1C31164G02 模块备件

1C31164G02

控制模块由控制器自动调度，
基于它们分配的扫描速率。这允许每个控件
基于过程动力学优化的函数。
模块扫描时间可以设置为快100ms，也可以设置为慢速
如60秒。可以使用的控制模块数量：
分配给控制器取决于复杂性和扫描
每个模块的速率以及可用的CPU和内存。
SQ控制器应用于中小型
具有多750个单独I/O信号的应用。
SQ控制器专为恶劣环境设计
额定用于G3腐蚀性环境，具有
温度范围为-40至70°C。它非常适合：
远程安装，靠近工艺设备。更多
具有中央编组柜的传统装置，
CHARM I/O卡可以安装在标准I/O机柜中
提供电子编组。CHARM I/O卡还可以：
用于高度分布式I/O应用。
DeltaV SQ控制器硬件尺寸。
DeltaV SQ控制器，2022年8月
www.emerson。com/deltav 4
硬件规格
SQ控制器的规格
夏令时限额750
SCADA标签3200
每秒发送的大数据值为2000
接收的大数据值：250/秒
大未经请求的客户端节点64
模块执行速率为100ms、200ms、500ms、1s、2s、5s、10s、30s、60s
用户内存48 MB
保险丝保护（内部）3.0 A，不可更换保险丝
功耗典型为5.0 W，大为7.0 W
环境规范
工作温度*-40°至70°C（-40°至158°F）
储存温度-40°至85°C（-40°至185°F）
相对湿度5-95%，不冷凝
防护等级IP 20
空气污染物ISA-S71.04-1985空气污染物G3类保形涂层
冲击（正常工作条件）10 g½-正弦波持续11 ms
振动（工作极限）从5 Hz到13.2 Hz的1 mm峰间，从13.2赫兹到150 Hz的0.7 g
LED指示器
绿色–电源表示应用了直流电源
红色–错误表示错误情况
绿色–活动表示控制器作为主控制器运行
绿色–备用表示控制器作为备用控制器运行
黄色闪烁–Pri。CN表示有效的主控制网络通信
黄色闪烁–秒CN表示有效的二次控制网络通信
外部连接
主控制网络8针RJ-45连接器
辅助控制网络8针RJ-45连接器
*在其温度范围的较高端长时间运行任何电子器件将缩短其预期寿命，
有关详细信息，请参阅机箱内的热量和气流影响白皮书。
DeltaV SQ控制器，2022年8月
www.emerson。com/deltav 5
所获证书
DeltaV上提供以下认证：
SQ控制器（请参见实际证书以获取准确证书）。
„CE：
EMC-EN 61326-1
„调频：
FM 3600
FM 3611
„CSA：
CSA C22.2213号
CSA C22.21010-1号
„ATEX：
EN 60079-0
EN 60079-7
„IEC Ex：
IEC60079-0
IEC60079-7
„海事认证：IACS E10
ABS设计评估证书
DNV型式认证证书
„Wurldtech：
阿喀琉斯通信认证1级（v12.3）
阿喀琉斯通信认证2级
（v13.3.1和v14.3）
危险区域/位置
DeltaV SQ控制器可根据以下情况安装和使用：
根据以下标准（参见实际证书以了解确切信息
产品标记）：
„FM（美国）：
一类，二类，A、B、C、D、T4组
„cFM（加拿大）：
一类，二类，A、B、C、D、T4组
„ATEX：
II 3G Ex ec IIC T4 Gc
„IEC Ex：
II 3G Ex ec IIC T4 Gc
关于安装说明，请参考以下文件：
DeltaV S系列（12P5402）1类2部分安装说明
DeltaV S系列（12P5）2区安装说明

1C31164G02

1C31164G02

Control modules are automatically scheduled by the controller,
based on their assigned scan rates. This allows each control
function to be optimized based on the process dynamics.
Modules scan times can be set as fast as 100 ms, and as slow
as 60 seconds. The number of control modules that can be
assigned to a controller depends on the complexity and scan
rate of each module, and the available CPU and memory.
The SQ controller should be used for small to medium
applications with a maximum of 750 individual I/O signals.
The SQ controller is designed for harsh environments and
is rated for G3 corrosive environments, with an operating
temperature range from -40 to 70°C. It is ideally suited for
remote installation, close to the process equipment. For more
traditional installations with central marshalling cabinets,
CHARM I/O Cards can be mounted in standard I/O cabinets
providing Electronic Marshalling. CHARM I/O Cards can also
be used for highly distributed I/O applications.
DeltaV SQ controller hardware dimensions.
DeltaV SQ Controller August 2022
www.emerson.com/deltav 4
Hardware Specifications
Specifications for the SQ Controller
DST Limit 750
SCADA Tags 3200
Max Data Values Sent 2000/second
Max Data Values Received 250/second
Max Unsolicited Client Nodes 64
Module Execution Rates 100ms, 200ms, 500ms, 1s, 2s, 5s, 10s, 30s, 60s
User Memory 48 MB
Fuse Protection (Internal) 3.0 A, non-replaceable fuses
Power Dissipation 5.0 W typical, 7.0 W maximum
Environmental Specifications
Operating Temperature* -40° to 70°C (-40° to 158°F)
Storage Temperature -40° to 85°C (-40° to 185°F)
Relative Humidity 5 to 95%, non-condensing
Protection Rating IP 20
Airborne Contaminants ISA-S71.04-1985 Airborne Contaminants Class G3 Conformal coating
Shock (Normal Operating Conditions) 10 g ½-sine wave for 11 ms
Vibration (Operative Limit) 1 mm peak-to-peak from 5 Hz to 13.2 Hz, 0.7 g from 13.2 Hz to 150 Hz
LED Indicators
Green – Power Indicates DC power is applied
Red – Error Indicates an error condition
Green – Active Indicates that the controller is operating as the primary controller
Green – Standby Indicates that the controller is operating as a backup controller
Yellow Flashing – Pri. CN Indicates valid primary control network communication
Yellow Flashing – Sec. CN Indicates valid secondary control network communication
External Connections
Primary Control Network 8-pin RJ-45 connector
Secondary Control Network 8-pin RJ-45 connector
*Operating any electronics at the higher end of its temperature range for long periods of time will shorten its expected lifetime,
see Effects of Heat and Airflow Inside an Enclosure White Paper for more information.
DeltaV SQ Controller August 2022
www.emerson.com/deltav 5
Certifications
The following certifications are available on the DeltaV
SQ controller(see actual certificates for exact certifications).
„ CE:
EMC- EN 61326-1
„ FM:
FM 3600
FM 3611
„ CSA:
CSA C22.2 No. 213
CSA C22.2 No. 1010-1
„ ATEX:
EN 60079-0
EN 60079-7
„ IEC Ex:
IEC60079-0
IEC60079-7
„ Marine Certifications: IACS E10
ABS Certificate of Design Assessment
DNV Type Approval Certificate
„ Wurldtech:
Achilles Communications Certification Level 1 (v12.3)
Achilles Communications Certification Level 2
(v13.3.1 & v14.3)
Hazardous Area/Locations
The DeltaV SQ Controller can be installed and used based
on the following Standards (see actual certificates for exact
product markings):
„ FM (USA):
Class I, Division 2, Groups A, B, C, D, T4
„ cFM (Canada):
Class I, Division 2, Groups A, B, C, D, T4
„ ATEX:
II 3G Ex ec IIC T4 Gc
„ IEC Ex:
II 3G Ex ec IIC T4 Gc
Regarding the installation instructions please refer to the following documents:
Class 1 Division 2 Installation Instructions DeltaV S-Series (12P5402)
Zone 2 Installation Instructions DeltaV S-series (12P5
