1C31223G01 模块备件

1C31219G01

可热封、银、化学处理聚酯表面
用于化妆品和食品软包装的层压材料。
粘合剂涂层三层压板：PET 12μ/Adh/Alu
9μ/Adh/LLDPE为75μ。
应用和使用
聚酯面层压袋材料用于柔性
干货和湿货的包装，如
化妆霜、乳液、油和洗发水。好化学品
反对
转换和打印
经过化学处理的PET表面提供了可印刷性、柔印和
用UV低迁移油墨胶印。相对较厚的产品具有：
非常好的尺寸稳定性。
实际使用说明：t应测试本产品
完全在终用户条件下，以确保其符合
具体应用的要求。这尤其是
如果预期用途为食品，则为案例。因此，艾弗里·丹尼森
要求客户进行充分的测试，以确保
预期应用不会造成任何伤害，并且是安全的。
保质期
要获得佳性能，请在半年内使用本产品
制造日期，在规定的储存条件下
通过FINAT（20-25°C；40-50%相对湿度）。长时间储存在室外
这些条件可能会缩短保质期。
基重111 g/m²ISO 536
卡尺96µm ISO 534
断裂伸长率CD>55%DIN 53455
断裂伸长率MD>70%DIN 53455
透氧性（23°C；
50%RH）
<
0.05 cm³/m²/24
人力资源
ASTM D3985
2%割线模量MD＞850 N/mm²DIN EN ISO
527吨3
2%割线模量CD>800 N/mm²DIN EN ISO
527吨3
弯曲模量Fmax MD>750 mN扫描P
29/DIN 52 121
弯曲模量Fmax CD>500 mN扫描P
29/DIN 52 121
撕裂Elmendorf MD＞0.60 N DIN EN 21974
撕裂Elmendorf CD>1.10 N DIN EN 21974
抗拉强度。MD＞35 N/mm²ISO 527-3
抗拉强度。CD>35 N/mm²ISO 527-3
WVTR（38°C；90%相对湿度）<0.05 g/m²/24
人力资源
ASTM F1249
密封强度>35 N/15mm DIN 52
529@140°C/5
巴/0.5秒
内/内COF 0.20-0.35μs ASTM D1895
COF外部/外部0.30-0.45μs ASTM D1895
AO610
Fasson®
化妆品网SILV96升
这是一个自动生成的数据表。所有数据均视为典型数据
价值，如有更改，恕不另行通知。进一步的测试总是
推荐。
如果您想对此数据表提出建议或意见，请发送
电子邮件至datasheet.mgmt@eu.averydennison.com

1C31219G01

1C31219G01

heatsealable, silver, chemically treated polyester faced
laminate used in flexible packaging of cosmetics and foodstuffs.
Adhesive coated three layer laminate: PET 12μ/Adh/Alu
9μ/Adh/LLDPE 75μ.
Applications and Use
Polyester-faced laminated pouching material used in flexible
packaging of dry and wet goods such as product samples of
cosmetic creams, lotions, oils and shampoos. Good chemical
resistance.
Conversion and Printing
The chemically treated PET face provides printability Flexo and
offset with UV low migration inks. The relatively thick product has
very good dimensional stability.
Statement of Practical Use: Tthis product should be tested
thoroughly under end-user conditions to ensure it meets the
requirements of the specific application. This is particularly the
case if the intended use is for food. Avery Dennison therefore
request the client to do sufficient testing to make sure that the
intended application does not cause any harm and is safe.
Shelf Life
To obtain optimal performance, use this product within half a year
of the date of manufacture, under storage conditions as defined
by FINAT (20-25°C; 40-50%RH). Prolonged storage outside
these conditions might reduce the shelf life.
Basis Weight 111 g/m² ISO 536
Caliper 96 µm ISO 534
Elongation at break CD >55 % DIN 53455
Elongation at break MD >70 % DIN 53455
Oxygen Permeability (23°C;
50%RH)
<
0.05 cm³/m²/24
hr
ASTM D3985
2% Secant Modulus MD >850 N/mm² DIN EN ISO
527 T 3
2% Secant Modulus CD >800 N/mm² DIN EN ISO
527 T 3
Flexural Modulus Fmax MD >750 mN SCAN P
29/DIN 52 121
Flexural Modulus Fmax CD >500 mN SCAN P
29/DIN 52 121
Tear Elmendorf MD >0.60 N DIN EN 21974
Tear Elmendorf CD >1.10 N DIN EN 21974
Tensile Stren. MD >35 N/mm² ISO 527-3
Tensile Stren. CD >35 N/mm² ISO 527-3
WVTR (38°C; 90% RH) < 0.05 g/m²/24
hr
ASTM F1249
Sealing Strength >35 N/15mm DIN 52
529@140°C/5
bar/0.5sec
COF inside/inside 0.20 - 0.35 μs ASTM D1895
COF outside/outside 0.30 - 0.45 μs ASTM D1895
AO610
Fasson ®
COSMETIC WEB SILV96 HEAV
This is an automatically generated datasheet. All data to be considered as typical
values and subject to change without prior notice. Further testing is always
recommended.
If you would like to make a suggestion or comment on this datasheet, please send an
email to datasheet.mgmt@eu.averydennison.com
