测试您的系统
报警测试
报警测试提供键盘发声器和铃声或警报器的两秒钟测试。从面板开始
处于就绪状态。
从LED键盘输入[✱][6] [Master Code][4]然后按[#]返回就绪状态。
在LCD键盘上，按[✱] 以进入功能列表。使用箭头（<>）键滚动查找“用户”
功能”和新闻[✱] 选择。输入主代码并滚动以查找以下消息。。。
压榨[✱] 以执行警报测试。键盘将显示以下消息。。。
按[#]返回就绪状态。
全系统测试
我们建议您每周测试一次系统。如果系统无法正常运行，请致电
安装公司立即提供服务。
注意：在非高峰时间进行系统测试，如清晨或傍晚。
1.通知监控站您正在测试系统。
2.从系统处于就绪状态开始。
3.按执行铃/电池测试[✱][6] [主代码][4]。铃声和键盘蜂鸣器将：
声音持续两秒，所有键盘灯将亮起。按[#]退出。
4.依次激活每个传感器（例如，打开门/窗或进入运动检测器区域）。
在LED键盘上，观察区域激活时区域灯是否亮起。区域灯将：
当系统恢复正常时关闭（即车门或车窗关闭）。
当每个区域激活时，LCD键盘将显示以下消息。。。
使用箭头（＜）键查看打开的区域。此消息将消失
当区域恢复时。
5.如果面板有任何火灾区域，激活将导致报警信号以脉冲模式发出声音。
警告：不要使用明火或燃烧材料测试烟雾或热探测器。
请与您的安装人员联系，以获取有关测试探测器的安全方法的信息。
6.测试完成后，致电并通知监控站。如果系统不能正常工作
请与安装程序联系。
注意：除非安装程序启用，否则上述某些功能将无法运行。
请确保您的安装程序已告知您系统上哪些功能正常。
门铃功能
车门蜂鸣器功能用于在每次打开车门或车窗时从键盘发出提示音
或关闭。您的安装程序将编程哪些车门和车窗将激活门铃。
要从LED键盘激活门铃：
进入[✱][4] 打开和关闭车门蜂鸣器功能。输入命令时，键盘
如果车门蜂鸣功能启用，蜂鸣器将发出3次蜂鸣音，如果启用，则会发出一声长蜂鸣音
残废
安全系统
武装前<>
选择选项<>
系统测试
系统测试
进行中
14
按（*）以获取<>
输出控制
选择输出<>
命令输出#1
选择输出<>
命令输出#2
要从LCD键盘激活门铃：
压榨[✱] 要进入功能列表，请滚动以查找。。。
压榨[✱] 或[4]以启用或禁用车门蜂鸣功能。按[#]返回
准备就绪状态。
火灾报警操作
惊恐
在火灾报警期间，警铃或警报器将脉冲打开和关闭。将警报传输到
监测站延迟30秒。如果在30秒延迟内未清除警报，则将
发送到监控站。
寂静
要使铃声或警报器静音，请按[#]键。如果警报静音，烟雾探测器未静音
重置，90秒后警报将响起。
重置烟雾探测器
烟雾探测器复位后，如果仍检测到烟雾，报警序列将按所述响起
在上面如果没有烟雾，系统将恢复正常。
要从LED键盘重置烟雾探测器：
压榨[✱][7][2].
要从LCD键盘重置烟雾探测器：
压榨[✱] 以进入功能列表。滚动查找：
压榨[✱] 以选择输出控制。显示器将显示。。。
使用箭头（＜>）键查找以下消息，然后按[✱] 关键
选择
注意：如果您怀疑已发出火灾警报，并且没有火灾情况，请拨打
监控站以避免不必要的响应。如果出现明显的火灾情况，请遵循
立即制定疏散计划。如果警报在夜间响起，立即撤离。
注意：以上描述可能不适用，具体取决于安装程序的安装方式
对系统上的火灾报警操作进行编程。请咨询安装程序以获取更多信息
关于您系统的操作。
家庭消防安全审计
大多数火灾发生在家里。为了尽量减少这种危险，我们建议进行家庭消防安全审计
并制定火灾逃生计划。
1.所有电器和插座是否处于安全状态？检查电线是否磨损、过载
照明电路等。如果您不确定电器的状况，或
家政服务，有专业评估这些单位。
2.所有易燃液体是否安全储存在密闭容器中
5X00006H12

5X00006H12

esting Your System
Alarm Test
The Alarm Test provides two-second tests of the keypad sounder and bell or siren. Begin with the panel
in the Ready state.
From an LED keypad, Enter [✱][6][Master Code][4] then press [#] to return to the Ready state.
From an LCD keypad, press [✱] to enter the function list. Use the arrow (< >) keys to scroll to find “User
Functions” and press [✱] to select. Enter your Master Code and scroll to find the following message...
Press [✱] to perform an Alarm Test. The keypad will display the following message...
Press [#] to return to the Ready state.
Full System Test
We recommend that you test your system weekly. Should the system fail to function properly, call your
installation company immediately for service.
NOTE: Perform system tests during off-peak hours, such as early morning or late evening.
1. Inform the monitoring station that you are testing your system.
2. Begin with the system in the Ready state.
3. Perform a Bell/Battery test by pressing [✱][6][Master Code][4]. The bell and keypad buzzer will
sound for two seconds and all keypad lights will turn ON. Press [#] to exit.
4. Activate each sensor in turn (e.g. open a door/window or walk in motion detector areas).
From an LED keypad, observe the zone light turn ON when the zone is activated. The zone light will
turn OFF when the system restores to normal (i.e. door or window closed).
From an LCD keypad, the following message will be displayed when each zone is activated...
Use the arrow (< >) keys to view which zone is open. This message will disappear
when the zone is restored.
5. If the panel has any fire zones, activation will cause the alarm signal to sound in a pulsed mode.
CAUTION: Do not use an open flame or burning materials to test a smoke or heat detector.
Contact your installer for information on safe methods of testing detectors.
6. When testing is complete, call and advise the monitoring station. Should the system fail to function
properly, contact your installer.
NOTE: Some features described above will not be functional unless enabled by your installer.
Please ensure that your installer has advised you which features are functional on your system.
Door Chime Feature
The door chime feature is used to provide a tone from the keypad each time a door or window is opened
or closed. Your installer will program which doors and windows will activate the door chime.
To activate the door chime from an LED Keypad:
Enter [✱][4] to turn the door chime feature ON and OFF. When the command is entered, the keypad
buzzer will beep 3 times if the door chime feature is enabled and will sound one long beep if it is
disabled.
Secure System
Before Arming <>
Select Option <>
System Test
System Test
In Progress
14
Press (*) For <>
Output Control
Select Output <>
Command Output #1
Select Output <>
Command Output #2
To activate the door chime from an LCD Keypad:
Press [✱] to enter the function list, then scroll to find...
Press [✱] or [4] to enable or disable the Door Chime feature. Press [#] to return to the
Ready state.
Fire Alarm Operation
Alarm
During a fire alarm, the bell or siren will pulse ON and OFF. The transmission of the alarm to the
monitoring station is delayed for 30 seconds. If the alarm is not cleared within the 30-second delay, it will
be transmitted to the monitoring station.
Silence
To silence the bell or siren, press the [#] key. If the alarm is silenced and the smoke detector is not
reset, the alarm will resound after 90 seconds.
Resetting Smoke Detectors
Once the smoke detector is reset, if it still detects smoke, the alarm sequence will resound as described
above. If there is no smoke, the system will return to normal.
To reset smoke detectors from an LED Keypad:
Press [✱][7][2].
To reset smoke detectors from an LCD Keypad:
Press [✱] to enter the function list. Scroll to find:
Press [✱] to select the output control. The display will read...
Use the arrow (< >) keys to find the following message and press the [✱] key to
select...
NOTE: If you suspect that a fire alarm has transmitted and that there is no fire condition, call the
monitoring station to avoid an unnecessary response. If a fire condition is apparent, follow your
evacuation plan immediately. If the alarm sounds at night, evacuate immediately.
NOTE: The description above may not be applicable depending on how your installer has
programmed the fire alarm operations on your system. Ask your installer for more information
regarding your system’s operation.
Household Fire Safety Audit
Most fires occur in the home. To minimize this danger, we recommend that a household fire safety audit
is conducted and a fire escape plan is developed.
1. Are all electrical appliances and outlets in a safe condition? Check for frayed cords, overloaded
lighting circuits, etc. If you are uncertain about the condition of your electrical appliances or
household service, have a professional evaluate these units.
2. Are all flammable liquids stored safely in closed containers in a well-ventilated cool area? Cleaning
with flammable liquids should be avoided.
3. Are fire hazardous materials (matches) well out of reach of children?
4. Are furnaces and wood burning appliance
