1C31233G01 模块备件

1C31233G01

如果您的系统已安装火灾探测器，且警报以脉冲模式发出，请按照
立即制定紧急疏散计划（参见15页的“消防逃生计划”）。
入侵报警
如果入侵警报响起，由连续的铃声或警报器指示，则可以通过以下方式使警报静音：
输入您的访问代码。如果警报是无意的，请立即致电当地当局，以避免
这是不必要的回应。
您可以按照“解除报警”部分中的说明确定报警源（请参见
6页）。报警源纠正后，面板可以恢复到其原始状态
武装国家。
注：火灾报警优先于防盗型报警。
功能键
键盘上有五个功能键，分别标记为停留、离开、鸣响、复位和退出，方便操作
单按钮激活常用的功能。如果您的安装程序已启用这些密钥，
您可以通过按住相应的键两次来执行其编程功能
秒。
有关功能键操作的信息，请与报警安装程序联系。
编程安全代码
LED键盘的编程代码：
主代码
要对主代码进行编程，请输入[✱][5] [当前主代码][40][新主代码]。大师
除非安装程序另有说明，否则代码长度必须为四位数。输入数字0到9
只有按[#]返回就绪状态。
注意：您必须对每个访问代码中的所有数字进行编程。
请务必在本手册的“系统信息”页上记录新的主代码。注：我们
建议不要使用出厂默认或明显的代码，如[1111]或[1234]。
附加代码
多可编程32个附加访问代码（01至32）。
要编写新代码：
进入[✱][5] [主代码][代码编号01至32][新访问代码]。代码是双精度的
从01到32的数字。除非安装程序另有说明，否则访问代码必须是四位数字。
仅输入数字0到9。按[#]返回就绪状态。
如果所选代码号的访问代码已经存在，则将用新代码替换
密码请务必在本书的“系统信息”页面上记录您的新代码。
要擦除代码：
进入[✱][5] [主代码][代码编号01至32][✱]. 按[#]返回就绪状态。这个
无法擦除主代码。

1C31233G01

1C31233G01

If your system has been installed with fire detectors and the alarm sounds in a pulsing mode, follow
your emergency evacuation plan immediately (see “Fire Escape Planning” on page 15).
Intrusion Alarm
If an intrusion alarm sounds, indicated by a continuous Bell or Siren, the alarm may be silenced by
entering your access code. If the alarm was unintentional, call local authorities immediately to avoid an
unnecessary response.
You can determine the source of the alarm by following the instructions in the “Disarming” section (see
page 6). Once the source of the alarm has been corrected, the panel can be restored to its original
Armed state.
NOTE: A fire alarm has priority over a burglary type alarm.
Function Keys
The keypads have five function keys – marked Stay, Away, Chime, Reset and Exit – which allow easy
single-button activation of the most commonly used features. If your installer has enabled these keys,
you can execute their programmed function by pressing and holding the corresponding key for two
seconds.
For information regarding the operation of the function keys, talk to your alarm installer.
Programming Security Codes
Programming codes from an LED Keypad:
The Master Code
To program the Master Code, enter [✱][5][current Master Code][40][new Master Code]. The Master
Code must be four digits long, unless otherwise indicated by your installer. Enter digits 0 through 9
only. Press [#] to return to the Ready state.
NOTE: You must program all digits in each access code.
Be sure to record your new Master Code on the “System Information” page in this booklet. NOTE: We
recommend that the factory default or obvious codes such as [1111] or [1234] not be used.
Additional Codes
Up to 32 additional access codes (01 through 32) may be programmed.
To program a new code:
Enter [✱][5][Master Code][code number 01 to 32][new access code]. The code number is a double
digit from 01 to 32. Access codes must be four digits unless otherwise indicated by your installer.
Enter digits 0 through 9 only. Press [#] to return to the Ready state.
If an access code already exists for the code number you have selected, it will be replaced by the new
code. Be sure to record your new code(s) on the “System Information” page in this book.
To erase a code:
Enter [✱][5][Master Code][code number 01 to 32][✱]. Press [#] to return to the Ready state. The
Master code cannot be erased.
