F3.14) is the interval from the
time when the last Jog operation command is ended to
the time when the next Jog operation command is
executed.
The jog command sent during the interval will not be
executed. If this command exists until the end of the
interval, it will be executed.
     Note:
1. In Jog operation process, the drive starts according to
starting mode 0 and stops according to stopping mode 0.
The unit of Acc/Dec time is second.
2. Jog operation can be controlled by panel, terminals and
serial port.
F3.17 Acc time 2 Range: 0.1~3600s(min) 【6.0s/20.0s】
F3.18 Dec time 2 Range: 0.1~3600s(min) 【6.0s/20.0s】
F3.19 Acc time 3 Range: 0.1~3600s(min) 【6.0s/20.0s】
F3.20 Dec time 3 Range: 0.1~3600s(min) 【6.0s/20.0s】
F3.21 Acc time 4 Range: 0.1~3600s(min) 【6.0s/20.0s】
F3.22 Dec time 4 Range: 0.1~3600s(min) 【6.0s/20.0s】
Three kinds of Acc/Dec time can be defined, and the
drive’s Acc/Dec time 1~4 can be selected by different
combinations of control terminals, refer to the
introductions of F7.00~F7.07 for the definitions of
terminals used to select Acc/Dec time.
     Note:
1. Acc/Dec time 1 is defined in F0.10 and F0.11.
2. For the drive of 30kW or above, its factory setting of
Acc/Dec time is 20.0s.
F3.23 Preset
frequency 1
Range: Lower limit of frequency
~upper limit of frequency【 5.00Hz】
F3.24 Preset
frequency 2
Range: Lower limit of frequency
~upper limit of frequency【10.00Hz】
52 Chapter 5 Parameter Introductions
EV2000 Series Universal Variable Speed Drive User Manual
F3.25 Preset
frequency 3
Range: Lower limit of frequency
~upper limit of frequency【20.00Hz】
F3.26 Preset
frequency 4
Range: Lower limit of frequency
~upper limit of frequency【30.00Hz】
F3.27 Preset
frequency 5
Range: Lower limit of frequency
~upper limit of frequency【40.00Hz】
F3.28 Preset
frequency 6
Range: Lower limit of frequency
~upper limit of frequency【45.00Hz】
F3.29 Preset
frequency 7
Range: Lower limit of frequency
~upper limit of frequency【50.00Hz】
These frequencies will be used in simple PLC operation
and multi-step speed operation, refer to the introductions
of F7.00~F7.07 and group F4 parameters.
F3.30 Skip frequency 1 Range:0.00~650.00Hz
【0.00Hz】
F3.31 Range of skip
frequency 1
Range:0.00~30.00Hz
【0.00Hz】
F3.32 Skip frequency 2 Range:0.00~650.00Hz
【0.00Hz】
F3.33 Range of skip
frequency 2
Range:0.00~30.00Hz
【0.00Hz】
F3.34 Skip frequency 3 Range:0.00~650.00Hz
【0.00Hz】
F3.35 Range of skip
frequency 3
Range:0.00~30.00Hz
【0.00Hz】
F3.30~F3.35 define the output frequency that will cause
resonant with the load, which should be avoided.
Therefore, the drive will skip the above frequency as
shown in Fig. 5-2020. Up to 3 skip frequencies can be
set.
Adjusted preset
frequency
Skip
frequency 3
Skip
frequency 2
Skip
frequency 1
Skip
range 3
Skip
range 2
Preset
frequency
Skip range 1
Fig. 5-20 Skip frequency and skip range
5.5 PLC Operating Parameters(Group F4)
Simple PLC function can enable the drive change its
operating frequency and directions automatically
according to the operating time to satisfy the
manufacturing requirements. Before, this function is
realized by PLC, now the drive itself can realize such
function, as shown in Fig. 5-21.
f 1
f 2
f 3
f 4
f 5
f 6
f 7
T1 T2 T3 T4 T5 T6 T7
a1
a2
a3
d3
a4 d5
a5
a6
d7
d7
Simple PLC operation
500ms Indicating signal for complating
one stage of PLC operation
Indicating signal for completing a
cycle of PLC operation
Fig. 5-21 Simple PLC operation
In Fig. 5-21, a1~a7 and d1~d7 are the Acc time and Dec
time in different stages. f1~f7 and T1~T7 will be defined in
the following parameters.
Bi-direction open-collector output terminals Y1 and Y2 or
the relay that output the 500ms pulse can indicate the
completion of PLC operation, refer to the introductions of
F7.10~F7.12.
F4.00 Simple PLC operation
mode Range: 0000~1123【0000】
A B C D
PLC operating mode selection 0: No action
3: stop after single cycle
1: Hold final value after 1-cylce running

4: continuous operation
PLC restarting mode selection:
0: Restart from 1st stage
1: Continue to run at the frequency in the stafe
when the drive stopes
2: Continue to run at the frequency when the
drive pauses
Save PLC operating parameters upon power
outage:
0: No save
1: Save the frequency and running stage upon
power outage
Unit of running time:
0: Second
1: Minute
Fig. 5-22 Simple PLC operat
