正确包装REF542plus；好是原始包装
按照规定，事先将装置侧面存放。
无需停用配置程序。如果您希望卸载
配置程序，请遵循相关说明。
8.2储存
请遵守以下佳储存的低要求：
有标准包装或无包装的装置
干燥通风的储存空间，条件符合DIN VDE 0670
1000部分/IEC 60694，
如果使用包装，包装必须完好无损或
无包装的单元必须用保护板覆盖好；然而，确保
足够的空气循环以防止腐蚀。
定期检查机组是否冷凝。
REF 542plus开关间保护和控制单元
手册3部分：安装和调试
1VTA10004 en DMS，2001-10-04参考542 Plus：安装和调试58/80
9.技术数据
9.1模拟输入通道
测量精度，包括1级电流/电压传感器。
保护等级3的精度
9.1.1带电流和电压互感器：
1A或5A中的额定电流
额定电压Un:100V（也适用于110V）
额定频率fn:50 Hz/60 Hz
热负荷能力
电流路径250处于（峰值）动态，
100英寸，持续1s，
4连续，
电压路径2 Un/√3连续。
消耗
电流路径≤ 0.1 VA，带输入
电压路径≤ 0.25 VA，带Un
9.1.2带电流和电压传感器
150 mV（rms）的额定电流
额定电压Un:2V（均方根）
额定频率fn:50 Hz/60 Hz
REF 542plus开关间保护和控制单元
手册3部分：安装和调试
1VTA10004 en DMS，2001-10-04参考542 Plus：安装和调试59/80
9.2二进制输入和输出
每个二进制I/O板具有以下数量的输入和输出：
9.2.1带机械继电器（1 BIO版本3）
辅助电压范围的14个输入（BI 1至14）：
20至90伏直流电（阈值14伏直流电）或
对于辅助电压范围：
80至250伏直流电（阈值50伏直流电）
每个输入具有1ms的固定滤波时间。
扩展可以自由编程。
5个功率输出（BO 1、2、3、4和5）
6（BO6的继电器触点与BO5的继电器触点连接在一起）
大工作电压250V AC/DC
接通电流20 A
负载电流12 A
L/R=15 ms时的断开容量为300 W
操作时间：9毫秒
2个信号输出（BO7和8）和1个看门狗
输出（WD）
工作电压250V AC/DC
负载电流2 A
操作时间：5ms
1静态输出（可选BO7）大工作电压250 VDC
操作时间1毫秒
1线圈监控电路（BO2）
9.2.2具有静态输出（1个生物版本静态）
辅助电压范围的14个输入（BI 1-14）
48至265 VDC（阈值35 VDC）
每个输入具有1ms的固定滤波时间。
扩展可以自由编程。
3个电源输出（BO1、2和7）工作电压48至265 VDC
t的接通电流为70 A≤ 10毫秒
t的负载电流12 A≤ 30秒
操作时间1毫秒
4个电源输出（BO3至6）工作电压48至265 V DC
t的接通电流为16 A≤ 10毫秒
t的负载电流10 A≤ 30秒
操作时间1毫秒
2个信号输出和1个看门狗输出，工作电压48至265 V DC
接通电流0.3 A
操作时间1毫秒

140AMM09000

140AMM09000

Pack the REF542plus properly; preferably in the original packaging
Store the unit on its side beforehand as specified.
It is not necessary to decommission the configuration program. If you wish to uninstall
the configuration program, follow the relevant directions.
8.2 Storage
Please observe the following minimum requirements for optimum storage:
Units with standard packaging or without packaging
Dry and well ventilated storage space, conditions in accordance with DIN VDE 0670
Part 1000/IEC 60694,
If packaging is used, it must be undamaged or
units without packaging must be well covered with protective sheets; however, ensure
sufficient air circulation to prevent corrosion.
Check the unit regularly for condensation.
REF 542plus switchbay protection and control unit
Manual Part 3: Installation and Commissioning
1VTA100004-en DMS,2001-10-04 REF542plus: Installation and Commissioning 58 / 80
9 Technical data
9.1 Analog input channels
Accuracy for measurement including the current/voltage sensors class 1.
Accuracy for protection class 3
9.1.1 With current and voltage transformer:
Rated current In 1A or 5A
Rated voltage Un: 100V (also suitable for 110V)
Rated frequency fn: 50 Hz / 60 Hz
Thermal load capacity
Current path 250 In (peak value) dynamic,
100 In for 1s,
4 In continuous,
Voltage path 2 Un /√3 continuous.
Consumption
Current path ≤ 0.1 VA with In
Voltage path ≤ 0.25 VA with Un
9.1.2 With current and voltage sensor
Rated current In 150 mV (rms)
Rated voltage Un: 2V (rms)
Rated frequency fn: 50 Hz / 60 Hz
REF 542plus switchbay protection and control unit
Manual Part 3: Installation and Commissioning
1VTA100004-en DMS,2001-10-04 REF542plus: Installation and Commissioning 59 / 80
9.2 Binary inputs and outputs
Each binary I/O board has the following number of inputs and outputs:
9.2.1 With mechanical relays (1 BIO version 3)
14 inputs (BI 1 to 14) For auxiliary voltage range:
20 to 90 V DC (threshold 14 V DC) or
for auxiliary voltage range:
80 to 250 V DC (threshold 50 V DC)
Each input has a fixed filter time of 1 ms.
Extension can be freely programmed.
5 power outputs (BO 1,2,3,4 and 5) respectively
6 (Relay contact of BO6 is link together with relay contact of BO5)
Maximal Operation voltage 250V AC/DC
Make current 20 A
Load current 12 A
Breaking capacity 300 W at L/R = 15 ms
Operation time 9 ms
2 signal outputs (BO7 and 8) and 1 Watchdog
output (WD)
Operation voltage 250 V AC/DC
Load current 2 A
Operation time 5 ms
1 Static output (optionally BO7) Maximal Operation voltage 250 VDC
Operation time 1 ms
1 coil supervision circuit (BO2)
9.2.2 With static outputs (1 BIO version static)
14 inputs (BI 1-14) for auxiliary voltage range
48 to 265 VDC (Threshold 35 VDC)
Each input has a fixed filter time of 1 ms.
Extension can be freely programmed.
3 power outputs (BO1,2 and 7) Operation voltage 48 to 265 VDC
Make current 70 A for t ≤ 10 ms
Load current 12 A for t ≤ 30 s
Operation time 1 ms
4 power outputs (BO3 to 6) Operation voltage 48 to 265 V DC
Make current 16 A for t ≤ 10 ms
Load current 10 A for t ≤ 30 s
Operation time 1 ms
2 Signal outputs and 1 Watchdog output Operation voltage 48 to 265 V DC
Make current 0.3 A
Operation time 1 ms
