exitSeatVal=5000 When the RSR is seating the valve, then decides to retreat, this is
the output in mV to which the output goes.
exitBkSeatVal=-5000 When the RSR is backseating the valve, then decides to retreat,
this is the output in mV to which the output goes.
CASCADE=0 If this flag is set to 1, the two PI’s are cascaded.
Page 22-35, Make the following changes to Table 22-9 “Servo Driver Configuration/Status Register”:
Bit Data Description (Write) Data Description (Read)
9 Not Used Ch1 - Retreat in progress
10 Not Used Ch2 - Retreat in progress
11 Not Used Ch1 - Retreat is disabled
12 Not Used Ch2 - Retreat is disabled
Page 22-38, Make the following changes to Table 22-11 “Servo Driver Diagnostic”:
For LED E (Red) Description, delete the following Possible causes:
“SLIM not connected,” and
“No auxiliary voltage,”
For LED I (Red), delete the following:
“Fatal error occurs”
IPU-247 17
Emerson Process Management Proprietary Class 2C
Add the following Changes to Section 25
Page 25-7, Replace the middle section of Table 25-1 with the following:
When using the Point Builder to define points for a Valve Positioner module, only the following point
types are valid for each channel:
I/O Name Type Input Source or Terminal Block
Channel Output Destination Connection 2
 1 Shutdown Status Input Valve Positioner DI1
 2 Auxiliary (wetting) Voltage Sense Input Valve Positioner DI2
 3 SLIM ON Signal Input Valve Positioner DI3
 4 Position Feedback Input Valve Positioner
 5 Coil 1 Voltage (Read-back Input Valve Positioner Coil 1
 6 Coil 2 Voltage (Read-back Input Valve Positioner Coil 2
 7 Coil 3 Voltage (Read-back) Input Valve Positioner Coil 3
 8 Raw Demodulator Voltage Input Valve Positioner
 9 VP Status Input Valve Positioner
10 Demand Feedback input Valve Positioner
11 VP Command output Valve Positioner
12 VP Demand output Valve Positioner
13 Partner Position Feedback output Valve Positioner
Page 25-8, Replace the table (concerning the VP module firmware releases) with the following:
Page 25-21, Delete Section 25-7.2 “Calibration Required,” Repetitive.
VP Firmware Level
(Electronics
Module)
VP Revision Level
(Electronics
Module) Firmware Features
0F 9 Added support for the following:

Calibration from the Controller using graphics.

Upload/download of calibration constants to and
from the Controller.

New tuning constants kServo and kServoDb to
replace hard-coded constants. They add
flexibility in dealing with differing coil
impedances.

Reduction of valve calibration time.
0C 6 Added support for VP Redundancy.
0B 5 First full production firmware release.
0D obsolete
0E obsolete
0G 11 Redundancy support changed so that multiple
failovers are precluded.
Improvements to calibration.
Fixed problem with coil diagnostics for “coilCount =
0”.
Position feedbacks rollover problem fixed.
0H 13 Added “priority Demand” tuning constant to support
Rockport project.
Fixed overflow problem in PI math.
18 IPU-247
Emerson Process Management Proprietary Class 2C
Page 25-28, Section 25-9.3 “Shutdown Input”, change the name to the following, then add the text
that follows to the end of the section:
25-9.3 Shutdown Input (Priority Demand Input)
For VP firmware revisions 0H and later, the shutdown input is redefined to “Priority Demand
Input”. When the input is activated, the target position is set to a tunable constant. For
compatibility with previous firmware revisions, the default value of priorityDemand is -5%.
This allows the user to rapidly move the valve to some intermediate position during upset
conditions. The user has the flexibility to create his own scheme to handle an upset.
While the “priority demand input”, or “Shutdown” input is active, the VP is in the local mode
and the controller must unconditionally track demand feedback.
Page 25-29, Section 25-10.5. “Open Coil Diagnostic Error”, replace “is incorrect” at the end of the
second sentence with:
has been adjusted to yield that result.
Page 25-29, Section 25-10.5. “Open Coil Diagnostic Error”, add the following text after the first
paragraph of the section:
For firmware revisions prior to 0F, the diagnostic works as described below. For later
revisions servo coil voltage is measured and compared to a model described by tuning
constants “kServo” and “kServoDb’. If the voltage does not fit into the model, due to being
too large, “open coil” is blamed and the internal diagnostic bit is set. Then the timing
