1X00024H01 模块备件

1X00024H01

LED键盘故障：
故障指示灯将指示故障，故障指示灯会一直亮起，直到故障状态为
变明朗。如果无法确定故障状况的原因，请与安装人员联系以获取帮助。
要查看故障状况的类型，请按[✱][2]. 一个或多个区域灯将点亮，指示
各种故障情况：
区域灯故障类型
1…………需要服务。请致电安装公司寻求服务。
2………..表示交流电源的损耗。发生此故障时，故障指示灯将点亮
打开，但键盘蜂鸣器不会鸣响。
3…………电话线路故障。
4………..面板无法与中央站通信。
5……………区域断层。按[5]，与故障区域相对应的区域指示灯将亮起
上。
6…………..区域夯实。按[6]和与篡改区域相对应的区域灯
将打开。
7…………..低区电池。当无线设备显示低电平时，会产生此故障
电池状况。
按[7]一次、两次或三次可查看哪些设备正在使用电池
失败将发生以下情况：
键盘蜂鸣：键盘显示：
按[7]1低电量区域（LED键盘-区域灯1至8）
再次按[7]，2个电池电量低的手持键盘（LED键盘-区域
灯1至4）
再次按[7]，3个电池电量低的无线键（LED键盘-区域灯1
至8）。要查看无线钥匙9的电池状况：
到16岁，您必须在LCD键盘上。
8……….系统时钟上的时间损失。要设置系统时间，请按照中的说明操作
12页的“设置系统日期和时间”。
要查看LCD键盘的故障：
从就绪状态，使用箭头（＜）键滚动至以下消息。
压榨[✱] [2] 按键查看故障。消息将显示。。。
使用箭头（＜）键查看系统上存在的故障。一旦你
滚动浏览故障列表后，按[#]键退出故障查看
模式并返回到就绪状态。
设置系统日期和时间
要设置系统时间，请输入[✱] [6] 然后是主代码。按[1]。键盘现在将接受
10个连续数字：
•使用24小时格式（00:00至23:59）以小时和分钟为单位输入时间。
•以月、日和年（MM-DD-YY）为单位输入日期。
注意：如果您有LCD键盘，安装程序可能已将系统编程为显示时间
以及键盘空闲时的日期。如果是这种情况，您可能必须按[#]键清除
输入访问代码以保护系统或执行任何其他操作之前的日期和时间
键盘功能。
系统故障
（*2）查看<>
查看故障<>
“故障消息”
13
测试您的系统
报警测试
报警测试提供键盘发声器和铃声或警报器的两秒钟测试。从面板开始
处于就绪状态。
从LED键盘输入[✱][6] [Master Code][4]然后按[#]返回就绪状态。
从LCD键盘，预

1X00024H01

1X00024H01

 troubles from an LED Keypad:
A trouble will be indicated by the Trouble light, which will remain ON until the trouble condition is
cleared. If you cannot determine the cause of the trouble condition, contact your installer for assistance.
To view the type of trouble condition, press [✱][2]. One or more zone lights will turn ON, indicating the
various trouble conditions:
ZONE LIGHT TYPE OF TROUBLE
1 ................. Service required. Call your installation company for service.
2 ................. Indicates the loss of AC power. When this trouble occurs, the Trouble light will turn
ON but keypad buzzer will not sound.
3 ................. Telephone line trouble.
4 ................. The panel has failed to communicate with the central station.
5 ................. Zone fault. Press [5] and the zone light(s) corresponding to the faulted zones will turn
ON.
6 ................. Zone tamper. Press [6] and the zone light(s) corresponding to the tampered zones
will turn ON.
7 ................. Low zone battery. This trouble is generated when a wireless device exhibits a low
battery condition.
Press [7] one, two, or three times to view which devices are experiencing battery
failure. The following will occur:
Keypad beeps: Keypad displays:
Press [7] 1 Zones with low batteries (LED keypad - zone lights 1 to 8)
Press [7] again 2 Handheld keypads with low batteries (LED keypad - zone
lights 1 to 4)
Press [7] again 3 Wireless keys with low batteries (LED keypad - zone lights 1
to 8). To view the battery conditions of wireless keys 9
through 16, you must be at an LCD keypad.
8 ................. Loss of time on system clock. To set the system time, follow the instructions in
“Setting System Date and Time” on page 12.
To view troubles from an LCD Keypad:
From the Ready state, use the arrow (< >) keys to scroll to the following message.
Press [✱] [2] key to view the trouble. The message will read...
Use the arrow (< >) keys to view which troubles are present on the system. Once you
have scrolled through the list of troubles, press the [#] key to exit the Trouble Viewing
mode and return to the Ready state.
Setting the System Date and Time
To set the system time, enter [✱] [6] followed by the Master Code. Press [1]. The keypad will now accept
10 consecutive digits:
• Enter the Time in Hours and Minutes using the 24-Hour format (00:00 to 23:59).
• Enter the Date in Months, Days and Years (MM DD YY).
NOTE: If you have an LCD keypad, your installer may have programmed your system to display the time
and date while the keypad is idle. If this is the case, you may have to press the [#] key to clear the
date and time before entering an access code to arm the system, or before performing any other
keypad function.
System Trouble
(*2) to View <>
View Trouble <>
“Trouble Message”
13
Testing Your System
Alarm Test
The Alarm Test provides two-second tests of the keypad sounder and bell or siren. Begin with the panel
in the Ready state.
From an LED keypad, Enter [✱][6][Master Code][4] then press [#] to return to the Ready state.
From an LCD keypad, pre
